4.1.2

SOPASair (web server)

4.1.3

Saving parameter set

8024534 / 16UW / 2020-02-26
Subject to change without notice
The device is set up and parameterized using the SOPASair operating software.
You can call up the operating software with a web browser (recommendation: Google
Chrome). No installation of software is required. The device must be supplied with
voltage and connected to the computer via the Ethernet interface in order to use
the SOPASair web server.
Starting SOPASair
1. Start web browser (recommendation: Google Chrome).
2. Enter the device IP address into the address line.
 The SOPASair user interface appears.
The currently valid parameter set can be backed up using SICK AppManager.
The complete environment of the device is then available if support is necessary.
Saving on the computer (backup)
1. In the SICK AppManager, in the
 The Backup Apps and Data window opens.
Figure 4: "Backup Apps and data" window
2. Fill out the Name, Version and Filename fields.
3. Select the path for data backup.
4. Select all available options.
5. To run the backup, click on the Backup button in the Backup Apps and Data
window.
Saving on a microSD memory card (cloning)
IMPORTANT
Risk of damage to the memory card!
▸
To avoid damaging the memory card, make sure the device is
de-energized when you insert or remove the card. For this purpose,
disconnect the device from the supply voltage accordingly.
INSTALLATION
Device window, click on the
Operating Instructions | InspectorP Rack Fine Positioning
4
Backup button.
