- Page 1 Tornado PET 700w Cyclonic Vacuum Cleaner Model No. FLR00048 User Manual IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
Tornado PET 700w Cyclonic Vacuum Cleaner Model No. FLR00048 User Manual Contents Page No. Contents Reading and Storing the User Manual Important Safety Instructions for Proper Use Explanation of Symbols Description of Parts & Accessories Assembling Your Vacuum Cleaner Using the Floor Tool Using Your Vacuum Cleaner Using the Crevice and Upholstery Multi Tool Using the Pet and Stair Brush... -
Page 3: Reading And Storing The User Manual
Tornado PET 700w Cyclonic Vacuum Cleaner Model No. FLR00048 User Manual READING AND STORING THE USER MANUAL Before using this product, please read through this manual carefully paying particular attention to the safety instructions. Failure to do so may result in personal injury or damage to the product. - Page 4 Tornado PET 700w Cyclonic Vacuum Cleaner Model No. FLR00048 User Manual to the mains supply. DO NOT use this appliance outdoors. • It is imperative to unplug the power cord after the • appliance has been used, before it is cleaned and whilst being repaired.
- Page 5 Tornado PET 700w Cyclonic Vacuum Cleaner Model No. FLR00048 User Manual Ensure fingers and other objects are never placed in any • part of the vacuum cleaner. Clothing or hair may become trapped if the vacuum is used improperly. Keep hair, loose clothing, jewellery, fingers and all parts of •...
-
Page 6: Explanation Of Symbols
Tornado PET 700w Cyclonic Vacuum Cleaner Model No. FLR00048 User Manual Explanation of Symbols The following warning symbols or words are used in this instruction manual: Products labelled with UK Conformity Assessment identifies products conforming to UK statutory requirements. Products labelled with this symbol conform to applicable provisions of the European Economic Area. -
Page 7: Description Of Parts & Accessories
Tornado PET 700w Cyclonic Vacuum Cleaner Model No. FLR00048 User Manual Description of Parts & Accessories 1. Cylinder Release Catch 2. Cable Retract Button (press to wind in the mains cable) 3. Wheel(s) 4. Cyclonic Filter Assembly 5. Air Intake 6. -
Page 8: Assembling Your Vacuum Cleaner
Tornado PET 700w Cyclonic Vacuum Cleaner Model No. FLR00048 User Manual Assembling Your Vacuum Cleaner CAUTION Ensure that the vacuum cleaner is not connected to the mains supply before connecting the attachments. Attaching the Flexible Hose (13) Left: Attach the Flexible Hose (13) to the vacuum cleaner by pushing the Hose Connector (16) into the Air Intake (5) until it clicks home. -
Page 9: Using Your Vacuum Cleaner
Tornado PET 700w Cyclonic Vacuum Cleaner Model No. FLR00048 User Manual 2. Attach the Floor Tool (11) to the other end of the Telescopic Tube (17) as shown below: 3. Extend the Telescopic Tube (17) to the desired length by pushing the catch down and adjusting in or out as below: Using Your Vacuum Cleaner 1. -
Page 10: Using The Crevice And Upholstery Multi Tool
Tornado PET 700w Cyclonic Vacuum Cleaner Model No. FLR00048 User Manual Using the Crevice & Upholstery Multi Tool (18) Below: Attach the Crevice & Upholstery Multi Tool (18) onto the Telescopic Tube (17) to clean carpet edges, upholstered furniture and hard to get at areas: Left: Attach the Crevice &... -
Page 11: Using The Pet And Stair Brush
Tornado PET 700w Cyclonic Vacuum Cleaner Model No. FLR00048 User Manual Using the Pet and Stair Brush (12) Above: Use the Pet and Stair Brush (12) to remove pet hairs and difficult to remove marks from upholstery and stairs. This should be fitted onto the hose as shown above. The fixed combs and rotating brush clean up the stubborn or matted hairs. -
Page 12: Emptying Your Vacuum Cleaner
Tornado PET 700w Cyclonic Vacuum Cleaner Model No. FLR00048 User Manual Emptying Your Vacuum Cleaner WARNING! Always disconnect the cleaner from the mains power supply before cleaning. 1. Left: Once the dust level reaches the ‘MAX’ mark (arrowed left) on the Dust Compartment (6) it will need emptying and the filters cleaned. - Page 13 Tornado PET 700w Cyclonic Vacuum Cleaner Model No. FLR00048 User Manual 2. Right: Hold the Dust Compartment (6) and twist off the Cyclonic Filter Assembly (4) from the top of the Dust Compartment (6) as shown right. 3. Left: Remove the Cotton (a) and the Foam filter (b).
-
Page 14: Removing & Cleaning The Outlet Filter
Tornado PET 700w Cyclonic Vacuum Cleaner Model No. FLR00048 User Manual Removing & Cleaning the Outlet Filter Remove the outlet Hepa filter located under the Dust Compartment (6) as follows: a. Remove the filter cover by pushing the catch to the right and then lift out the cover. -
Page 15: Recommended Filter Cleaning Intervals
Tornado PET 700w Cyclonic Vacuum Cleaner Model No. FLR00048 User Manual Recommended Filter Cleaning Intervals Filter Type Recommended cleaning period • Shake out debris when you empty the dust container Round Cotton • Rinse under warm water once a Filter month •... -
Page 16: Technical Specification
Tornado PET 700w Cyclonic Vacuum Cleaner Model No. FLR00048 User Manual Technical Specification Model Number FLR00048 Supply Voltage AC 220-240V ~ 50/60Hz Rated Power 700W (max) Protection Class Unpacked Weight (approx.) 5.9 Kgs Dimensions (approx.) 390mm (l) x 270mm (w) x 330mm (h) Vacuum >17KPA Max Air Flow... -
Page 17: Recycling Information
• Replacement parts and accessories are guaranteed for 1 year from the date of purchase. • It is important to note that your warranty becomes invalid should non Daewoo parts or accessories be used with this appliance. IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE... -
Page 18: Warranty
As part of our commitment to quality, we are offering you an extra 2 years warranty in addition to your 1 year guarantee Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof of purchase or receipt. If any defect should occur due to faulty workmanship or material, your faulty product should be returned to the place of purchase, replacement or refund is at the discretion of the retailer.
