HDMI KVM Extender Set
with USB 2.0 Extension
EXP-EX-80-KVM
WyreStorm recommends reading through this document in its entirety to become familiar with the product's features prior to starting the
installation process.
IMPORTANT! Installation Requirements
• Visit the product page to download the latest firmware, document version,
additional documentation, and configuration tools.
• Read through the
Wiring and Connections
guidelines before creating or choosing premade cables.
Basic Wiring Diagram
12V DC
Power Supply
Copyright © 2020 WyreStorm Technologies | wyrestorm.com
EXP-EX-80-KVM Quickstart Guide | 200330
section for important wiring
Personal Computer
KEY
HDMI
USB
EXP-EX-80-KVM Transmitter (TX)
In the Box
1x EXP-EX-80-KVM Transmitter
1x EXP-EX-80-KVM Receiver
1x 12V DC 2A Power Supply (US/UK/EU/AU)
1x USB Type B to Type A Cable
4x Mounting Brackets
HDMI Monitor/Display
HDMI
HDMI
Cat5e/6/6a/7
USB
Power
Cat5e/6/6a/7
UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)
1 of 4
Quickstart Guide
Keyboard and Mouse
USB
EXP-EX-80-KVM Receiver (RX)
support@wyrestorm.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Wyrestorm EXP-EX-80-KVM
Summary of Contents for Wyrestorm EXP-EX-80-KVM
- Page 1 HDMI KVM Extender Set with USB 2.0 Extension Quickstart Guide EXP-EX-80-KVM WyreStorm recommends reading through this document in its entirety to become familiar with the product’s features prior to starting the installation process. In the Box IMPORTANT! Installation Requirements 1x EXP-EX-80-KVM Transmitter •...
- Page 2 Connection of USB Host device USB Device Connection of USB devices such as keyboards and mice. Copyright © 2020 WyreStorm Technologies | wyrestorm.com UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973) 2 of 4 EXP-EX-80-KVM Quickstart Guide | 200330...
- Page 3 Wiring and Connections WyreStorm recommends that all wiring for the installation is run and terminated prior to making connections to the switcher. Read through this section in it’s entirety before running or terminating the wires to ensure proper operation and to avoid damaging equipment.
- Page 4 Safety and Emission CE | FCC | RoHS | RCM | EAC Note: WyreStorm reserves the right to change product specification, appearance or dimensions of this product at any time without prior notice. Warranty Information WyreStorm Technologies LLC warrants that its products to be free from defects in material and workmanship under normal use for a period of two (2) years from the date of purchase.
