  • Page 1 GRUNDFOS INSTRUCTIONS CIM 260 and CIM 280 cellular modules Installation and operating instructions Installation and operating instructions Other languages net.grundfos.com/qr/i/99440283...

  • Page 2: Table Of Contents

    Original installation and operating instructions CAUTION These installation and operating instructions Indicates a hazardous situation which, if describe Grundfos CIM 260 and CIM 280 cellular not avoided, could result in minor or modules. moderate personal injury. Sections 1-2 give the information necessary to be able to install and start up the products in a safe way.

  • Page 3: Installing The Product

    RF exposure compliance. - Before starting any work on the product, The antenna used for the product in which CIM 260 make sure that the power supply has or CIM 280 is fitted must be installed to provide a...

  • Page 4: Fitting A Cellular Antenna

    2. Remove the PIN code from the SIM card, or set it the cellular network. to "4321". See the manual of the mobile phone. External antenna 3. Insert the SIM card into CIM 260 or CIM 280. See See fig. 3. fig. 4. Connect the antenna cable to the SMA connection For CIM 280, you must have a SIM card (pos.

  • Page 5: Connecting The Battery And Power Supply

    2.7.1 Connecting the battery The CIM 260 and CIM 280 cellular module can be fitted with a lithium-ion battery, part number 99465650. It is secured by a velcro strap which absorbs vibrations and makes it easier to replace the battery. Connect the battery to CIM 260 or CIM 280 as shown in fig.

  • Page 6: Product Introduction

    This is not described in this document. CIM 260 or CIM 280 is supplied separately and must Pos. Designation Description be fitted in the product to be communicated with or in Battery socket a CIU unit (CIU = Communication Interface Unit).

  • Page 7: Leds

    3.2 LEDs CIM 260 and CIM 280 cellular module have two LEDs. See fig. 6. • Yellow and green status LED (LED1) for cellular communication • Red and green status LED (LED2) for internal communication between CIM 260 or CIM 280 and the Grundfos product.

  • Page 8: Fault Finding The Product

    4. Fault finding the product Faults in a CIM 260 or CIM 280 cellular module can DANGER be detected by observing the status of the two communication LEDs. See the table below and Electric shock section LEDs. Death or serious personal injury...
  • Page 9 CIM 260 or 280 fitted in the CIU unit Fault (LED status) Possible cause Remedy Both LEDs (LED1 and LED2) The CIU unit is defective. Replace the CIU unit. remain off when the power The CIM module is defective. Replace the CIM module.

  • Page 10: Technical Data

    This product or parts of it must be disposed of in an environmentally sound way: 1. Use the public or private waste collection service. 2. If this is not possible, contact the nearest Grundfos company or service workshop. See also end-of-life information at www.grundfos.com/product-recycling. The crossed-out wheelie bin symbol on...
