BGS technic BGS 8698 Quick Start Manual

Glow Plug Electrodes Removal Tool Set, M8 / M10

TOOLS

1 Extractor spindle M4 x 0.7 x 100 mm
2 Extractor spindle M4 x 0.7 x 100 mm
3 Extractor spindle M3 x 0.5 x 100 mm
4 Twist drill 3.3 x 140 mm
5 Twist drill 2.5 x 120 mm
6 Screw tap M4 x 0.7
7 Screw tap M3 x 0.5
8 Spindle guide M10 x 1.25
9 Spindle guide M10 x 1
10 Spindle guide M8 x 1
11 Guide bolt M10x1. 25 (3.5 mm)
12 Guide bolt M10x1 (3.5 mm)
13 Guide bolt M8x1 (3.5 mm)
14 Guide bolt M8x1 (2.5 mm)
15 Guide bolt M8x1 (2.5 mm)
16 Guide bolt M10 x 1 (4.5 mm)
17 Guide bolt M10 x 1.25 (4.5 mm)
18 Guide bolt M10 x 1.0 (3.5 mm)
19 Guide bolt M10 x 1.25 (3.5 mm)
20 Spindle nut M4 x 0.7
21 Spindle nut M4 x 0.7
22 Spindle nut M3 x 0.5

INTENDED USE

This tool kit is used to dismantle broken glow plug tips.
The included tools are suitable for glow plugs M8x1, M10x1 and M10x1.25.

SAFETY INSTRUCTIONS

•
Use the tool for those jobs only for which it was designed.
•
Always wear safety goggles and gloves when working with this tool.
•
After completion of the repair work, make sure all tools have been removed from the engine
compartment.
•
Remove the ignition key to prevent the engine from being inadvertently started.
•
Do not use the tool if any parts are missing or damaged.

USE

Glow plug bodies with hexagonal drive and electrical
connection can be dismantled.
BGS technic KG
Bandwirkerstr. 3
D-42929 Wermelskirchen
Tel.: 02196 720480
Fax.: 02196 7204820
mail@bgs-technic.de
After breaking, the glow plug tip stays in
the cylinder head and can only be
removed by means of this tool or after
dismantling the cylinder head.
www.bgstechnic.com
© BGS technic KG, Copying and further use not allowed
BGS 8698
