Terex Genie S-60 XC Service And Repair Manual page 153

April 2021
ID Component ID Name
160 LF Steer (L 11 Shorted
or R) Coil to
supply
voltage
161 RF Steer (L 11 Shorted
or R) Coil to
supply
voltage
185 ESTOP 11 Shorted
Source to
supply
voltage
186 ESTOP 11 Shorted
Return to
supply
voltage
187 TCON Bank 13 Not
power detected
188 PCON Bank 13 Not
power detected
Part No. 1288652GT
Cause Effect
TCON detected Steer Left function
that C37STL circuit will not operate.
is shorted to 12 V
or GND.
TCON detected Steer Right function
that C36STR will not operate.
circuit is shorted to
12 V or GND.
TCON detected ESTOP circuit
that ESTOP 1 is at cannot complete,
12 V but ESTOP preventing machine
3 is at 0 V. functions.
Mismatched ESTOP circuit
signals detected cannot complete,
on ESTOP Return preventing machine
circuits. Either: functions.
* PCON ESTOP
2 and ESTOP 4 do
not match, or
* TCON ESTOP
2 and ESTOP 4 do
not match.
Power plug not TCON outputs will
connected or not turn on.
loose.
Internal TCON
component failure.
Power plug not PCON outputs will
connected or not turn on.
loose.
Internal TCON
component failure.
S ® -60/65 XC ™ • S ® -60/65 HF • S
Control System Fault Codes
Solution
* With a voltmeter, measure Y3.
Proper resistance should be between
5 - 60 ohms. Replace Y3 if resistance
is outside of those values.
* Verify wiring for C37STL (BL/BK,
TCON J4-11) and check for open or
short circuits.
* With a voltmeter, measure Y4.
Proper resistance should be between
5 - 60 ohms. Replace Y4 if resistance
is outside of those values.
* Verify wiring for C36STR (BL,
TCON J4-12) and check for open or
short circuits.
* Using a voltmeter and with the
system turned OFF, check the
resistance between TCON J5 pins
9 and 10. Replace TCON if
resistance is more than 5 ohms.
* Check P79PWR (BK, TCON J5-9)
and P23PWR (RD, TCON J5-10) for
open or short circuits.
* Inspect PCON J15 pins 11 and
12 for open or short circuits. Using a
voltmeter, set to diode test mode and
make sure the diode tests ok with the
anode at pin 12 and cathode at pin
11. If test fails, replace the PCON.
* Inspect TCON J5 pins 11 and 12 for
open or short circuits. Using a
voltmeter, set to diode test mode and
make sure the diode tests ok with the
anode at pin 12 and cathode at pin
11. If test fails, replace the PCON.
* Check P23RET (BK) for shorts to
ground or power.
* Check J1, Bank Power, on TCON is
making a good connection.
* Verify pin 1 is grounded
* Verify pins 2, 3, 4 are 12V
* Replace TCON
* Check J11, Bank Power, on PCON
is making a good connection.
* Verify pin 1 is grounded
* Verify pins 3, 4 are 12V
* Replace PCON
® -60/65 TraX ™
Service and Repair Manual
141
