- Page 1 054-4289-2 20V max* LITHIUM-ION CORDLESS ORIBITAL JIGSAW INSTRUCTION IMPORTANT: Read and understand this instruction manual thoroughly MANUAL before using the product.
- Page 2 headline bars continuation tabs notes warnings...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Technical Specifications Safety Guidelines Key Parts Diagram Assembly Instructions Operating Instructions Maintenance Troubleshooting Parts List Warranty NOTE: If any parts are missing or damaged, or if you have any questions, please call our toll-free helpline at 1-800-689-9928. SAVE THESE INSTRUCTIONS •... -
Page 4: Technical Specifications
054-4289-2 | contact us 1-800-689-9928 TECHNICAL SPECIFICATIONS No-load speed 0-2800 SPM Length of stroke 1" (25.4 mm) Cutting capacity: wood 2 9/16" (65 mm) Cutting capacity: metal 1/4" (6 mm) Blade type T- and U-shank continuation tabs Cutting-angle range 0-45°... -
Page 5: Safety Guidelines
SAFETY GUIDELINES: WARNING! Safety symbols in this Instruction Manual are used to flag possible dangers. The safety symbols and their explanations require your full understanding. The safety warnings do not by themselves eliminate any danger, nor are they substitutes for proper accident prevention measures. - Page 6 054-4289-2 | contact us 1-800-689-9928 ELECTRICAL SAFETY • Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
- Page 7 • Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired. • Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools.
- Page 8 054-4289-2 | contact us 1-800-689-9928 • Hold power tools by insulated gripping surfaces when performing an operation where the tool may contact hidden wiring or its own cord. Contact with a “live” wire may make exposed metal parts of the power tool “live”...
-
Page 9: Key Parts Diagram
• Do not allow familiarity with the cordless jigsaw to cause a lack of alertness. A fraction of a second of carelessness is enough to cause severe injury. • Carefully read the Instruction Manual for your Mastercraft 20V max* Lithium-Ion Battery and Mastercraft 20V max* Lithium-Ion Charger for safety operation instructions. -
Page 10: Assembly Instructions
054-4289-2 | contact us 1-800-689-9928 ASSEMBLY INSTRUCTIONS TO ATTACH BATTERY PACK (fig 1) fig 1 Latch 1. Align the raised portion on the battery pack with the Detach groove on the bottom of the tool, then slide the battery pack into the body of the tool. - Page 11 ADJUSTING THE BASE PLATE FOR BEVEL fig 3a CUTTING (fig 3a, 3b & 3c) 1. Rotate the keyless bevel lever to unlock the base plate; refer to fig 3a. 2. When the adjustment is blocked by the locking knob on the plate base, change it to another side.
- Page 12 054-4289-2 | contact us 1-800-689-9928 INSTALLING THE STRAIGHT EDGE fig 4 GUIDE (fig 4) 1. Loosen the edge-guide locking knob. Edge-guide 2. Insert the bar of the edge guide through the slots in the locking knob base of the jigsaw with the edge guide facing down.
-
Page 13: Operating Instructions
OPERATION INSTRUCTIONS TURNING ON AND OFF (fig 6) fig 6 Lock-off button 1. To turn the saw ON, press the lock-off button and while holding it down, press the trigger switch. (The lock-off button can be pressed on either side.) 2. - Page 14 054-4289-2 | contact us 1-800-689-9928 LED WORKLIGHT (fig 8) fig 8 The LED worklight will illuminate when the trigger switch is pressed. This provides additional light on the surface of the workpiece for operation in lower light situations.
-
Page 15: Metal Cutting
METAL CUTTING When cutting metal, always clamp down the material. Be careful to move the saw along slowly. Use lower speeds. Do not twist, bend, or force the blade. If the saw jumps or bounces, use a blade with finer teeth. If the blade is clogged when cutting soft metal, use a blade with coarser teeth. For easier cutting, lubricate the blade with a stick of cutting wax, if available, or use cutting oil when cutting steel. -
Page 16: Maintenance
054-4289-2 | contact us 1-800-689-9928 MAINTAINANCE BEFORE EACH USE 1. Inspect the jigsaw, the trigger switch and the accessories for damage. 2. Check for damaged, missing, or worn parts. 3. Check for loose screws, misalignment or binding of moving parts, or any other condition that may affect the operation. -
Page 17: Troubleshooting
TROUBLESHOOTING Problem Possible Causes Solution The jigsaw does not start The battery is depleted Charge the battery Blade cannot be removed Saw dust in the blade clamp Clean the clamp slot with a brush Cutting is difficult Saw blade is worn Replace the saw blade If the problem remians unsolved after performing the checks described above, call the toll-free helpline at 1-800-689-9928. -
Page 18: Parts List
054-4289-2 | contact us 1-800-689-9928 EXPLODED VIEW continuation tabs continuation tabs notes notes warnings warnings... - Page 19 Part No. Description No. Part No. Description 3321558000 Left Housing 3520945000 Crank Roller Contact Receptacle 3402407000 5660027000 Circlips For Shaft Assembly 3128596000 Pendulum Lever 2823084000 Quick Clamp Assembly 3660050000 Spring B 5700305000 Upper Sliding Bearing 3700191000 3705624000 Sping Piece 3520668000 Pendulum Lever Shaft 2830082000 Electric Assembly...
-
Page 20: Warranty
This Mastercraft product is guaranteed three (3) years from the date of original retail purchase against defects in materials and workmanship, except for the following components: a) Component A: Batteries, chargers and carrying case, which are guaranteed for a period of 2 years from the date of original retail purchase against defects in workmanship and materials;... - Page 21 The provisions contained in this warranty are not intended to limit, modify, take away from, disclaim or exclude any statutory warranties set forth in any applicable provincial or federal legislation. Made in China Imported by Mastercraft Canada Toronto, Canada M4S 2B8...
