- Page 1 EDGE SPOT WELD DRILL EDGE SPOT WELD DRILL MODEL NO: CAT68 PART No: 3110740 OPERATION & MAINTENANCE INSTRUCTIONS 0602 0502...
- Page 2 Fig. 2 Please note that the details and specifications contained herein are correct at the time of going to print. However CLARKE International reserve the right to change specifications at any time without prior notice. Always consult the machines data plate...
-
Page 3: Clarke Guarantee
PARTS: Parts@clarkeinternational.com SERVICE: Service@clarkeinternational.com ACCESSORIES A wide range of Airline accessories is available, including Filter/Regulators, Lubricators, High Pressure Hoses from 5 to 100 Metres, etc. Contact your CLARKE dealer for further informa- tion, or CLARKE International Sales Department on 01992 565300... -
Page 4: Safety Precautions
They add weight ¼” hose adapter, (A whip hose with Quick Fit and could fail due to vibration. coupling is available from your CLARKE ❐ DO NOT overreach. Keep your proper dealer). then connect the other end to the footing and balance at all times. -
Page 5: Maintenance
If the drill is to be stored, or is idle for longer Noise Level 90 dB(A) than 24 hours, run a few drops of Clarke Air Line Oil into the air inlet, and run the tool for 5 seconds in order to lubricate the internal... -
Page 6: Parts Diagram
PARTS DIAGRAM PARTS LIST Index Part Description Index Part Description KL0608001 Valve Screw KL0608025 Planet Carrier KL0608002 ‘O’ Ring KL0608026 Planet Gear KL0608003 ‘O’ Ring KL0608027 Planet Cage KL0608004 Air Controller KL0608028 Spindle Shaft KL0608005 Valve Spring KL0608029 Internal Gear KL0608006 Valve Stem KL0608030...
