IS-420
Getting to know your mailing system
Screen main areas
D1
D2
D3
D4
D1 Rate and services (to change: K1)
D2 Date printed (to change: K4)
D3 Weighing type (to change: K6)
D4 Imprint position offset
D5 Postage and weight
D6 Job memory (can contain rate, stamp settings
and account)
D7 Current account
Shortcut keys
K1
K7
K2
K5
K3
K8
K6
K4
K9
K1 Rates and services selection
K2 Memorized jobs (rate, stamp settings, account)
K3 Credit management
K4 Type of imprint and Imprint settings
K5 Label printing
K6 Weighing modes
K7 Sleep / wake (amber / green)
K8 Stops printing
K9 Starts printing
Applying postage
To reset previous settings...
1
Press Clear or Wake
If needed, press to get back to the
home screen.
To get back to default rate settings,
press on the keyboard.
D5
If the system is asleep, press
wake it up with default settings.
D6
D7
Changing the ink cartridge
1
On the new ink cartridge,
remove the protective
strips from the printing
heads.
2
Raise base cover and
follow instructions printed
on sticker inside.
2a
To weigh your mail...
Put your mail on the scale
1
Check that the D3 icon is
2
Otherwise, press
option Standard weighing.
2b
or
to
Enter the weight manually
1
Press and then select the option
Manual weight entry.
2
Enter the weight and press OK.
4 When the postage is displayed...
Print the stamp
If you want to print on a label, see the alterna-
tive sequence below.
1
Press to start the motors of your mail-
ing system.
2
Insert the mail piece in
the mail path, the
imprint printing
position on the upper
right side.
To print on labels
1
Insert labels into the
dispenser until a click,
printing side facing
the right.
2
Press
labels to print and then press
If jamming occurs...
1
Press on the control
panel to stop the motor.
2
Under the base, lift up
the release handle and,
using your other hand,
remove stuck envelope
or labels.
For more specific information about your
mailing system, see the User Guide.
For your installation Pin Code please visit
www.quadient.co.uk
.
Consumables,
and then select the
contact Quadient Supplies: 0845 880 0002
3
Current rate and select-
ed
displayed in this zone of
the screen.
To change the rate and/or add services:
1
Press
The rate selection
screen is displayed.
2
Use the keypad to select an available Class
and/or Services, or select key 8 for the
wizard.
3
Press OK to validate your selection and
return to the home screen.
to enter the number of
.
Adding credit
Press
onscreen.
Note: to complete this operation successfully, your postal
services account must have a positive credit balance of
the corresponding amount.
When the weight is displayed...
Choose rate and services
ser vices are
.
, type 2 and follow the instructions
