Attaching the Accessories
CAUTION Ensure that the vacuum cleaner is not connected to the mains charger before use.
The Floor Attachment
1. Push the Aluminium Flexi Tube (21) onto the Air Intake (13) until it clicks home as shown
below:
2. Push the Motorised Floor Tool (16) onto the other end of the Aluminium Flexi Tube (21)
again until it clicks home.
Selecting the Correct Brush for the Motorised Floor Tool (16)
1. Before using the Motorised Floor Tool
(16), first choose the appropriate brush
type for the floor type being cleaned:
Select the Carpet Brush (22) for vacuum
cleaning carpets, rugs, etc.
Select the Hard Floor Brush (23) for
cleaning vinyl, laminate, tiled floors, etc.
2
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
1
2. To change the brush attachment,
slide the catch (a) to the left and lift
up the brush bearing retaining clip (b)
on the underside of the Motorised
b.
Floor Tool (16) as shown left.
a.
NB the Carpet Brush (22) is currently
fitted in this example.
c.
Lift out the Carpet Brush (22) and the
brush bearing (c). Remove the brush
bearing from the Carpet Brush (22).
