American Dynamics ADTTE Installation Instructions

PARTS REQUIRED
AD T T Installation Kit:
OUCH RACKER
0351-0474-04
Description
Modular cable assy
Screw, M2.9x9.5
Anchor, 4-8x.750
Screw, #8x1
Conn, 1x5pos
Lug, 22-16AWG
Cable, 3-cond, 18AWG
Interconnect box
Hood, D-Sub, 9pos, cable
Conn, D-Sub, plug, hsg, 9pos

Installation Procedures

For connections less than or equal to 4m
(14 ft)
Refer to the diagram on page 2.
1. Mount each external interconnect module
(EIM) on a wall or other surface within 3m
(10 ft) of the controller.
2. Connect the power transformer to J3 on
each EIM. Refer to the J3 table on page 2.
3. Wire the DB9 connector to the data cable.
Refer to the DB9 table on page 2.
4. Connect the data cable from J1 on the
T T EIM to one of the RS232
OUCH RACKER
ports at the rear panel of the AD Switch.
Refer to the RJ45 table on page 2.
5. Connect the modular cable from J2 on EIM
to the T T
OUCH RACKER
6. Plug each power transformer into a
grounded, 3 wire receptacle.
NOTE: If the keypad and back lighting do not
illuminate when power is applied, unplug
each power transformer and repeat steps 2
through 6.
When all cables are connected, you must set the T
T for the appropriate communications protocol.
RACKER
If your AD switch does not support keyboard repeat,
enter 200, then press F1 to select Repeat Off. The
AD168 supports this mode.
If your AD switch supports keyboard repeat, enter
201, then press F1 to select Repeat On. The
AD1650, AD2050, AD2052, AD2150, and AD2350
support this mode.
Repeat On is the default setting for the T
8000-1658-02, Rev. C
Qty. Part No.
4.3m 6003-0047-01
1 5899-0004-102
2 2880-0083-01
2 2816-7634-44
1 2109-0254-04
3 2141-0002
5m 6002-0024-01
1 0300-1000-01
1 2125-0007-02
2130-0021-01
Controller.
OUCH
T .
OUCH RACKER
AD T

Installation Instructions

WARNING Shock Hazard!
Disconnect AC Power to the Switch.
CAUTION Static Sensitive
Components!
Follow proper handling procedures
to prevent component failure.
For connections greater than 4m (14 ft)
This installation requires 2 modular cable assemblies
(Part No. 6003-0047-01), 2 HP0047 AD Terminal
Boxes, and 3-wire, 18 AWG shielded cable. Contact
your sales representative for additional parts.
Refer to the diagram on page 3.
1. Mount each external interconnect module
(EIM) on a wall or other surface within 3m
(10 ft) of the controller.
2. Connect the power transformer to J3 on
each EIM. Refer to the J3 table on page 3.
3. Wire the DB9 connector to the data cable.
Refer to the DB9 table on page 3.
4. Referring to the diagram on page 3, connect
the wires as illustrated to the Terminal
boxes. The shield wire connects to 7 on the
Switch Terminal Box only.
5. Connect one modular cable from J2 on EIM
to the T T
OUCH RACKER
6. Connect the data cable from J1 on the
T T EIM to RJ45 on the T
OUCH RACKER
T Terminal Box. Refer to the RJ45
RACKER
table on page 3.
7. Connect remaining modular cable from the
Switch Terminal Box to one of the RS232
ports on the AD Switch.
8. Plug each power transformer into a
grounded, 3 wire receptacle.
NOTE: If the keypad and back lighting do not
illuminate when power is applied, unplug
each transformer and repeat steps 2 through
8.
When all cables are connected, you must set the T
T for the appropriate communications protocol.
RACKER
If your AD switch does not support keyboard repeat,
enter 200, then press F1 to select Repeat Off. The
AD168 supports this mode.
If your AD switch supports keyboard repeat, enter
201, then press F1 to select Repeat On. The
AD1650, AD2050, AD2052, AD2150, and AD2350
support this mode.
Repeat On is the default setting for the T
AD T T
OUCH
T
OUCH RACKER
Controller.
OUCH
OUCH
T
OUCH RACKER
Installation Instructions
RACKER
.
