2. External View 2-1. External Components List Model Name Part Name RCC-250F RCC-250B RCC-250S A : Dust Box ○ ○ ○ B : Main Handle (Cord Rewind Button) ○ ○ ○ C : On / Off Button ○ ○ D : Volume Dial ○...
3-2. Circuit Diagram 3-2-1. RCC-250F Circuit Diagram 0.22μ F AC 275V AC 230V 50Hz SWITCH THERMOSTAT MOTOR...
Page 9
3-2-2. RCC-250B Circuit Diagram LED PCB LEDJ BTA12 600BW MOTOR 1000μ F 0.22μ F AC 275V AC 230V 200K 50Hz 1N5399 1/2W 1/2W 0.22μ F 5.6V Pressure Switch SWITCH 474K R4 1K THERMOSTAT...
Page 10
3-2-3. RCC-250S Circuit Diagram LED PCB LEDJ BTA12 600BW MOTOR 1000μ F 0.22μ F AC 275V AC 230V 200K 50Hz 1N5399 1/2W 1/2W 0.22μ F 5.6V Pressure Switch 474K THERMOSTAT R4 1K...
Repair (See 5-1,5-3) or poor contacts in Cord Reel assembly Defective Motor Replace it (See 5-2) Breaking of connections in internal Repair (See 5-1) wiring Breaking of Zener Diode(ZD) Replace it (See 5-1) on PCB Defective Switch (RCC-250F,B) Replace it (See 5-4)
Page 12
Trouble Cause Countermeasure Motor does not stop Defective PCB assembly Replace it (See 5-1) even if switch off Power Cord is Broken Reel Spring of Cord Reel Replace it (See 5-3) not wound up assembly Power Cord broke away from Repair (See 5-3) the Bobbin ※...
5. Disassembling & Treatment 5-1. Cleaner Assembly Cover Top AS Box Dust AS Screw Cover AS Motor AS Cord Reel AS Cap Side AS Body AS Cap Side AS 1) Remove DUST BOX AS - pusing BOX DUST BUTTON 2) Remove 2 CAP SIDE AS - rotating CAP as above 3) Take COVER TOP AS out of COVER AS by using an awl or "-"...
5-2. Motor Assembly RCC-250B RCC-250F RCC-250S 1) Draw FILTER EXHAUST (#8-9 or #10) in back side of MOTOR AS 2) Unscrew a SCREW (#8) then remove PCB 3) Unscrew 4 SCREWs (#8), Check MOTOR(#1) - whether the motor is burnt out or not.
5-3. Cord Reel Assembly CORD REEL AS 14 15 1) Take CORD REEL AS out of BODY AS -- to be continued in next page...
Page 16
2) Before separate BOBBIN(5), CORD PLUG(9) pull out from the pocket of BRACKET(1) and push LEVER CR(2) for reducing the elasticity of REEL SPRING 3) Unscrew a SCREW (#20) and separate BOBBIN(5) from BRACKET(1) and check the contackts between the Y TERMINALS(13,14) and RING TERMINALS(7,8) 4) Check LEVER SPRING(4) 5) If ROLLER BRAKE(3) is worn out and Unscrew a SCREW(5), separate LEVER(2) from BRACKET(1) AND replace ROLLER BRAKE(3)
5-4. Cover Body Assembly RCC-250B RCC-250F RCC-250B RCC-250B RCC-250S 1) Take HANDLE(#4) out of COVER BODY by using an awl or "-" scerw driver and check them. 2) Unscrew 2 SCREWS (#3) then remove HANDLE ASSY(#2) 3) Take SWITCH(#5), HARNESS SW(#6) out of COVER BODY by using an awl or "-" scerw driver 4) Unscrew a SCREW (#8) then remove SLIDE VOL PCB and check it.
Page 21
Part Name Part Code Descriptions Q'nty BODY AS 3620413320 ASSY(RCC-250) HIGH, NONCURREN MOTOR CASE AS CORD REEL AS 3629508850 ASSY(RCC-250, EU) PCB POWER CONTROL AS 3624316040 RCC-2505SN 220_240V/50HZ SCREW TAPPING 7121402011 T2S PAN 4X20 MFZN COVER AS 3621444550 ASSY(RCC-250) LOW COVER TOP L 3621443200 COVER SIDE R ASSY...
6-4. Motor Case Assembly RCC-250B RCC-250F RCC-250S...
Page 27
Part Name Part Code Descriptions Q'nty MOTOR UNIVERSAL 396251125Z 220-230V, 50/60Hz, 1500W PACKING MOTOR 3624011000 NR FOAM (ZX) MOUNT MOTOR 3627902000 NR SHORE-A 60±5 CASE MOTOR FRONT 3621109100 CASE MOTOR REAR 3621109200 FILTER CASE 3621912100 PE 3T GUIDE EXHAUST 3622506600 SCREW TAPPING 7121401411 T2S PAN 4X14 MFZN...
6-6. Cover Side Assembly Part Name Part Code Descriptions Q'nty COVER SIDE R ASSY 3621444300 ASSY(RCC-250) HIGH COVER SIDE L 3621443500 CAP SIDE L 3620905500 COVER SIDE L ASSY 3621444400 ASSY(RCC-250) HIGH COVER SIDE R 3621443600 CAP SIDE L 3620905500...
