- Page 1 C-600 Series Genisys Solution Guide...
- Page 2 Genisys Solution Guide SC60010 C-600 24 Port Gigabit PoE++ Managed Switch 2 SFP Combo Port - 2 -...
-
Page 3: How To Use This Guide
How to Use This Guide This guide includes detailed instructions on how to optimize a C-600 Series switch for use with Genisys PoE Lighting System based on the requirements and information provided by Innovative Lighting. Who Should Read This guide is for network administrators who are responsible for this Guide? operating and maintaining network equipment. -
Page 4: Table Of Contents
Contents Contents How to Use This Guide ......................3 C-600 Series Genisys Configuration via Web Interface ............5 Device Management System (DMS) ..................... 6 Power over Ethernet (PoE) Mode ....................7 Power Mode ..........................8 - 4 -... -
Page 5: C-600 Series Genisys Configuration Via Web Interface
Dante Solution Guide C-600 Series Genisys Configuration via Web Interface See the Preparation for Web Interface section of the Web Management Guide for how to connect and login to the C-600 Switch - 5 -... -
Page 6: Device Management System (Dms)
Genisys recommends disabling the built in Device Management System of the C-600 Series switch. o By default DMS is disabled on the C-600 Series switches but if it was previously enabled it can be disabled by going to the DMS menu... -
Page 7: Power Over Ethernet (Poe) Mode
Power over Ethernet (PoE) Mode 1. Configure PoE Mode: o Navigate to Switch-> Configuration - > PoE - > Configuration o For each port that will have Genisys units select PoE Mode: 4-Pair For each port that will have Genisys units select Maximum Power: 60 - 7 -... -
Page 8: Power Mode
Power Mode 1. Configure secondary power supply to “Boost” mode: By default the secondary power supply on the C-600 Series switch is set to Boost mode but if it was previously changed to Redundant mode it can be set as follows: o Navigate to Switch->Configuration->System->Power Information... - Page 9 Startup Config 1. Saving the configuration file o Click the Save Current Settings button in the upper right of the screen - 9 -...
