- Page 1 Lovibond Water Testing ® Tintometer Group ® Photometer-System MD 100 • MD 110 • MD 200 Instruction Manual Page 28–49 www.lovibond.com...
- Page 2 Bevollmächtigte Person im Sinne des Anhangs II Nr. 1. A. Nr. 2, 2006/42/EG für die Zusammenstellung der technischen Unterlagen / Authorized person for compilation of technical documents on behalf of Annex II No. 1. A. No. 2, 2006/42/EC: Name: Corinna Meier c/o Tintometer GmbH, Schleefstr. 8-12, 44287 Dortmund Anschrift / Address: Dortmund 20.9.2016 Ort, Datum / Place and date of issue Rechtsgültige Unterschrift / Authorized signature...
-
Page 3: Table Of Contents
Contents • Important Information ..........29 •... -
Page 4: Important Information
This service only applies to electrical instruments purchased after 13th August 2005. Send your electrical Tintometer instrument for disposal freight prepaid to your supplier. Safety - General instructions The manufacturer's liability and warranty for damage and consequential damates lapses with improper use, failure to follow this operating manual, use of insufficiently qualified specialized personnel or unauthorized changes to the instrument. -
Page 5: General Notes
General notes Guidelines for photometric measurements 1. Vials, caps and stirring rods should be cleaned thoroughly after each analysis to prevent interference. Even minor reagent residues can cause errors in the test result. 2. The outside of the vial must be clean and dry before starting the analysis. Clean the outside of the vials with a towel to remove fingerprints or other marks. -
Page 6: Placing The Seal Ring
General notes Placing the seal cap: Placing the seal ring: Positioning Positioning the vials: the adapter: Correct filling of the vial: Correct handling of the reagents: Powder Packs Liquid reagents Blister-tablets MD1X0/200_1c 12/2020... -
Page 7: Replacement Of Batteries
General notes Replacement of batteries: MD 100 / MD 110 (B) battery compartment cover (E) seal ring (F) instrument (A) screw back (C) notch for IR data transfer (D) batteries MD 200 (B) battery compartment cover (E) seal ring (A) screw (F) instrument back (D) batteries... -
Page 8: Functional Description
Functional description Operation Switch the unit on Selecting a method Mode Scroll Memory (SM) To avoid unnecessary scrolling for the required test method, the instru- ment memorizes the last method used before being switched off. When the instrument is switched on again, the scroll list comes up with the last used test method first. -
Page 9: Otz
Functional description Press [ZERO/TEST] button Zero Test Remove the vial from the sample chamber OTZ (One Time Zero) The One Time Zero is available for all photometer variants whereby the zero adjustment is carried out in a 24-mm round vial with sample water. -
Page 10: Countdown / Reaction Period
Functional description Countdown / reaction period For methods with a reaction time, a countdown function can be swit- ched on during the test for some methods. press and hold Zero press Test release Countdown/reaction time runs, measurement takes place automatically after the time runs out. -
Page 11: Menu Options
Menu options Retrieve menu Device is switched off Mode press and hold press briefly, release release Mode Menu selections press to select a menu point (scroll) Store Date Selection of the following menu points: Time diS recall stored data oder Prt printing stored data Store Date... -
Page 12: Transmitting Stored Data - To Printer Or Pc ® - At The Md 100 And Md 200
Menu options Store Date Prt – Transmitting stored data - to Printer or PC Time - at the MD 100 and MD 200 Attention: To print data, or to transmit to a PC, the optional IRiM (Infrared Interface Module) is required. It can be used in combination with the devices MD 100 and MD 200. -
Page 13: Transmitting Stored Data Bluetooth ® - At The Md 110
(Low Energy). Data is transmitted from the photometer as a .csv file. Details on how information is transmitted from the photometer can be found on www.lovibond.com. To receive the data, there are several options on offer from the Tintometer Group. ®... -
Page 14: Setting Date And Time
Menu options The transfer can be cancelled at any time by pressing the [On/Off] key. The instrument switches off. Store Date Setting date and time (24-hour-format) Time Retrieve menu (see “Retrieve menu”) 2x press = arrow symbols on Time & Date confirm Mode Increase value... -
Page 15: User Calibration
User calibration Display of current calibration setting Retrieve menu (see “Retrieve menu”) 3x = arrow symbols on Cal or Cal on the display Mode confirm Display alternates between: CAL/„Methode“. METHOD METHOD Note: User calibration Factory calibration Store Date User calibration Time Retrieve menu (see “Retrieve menu”) 3x = arrow symbols on Cal or Cal on the display... - Page 16 User calibration Place the vial in the sample chamber. Pay attention to the positioning. Sample Zero press Test METHOD METHOD flashes for approx. 8 seconds 0.0.0 The display shows the following in alternating mode: Perform the measurement with a known standard concentration. Zero press Test...
-
Page 17: Calibration Mode For Fluoride
User calibration Calibration Mode for Fluoride Calibration takes place also: 0 mg/l and 1.0 mg/l F standard and a clean vial (see method description, rem.) Fluoride calibration: Retrieve menu (see “Retrieve menu”) 3x = arrow symbols on Cal or Cal on the display Mode confirm After confirming the selection with the [MODE] key the instrument will... -
Page 18: Factory Calibration Reset
User calibration The display shows: By pressing the [ON/OFF] key, the new correction factor is calculated and stored in the user calibration software. Confirmation of calibration (3 seconds). Factory calibration reset Resetting the user calibration to the original factory calibration will reset all methods and ranges. -
Page 19: Checking The Device
Checking the device Use a reference standard kit (see page 41 Reference standards- Kits for MD 100, MD 110 and MD 200) Use the photometer as described in the instructions for the method which correspond with normally used reagent system (tablet, liquid reagent or powder pack). -
Page 20: Use Of A Verification Standard Kit
Checking the device If the result falls outside of the tolerance, the shelf life of the standard must be checked as well as whether the photometer is in the factory calibration. If this applies, we recommend returning the device to the manufacturer or distributor. - Page 21 Checking the device The following appears briefly on the display: AbS followed by the wavelength to be measured (e.g. A530 for A530 A530 530 nm). For devices with several LEDs, select the desired wavelength by pressing Mode the [Mode] button several times as needed (scroll). Zero Position the vial marked “Zero”...
-
Page 22: Technical Data
Technical Data Technical Data MD 100, MD 110, MD 200 Instrument automatic wavelength selection, direct reading colorimeter Light source LEDs, interference filters (IF) and photosensor in transparent cell chamber Wavelength specifications of the interference filter depen- dent on the device variant, max. 3 wave lengths Possible built-in wavelengths: 430 nm = 5 nm... - Page 23 Technical Data Technical Data MD 100 Batteries 4 micro batteries (AAA/LR 03) Operating time 17hr operating time or 5000 test measurements in continuous mode when display backlight is off Storage internal ring memory for 16 data sets Serial Interface IR interface for data transfer Dimensions 155 x 75 x 35 mm (LxWxH) Weight...
-
Page 24: Operating Messages
Battery capacity was too low during measurement. Change battery. E 22 These error messages relate to a missing or faulty factory or user E 70 calibration. Please contact our Technical Support at techsupport@ E 71 tintometer.de. E 72 MD1X0/200_1c 12/2020... - Page 25 Spain www.lovibond.com www.lovibond.com Germany Tintometer China Tintometer South East Asia Tintometer Brazil Tintometer Indien Pvt. Ltd. Room 1001, China Life Tower Unit B-3-12, BBT One Boulevard, Caixa Postal: 271 Door No: 7-2-C-14, 2 & 4 Floor...
