Before Installing the Intellex
Connector
Alarm
Keyboard
Mouse
USB
Monitor
Call Monitor
(Composite)
TV Out
(Composite)
TV Out (S-Video)
Printer
Serial
SCSI-3
Network
Microphone

Power Supply

Input

Environmental Requirements

Temperature
Humidity
Storage temperature
Caution
Intellex Operating Temperature Range
The specified operating temperature range for the Intellex Ultra is 5
meets all functional specifications in this temperature range, and all of the internal components are within their
manufacturers' specified temperature limits. Extended operation at elevated temperatures reduces the life of
electronic components and reduces overall system reliability. It is recommended that the ambient temperature be
maintained at 15° C to 24° C (59° F to 75° F) to maximize the life of the electronic components. The ambient
temperature is the air temperature in the immediate vicinity of the chassis. For example, if the chassis is mounted in
a rack or lock box, the ambient temperature is the air temperature within the rack or lock box.
6
Connector block with screw terminals.
Standard PS/2-style connector.
Input device with standard PS/2-style connector.
These connectors are used to add RS-232 ports, data
storage devices, USB-Sensornet dome control modules,
and other accessories to the Intellex.
HD15-S. SVGA monitor output for live display.
BNC composite output to optional call monitor display.
Composite video output.
S-Video. Composite video output.
DB25-S. Parallel printer output.
DB9-P. Dome controller (Sensormatic VM16 or American
Dynamics ADTT16) input.
High density 68-pin female connector. For use with
external storage devices.
RJ-45. Category 3 or Category 5 twisted-pair Ethernet
(CAT 3 TPE or CAT 5 TPE) connector.
Compatible with dynamic, condenser, and electret
microphones. Line input is compatible with 1 Vrms line
level audio sources.
100 - 240 VAC, 50-60 Hz, less than 5A
Requires IEC-320-C13 plug
41–95° F (5–35° C)
5–95% RH noncondensing
14° –140° F (10–60° C)
Use
° C to 35° C (41° F to 95° F). The product
Applies to
Intellex:
Ultra, DVMS, LT
All (not supplied)
All
All
All
Ultra, DVMS**, LT**
DVMS, LT
Ultra, DVMS**
All
All
Optional
All
All (optional on IP)
Intellex®
