Electrolux EDE1072PDW User Manual

Hide thumbs

Advertisement

Quick Links

EDE1072PDW
EN
Tumble Dryer
User Manual

Advertisement

loading

  Also See for Electrolux EDE1072PDW

  Summary of Contents for Electrolux EDE1072PDW

  • Page 1 EDE1072PDW Tumble Dryer User Manual...
  • Page 2: Table Of Contents

    15. INSTALLATION....................17 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.
  • Page 3: Safety Information

    ENGLISH SAFETY INFORMATION Before beginning the installation and use of this appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.
  • Page 4 If the tumble dryer is put on top of a washing machine, • use the stacking kit. The stacking kit, available from your authorized vendor, can be used only with the appliance specified in the instructions supplied with the accessory. Read it carefully before installation (refer to the Installation leaflet).
  • Page 5: Safety Instructions

    ENGLISH Wipe away lint or packaging debris that has • accumulated around the appliance. Do not run the appliance without a filter. Clean the lint • filter before or after each use. Do not dry unwashed items in the tumble dryer. •...
  • Page 6 2.2 Electrical connection • Do not drink or prepare food with the condensed water/distilled water. It can WARNING! cause health problems to people and Risk of fire and electric pets. shock. • Do not sit or stand on the open door of the appliance.
  • Page 7: Product Description

    ENGLISH 3. PRODUCT DESCRIPTION Control panel Plastic ring Appliance door (reversible) Side/rear ventilation opening Primary Filter Rating plate Adjustable feet 4. ACCESSORIES 4.1 Stacking kit Available from your authorized dealer. Stacking kit can be used only with the washing machines specified in the leaflet.
  • Page 8: Control Panel

    4.2 Pedestal with the drawer which helps to easy load and remove the laundry. The drawer can be use for laundry storage e.g. : towels, cleaning products and more. Read carefully the instructions supplied with the accessory. 4.3 Vent kit Universal kit for vented dryers where an outdoor outlet is not possible.
  • Page 9: Programme Table

    ENGLISH 6. PROGRAMME TABLE Load (max.) Programmes Type of load Fabric mark Cotton Drying level: extra dry. Extra Dry 7kg/ Drying level: strong dry. Strong Dry 7kg/ Cupboard Drying level: cupboard dry. 7kg/ 2)3) Drying level: textiles which are still to be Damp 7kg/ ironed.
  • Page 10: Options

    Load (max.) Programmes Type of load Fabric mark Refreshing textiles that were in storage. Cooling 1) The maximum weight refers to dry items. 2) The Cotton Cupboard Dry ECO programme is the “Standard cotton programme” ac‐ cording to Commission Regulation EU No. 392/2012. It is suitable for drying normal wet cot‐...
  • Page 11: Settings

    ENGLISH Programmes Delicate Anticrease Buzzer ■ ■ ■ Cupboard Dry ■ ■ ■ Iron Dry ■ ■ ■ Special ■ ■ ■ ■ ■ ■ Easy Iron ■ ■ ■ Jeans ■ ■ Wool Care ■ Cooling 1) Together with the programme you can set 1 or more options. To activate or deactivate them, press the related touch button.
  • Page 12: Before First Use

    9. BEFORE FIRST USE Before you use the appliance for the first • Start a 1 hour programme with moist time: laundry. • Clean the tumble dryer drum with a moist cloth. 10. DAILY USE 10.1 Start a programme without •...
  • Page 13: Hints And Tips

    ENGLISH • Drying (Drying) : This light indicates is in the anticreasing phase and at the that the appliance is in the drying end of the programme. phase. • Filter : This light illuminates at the • Cooling (Cooling): This light indicates end of the programme to remind you that the appliance is in the cooling that the filters must be cleaned.
  • Page 14 2. Pull the filter. 6. Close the filter. 7. Remove fluff from the filter socket. For this a vacuum cleaner can be used. 8. Put the filter inside the filter socket . 12.2 Cleaning the drum WARNING! Disconnect the appliance before you clean it.
  • Page 15: Troubleshooting

    ENGLISH 13. TROUBLESHOOTING Problem Possible solution You cannot activate the appliance. Make sure that the mains plug is connec‐ ted to the mains socket. Check fuse in fuse box (domestic installa‐ tion). The programme does not start. Press Start/Pause. Make sure that the appliance door is closed.
  • Page 16: Technical Data

    14. TECHNICAL DATA Height x Width x Depth 850 x 600 x 600 mm (maximal 630 mm) Max. depth with the appliance door open 1090 mm Max. width with the appliance door open 950 mm Adjustable height 850 mm (+ 15 mm - feet regulation)
  • Page 17: Installation

    ENGLISH 14.1 Consumption data Energy Drying consump‐ Programme Spun at / residual humidity time tion Cotton Eco 7 kg Cupboard Dry 1400 rpm / 50% 110 min. 3,70 kWh 1000 rpm / 60% 125 min. 4,25 kWh Iron Dry 1400 rpm / 50% 85 min.
  • Page 18 “exhaust” at least beyond the kitchen units; preferable outside the kitchen. In order to prevent the appliance from overheating, it is important that the steam exhaust is unobstructed. Thus, if a...
  • Page 19 ENGLISH Installation There are 3 vent outlets: on the left, right side and at the rear. 1. Pull the ring nut A from the vent outlet at the rear. 3. The not used vents must be sealed with supplied covers. 15.3 Door Reversal To make it easier to load or unload the laundry, the door can be reversed.
  • Page 20 www.electrolux.com/shop...
