18Gbps HDMI-over-UTP Extender
with IR and PoC
EXP-EX-35-G2
WyreStorm recommends reading through this document in its entirety to become familiar with the product's features prior to starting the
installation process.
IMPORTANT! Installation Requirements
• Visit the product page to download the latest firmware, document version,
additional documentation, and configuration tools.
• Read through the
Wiring and Connections
guidelines before creating or choosing premade cables.
Basic Wiring Diagram
12V DC
Power Supply
Copyright © 2020 WyreStorm Technologies | wyrestorm.com
EXP-EX-35-H2 Quickstart Guide | 200330
section for important wiring
4K/UHD HDMI Source
HDMI
IR
EXP-EX-35-G2 Transmitter (TX)
In the Box
1x EXP-EX-35-G2 Transmitter
1x EXP-EX-35-G2 Receiver
1x IR Emitter
1x IR Receiver
1x 12V DC 1A Power Supply (US/UK/EU/AU)
4x Mounting Brackets
4K/UHD HDMI Display
KEY
HDMI
Cat6/7
IR
Power
Cat5e/6/6a/7
UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)
1 of 4
Quickstart Guide
HDMI
IR
EXP-EX-35-G2 Receiver (RX)
