- Page 1 054-8259-0 Orbital Jigsaw INSTRUCTION IMPORTANT: Read and understand this instruction manual thoroughly before MANUAL using the product.
-
Page 2: Table Of Contents
headline bars TAbLe Of CONTeNTS Technical Specifications Safety Guidelines 5–8 Key Parts Diagram Important Information 10–12 continuation tabs Assembly Instructions 13–14 Operating Instructions 15–17 Maintenance Troubleshooting notes Part list 20–21 Warranty 22–23 warnings NOTe: If any parts are missing or damaged, or if you have any questions, please call our toll-free helpline at 1-800-689-9928 SAVe THeSe INSTRUCTIONS • This manual contains important safety and operating... -
Page 3: Technical Specifications
054-8259-0 | contact us 1.800.689.9928 RULeS fOR SAfe OPeRATION TeCHNICAL SPeCIfICATIONS WARNING! Rated power input Rated voltage 120V~, 60Hz Safety symbols in this Instruction Manual are used to flag possible dangers. The safety symbols and their explanations require your full understanding. The safety warnings do not, by themselves, No load speed 800–3000 SPM... - Page 4 054-8259-0 | contact us 1.800.689.9928 eLeCTRICAL SAfeTy • Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety • Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter measures reduce the risk of starting the power tool accidentally. plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of • Store idle power tools out of the reach of children and do not allow persons unfamiliar with the...
-
Page 5: Key Parts Diagram
054-8259-0 | contact us 1.800.689.9928 SAfeTy gUIdeLINeS fOR jIgSAw PACKAge CONTeNTS • Hold the power tool by the insulated gripping surfaces when performing an operation where the Orbital jigsaw, edge guide, hex key (installed on the tool), wood cutting blade and instruction manual. cutting accessory may contact hidden wiring or its own cord. If a cutting accessory contacts a “live” wire, Key PARTS dIAgRAM it may make the exposed metal parts of the power tool “live”... -
Page 6: Important Information
054-8259-0 | contact us 1.800.689.9928 IMPORTANT INfORMATION ORbIT AdjUSTMeNT (fig 3) fig 3 Before attempting to use this tool, become familiar with all of its operating features and safety requirements. The jigsaw has orbital action, whereby the blade roller For optimum performance and safety, read the following operating instructions carefully before using. -
Page 7: Assembly Instructions
054-8259-0 | contact us 1.800.689.9928 THe fOLLOwINg CHART CAN HeLP yOU PICK THe PROPeR SPeed, bLAde ASSeMbLy INSTRUCTIONS fig 6 ANd ORbIT ACTION INSTALLINg THe SAw bLAde (fig 6) workpiece to be cut Setting on the speed... -
Page 8: Operating Instructions
054-8259-0 | contact us 1.800.689.9928 ATTACHINg THe edge gUIde (fig 8) OPeRATINg INSTRUCTIONS fig 8 1. Loosen the two edge guide locking knobs. TURNINg ON ANd Off (fig 10) fig 10 2. Insert the bar of the edge guide through the slots 1. - Page 9 054-8259-0 | contact us 1.800.689.9928 geNeRAL CUTTINg PLUNge CUTTINg ( (fig 12) fig 12 Plunge cutting is useful and time-saving for making 1. Make sure that the workpiece is firmly clamped to prevent the workpiece from moving while cutting.
-
Page 10: Maintenance
054-8259-0 | contact us 1.800.689.9928 MAINTeNANCe TROUbLeSHOOTINg Problem Possible Causes Solution befORe eACH USe The motor does not start The tool is not connected to a power source Connect the tool to a power source 1. Inspect the jigsaw, the trigger switch, the cord and the accessories for damage. -
Page 11: Exploded View
054-8259-0 | contact us 1.800.689.9928 exPLOded VIew Part No. description No. Part No. description 2750883000 Rotor 2821924000 Base Plate Assembly 2823927000 Internal Wire Assembly 3703598000 Clamp 2740103000 Stator 3700149000 Square Washer 2822537000 Bearing Support Assembly... -
Page 12: Operating Instructions
MastErCraFt CaNaDa tOrONtO, CaNaDa M4s 2b8 This Mastercraft product is guaranteed for a period of 3 years from the date of original retail purchase against defects in workmanship and materials, except for the following components: a) Component A: Batteries, chargers and carrying case, which are guaranteed for a period of 2 years from the...
