- Page 1 Cyclone Freedom Pro 22.2V Cordless Vacuum FLR00040 User Manual IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE...
-
Page 2: Important Safeguards
Cyclone Freedom Pro 22.2V Cordless Vacuum FLR00040 User Manual IMPORTANT SAFEGUARDS When using electrical appliances, basic safety precautions should always be followed. These instructions should be saved for future reference: • Read and familiarise yourself with all operating instructions before using this Vacuum Cleaner. - Page 3 Cyclone Freedom Pro 22.2V Cordless Vacuum FLR00040 User Manual airflow. • Avoid directing the appliance towards naked flames as the air discharged may extinguish gas fires or pilot lights and may disturb ashes in open fires. • Do not Vacuum water or any other liquids with this vacuum.
- Page 4 Cyclone Freedom Pro 22.2V Cordless Vacuum FLR00040 User Manual Before the first time you use your Cordless Vacuum Cleaner Please read these operating instructions thoroughly and keep them in a safe place for future reference. Remove all packing materials and discard responsibly.
- Page 5 Cyclone Freedom Pro 22.2V Cordless Vacuum FLR00040 User Manual Selecting the Correct Brush for the Motorised Floor Tool (12) 1. Before using the Motorised Floor Tool (12) the first choose the appropriate brush type for the floor type being cleaned: Select the Carpet Brush (19) for vacuum cleaning carpets, rugs, etc.
- Page 6 Cyclone Freedom Pro 22.2V Cordless Vacuum FLR00040 User Manual 1. Grasp the vacuum cleaner firmly by the Handle (6) and press the On/off Trigger Switch (7) to power up the cleaner. 2. During use, press the Min/Max Power Button (8) to select between minimum or maximum suction power.
- Page 7 Cyclone Freedom Pro 22.2V Cordless Vacuum FLR00040 User Manual Using the Crevice & Upholstery Tool (13) 1. Attach the Crevice Tool & Upholstery Tool (13) onto the Aluminium Tube (17) to clean carpet edges and hard to get at areas:...
- Page 8 Cyclone Freedom Pro 22.2V Cordless Vacuum FLR00040 User Manual Emptying and Cleaning Your Cordless Vacuum Cleaner WARNING Always disconnect the cleaner from the mains charger before cleaning. 1. Once the dust level reaches the ‘MAX’ mark (arrowed left) on the Dust compartment (4) it will need emptying and the filters cleaned.
- Page 9 Cyclone Freedom Pro 22.2V Cordless Vacuum FLR00040 User Manual 4. Twist the Motor Housing (11) in the direction of the arrow shown right and remove. 4. Rotate the Conical Hepa Filter (2) anticlockwise and remove it from the Dust Compartment (4).
- Page 10 Cyclone Freedom Pro 22.2V Cordless Vacuum FLR00040 User Manual Replacing the Filters in Your Cordless Vacuum Cleaner 7. First replace the Cyclonic Filter (2) into the Dust Compartment (4), ensure that the two arrows on the cyclonic filter and the Dust Compartment (4) line up as shown circled left.
- Page 11 Cyclone Freedom Pro 22.2V Cordless Vacuum FLR00040 User Manual Recommended filter cleaning intervals Filter Type Recommended cleaning period • Shake out debris when you empty the dust container Conical Hepa Filter • Rinse under warm water once a month • Allow to dry thoroughly for 24 hours before reuse.
-
Page 12: Troubleshooting Guide
Cyclone Freedom Pro 22.2V Cordless Vacuum FLR00040 User Manual Troubleshooting Guide Problem Possible Cause Solution Unit fails to turn on. Internal battery not Charge the internal battery. charged. The charger is not Ensure the charger is fully plugged into the mains inserted into the socket and socket. - Page 13 Cyclone Freedom Pro 22.2V Cordless Vacuum FLR00040 User Manual IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE...
