Summary of Contents for Clarke Air CAT107
- Page 1 1/2” REVERSIBLE DRILL 1/2” REVERSIBLE DRILL MODEL No: CAT107 Part No: 3110863 OPERATION & MAINTENANCE INSTRUCTIONS 1007...
-
Page 3: Specifications
Always consult the machine’s data plate GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase. This guarantee is invalid if the product is found to have been abused or tampered with in any way, or not used for the purpose for which it was intended. -
Page 4: Declaration Of Conformity
DECLARATION OF CONFORMITY We declare that these products comply to the following standards/directives • 98/37/EC Model No: CAT107 Serial or Batch number: See product data plate signature: D. Kemp ENGINEERING MANAGER... -
Page 5: Safety Precautions
SAFETY PRECAUTIONS IMPORTANT FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN PERSONAL INJURY, AND/OR DAMAGE TO PROPERTY. WORK ENVIRONMENT • Keep the work area clean and tidy. • Dress appropriately - Do not wear loose clothing or jewellery. Tie long hair out of the way. - Page 6 SAFETY PRECAUTIONS • Always disconnect from the air supply when: Performing any maintenance The air drill is not in use. The air drill will be left unattended. Moving to another work area. Passing the air drill to another person. • Never use the air drill if it is defective or operating abnormally.
-
Page 7: Air Supply
PARTS Secondary Handle Trigger Chuck Direction Selector Air Inlet AIR SUPPLY WARNING! COMPRESSED AIR CAN BE DANGEROUS. ENSURE THAT YOU ARE THOROUGHLY FAMILIAR WITH ALL PRECAUTIONS RELATING TO THE USE OF COMPRESSORS AND COMPRESSED AIR SUPPLY. • Use only clean, dry, regulated compressed air as a power source for the air drill. •... - Page 8 RECOMMENDED AIR SUPPLY CONNECTION...
- Page 9 ASSEMBLY Connect a suitable hose to the Drill using a ¼” hose adapter, (A whip hose with Quick Fit coupling is available from your CLARKE dealer).then connect the other end to the airline. NOTE: ensure the airline is turned off.
-
Page 10: Inserting The Drill Bit
OPERATING INSTRUCTIONS INSERTING THE DRILL BIT Drill bit To insert a drill bit, proceed as follows. Open the chuck jaws by inserting the chuck key in one of the holes in the chuck and turning it as shown. Chuck Make sure that the head of the chuck key is jaws located on the cog barrel of the chuck. - Page 11 OPERATING INSTRUCTIONS WARNING! WAIT UNTIL THE CHUCK HAS STOPPED ROTATING BEFORE OPERATING THE DIRECTION CONTROL SWITCH. USING THE DIRECTIONAL CONTROL SWITCH The direction control switch should be used as follows. For normal drilling into wood, metal and masonry, the drill should be operated in the forward (F) direction.
-
Page 12: Disconnecting The Air Supply
OPERATING INSTRUCTIONS OPERATING THE TRIGGER SWITCH To operate the trigger switch, proceed as follows. Squeeze the trigger switch to start the drill. Wait until the air drill is running at its maximum speed before applying it carefully to the workpiece. Release the trigger switch to stop the air drill. -
Page 13: Maintenance
Check and clean the air inlet gauze filter if necessary. Pour a few drops of CLARKE Air Line Oil, into the air inlet. This should be carried out regardless of whether or not an air line lubricator is used. If an Air line lubricator is not used, this procedure should be repeated after every two to three hours of use. -
Page 14: Parts Diagram
PARTS DIAGRAM... -
Page 15: Parts List
PARTS LIST Part No. Description KL147737 1/2'’ Chuck / Keyless Chuck KL147737A Chuck Key KL157702 Clamp Nut KL106016 Set Screw KL6201Z00A Ball Bearing KL103328A Washer KL157706 Spacer KL147841 Screw KL157708 Planet Carrier KL157709 Planet Gear KL157710 Internal Gear KL157711 Spacer KL6200ZZ0A Ball Bearing KL187725...
