American Dynamics ADTTE Datasheet

The ADTTE Touch Tracker matrix switcher keyboard is
compact, ergonomically-designed and compatible with
MegaPower matrix switcher/controller systems. This keyboard
provides easy access to a complete selection of video
switching options – from basic camera and monitor selection to
the most advanced automatic control.
The new controlstick provides pan/tilt functions of the currently
selected dome. Buttons for lens zoom, focus, and iris functions
are located near the controlstick enabling one-handed
operation. The keypad features buttons that allow you to assign
any camera to any monitor and access special features such
as salvos, tours, and alarms.
ADTTe Touch Tracker
Matrix Switcher Keyboard
Features That Make a Difference:
Attractive ergonomic design
Camera, monitor and satellite site selection
New controlstick provides pan/tilt functions
Lens control (zoom, focus, iris)
Supports dome "flip" feature
Preset, pattern auxillary control
Tour, salvo and alarm control
Built-in self-test hardware and software operation
Supports multiple languages (English, French, Spanish, German,
Italian and Portuguese)
Backlit LCD display
The LCD displays the selected camera, monitor, and site.
It also enables you to see the numbers as you enter them and
it displays system prompts and messages.
D A T A s h e e T
