DESCRIPTION
The patented Cord Take-Up System
(CTS) for Horizontal Blinds, enables
the lift and tilt functions and prevents
cord slippage, tangling and overlap.
By using the Cord Take-Up System
versus a tape, you achieve increased
product reliability, smoother and
more uniform operation and
RECOMMENDED COMPONENTS
Motor 400's (Sonesse 404S2, 406R2, 409R2)
Octagonal Crown and Drive Kit (# 9012225)
Motor/Idler Brackets x (2) (#9500736)
Tube 40mm Octagonal (# 1781154)
End Cap 40mm Octagonal (# 9012274)
CTS 40 Cone and Cradle Kit (#1781118)
RECOMMENDED HEADRAIL:
57mm x 51mm
Hunter Douglas, Perma Turnils, Graber, Levolor/Kirsch etc...
TECHNICAL SPECIFICATIONS
Sonesse
Maximum lifting
capacity
(lbs.)
404 S2
21
406 R2
31.5
409 R2
44
* *
Specifications based on motors used with (CTS). They are approximate and may
vary depending on product and application.
CTS40
Fabrication Instructions
eliminate unsightly tapes that don't
match horizontal blind colors.
What's more, manufacturing and
assembling horizontal blinds with
cords is an easier process.
motor
bracket crown
Maximum area for
Maximum area for
50 mm
50 mm
Aluminum blinds
Wood blinds
(sq. ft.)
(sq. ft.)
102
46
152
68
172
92
cone
motor
400s
Cts 40 cone
tube
and cradle
Maximum height
Operator
with
speed
o 1.4 mm cord
(RPM)
(ft.)
15
36
15
24
15
14
cradle
end
idler
drive
wheel
cap
bracket
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SOMFY Sonesse CTS40 404 S2
Summary of Contents for SOMFY Sonesse CTS40 404 S2
- Page 1 CTS40 Fabrication Instructions DESCRIPTION eliminate unsightly tapes that don't The patented Cord Take-Up System match horizontal blind colors. (CTS) for Horizontal Blinds, enables What's more, manufacturing and the lift and tilt functions and prevents assembling horizontal blinds with cord slippage, tangling and overlap. cords is an easier process.
- Page 2 .787" (20mm) *SOMFY can provide Tool and Die (#1781099) to enable accurate punching for CTS components. Contact our sales group for pricing and availability. 3. Drill the holes necessary for the motor and plug end and for access to the limit switch screws.
- Page 3 B. Motor and Tube Preparation 1. Cut 40mm octagonal tube to appropriate length for application. * Take-up cords that are 6" from end of headrail (Max length of tube = headrail length - 4 / ") 2. Insert 40mm octagonal end cap into end of tube. 3.
- Page 4 D. Cradle Bearing Assembly 1. Insert cradle bearing into headrail. It is recommended that all cradle bearings are positioned in the same direction. Headrail 2. Feed the take-up cords through the center holes of the cradle bearings as illustrated below. Be sure the cord is positioned in relation to the ladder braid.
- Page 5 E. Cone Assembly 1. With the take-up cord resting over the edge of the headrail, position the cone over the cradle bearing and slide ladder braid over the cone and into the groove as shown below. 2. Press cone into headrail and position into cradle bearing. Groove Ladder Braid Take-up...
- Page 6 G. Securing Take-up Cords 1. Temporarily hang the blind and extend slats to a 1. Temporarily hang the blind and extend slats to a "lowered position." (be certain take-up cords remain accessible.) "lowered position." (be certain take-up cords remain accessible.) 2.
