- Page 1 USER’S MANUAL FAN FOR SOLID FUEL BOILER Series V119EN-01.indd 1 02.09.2015 7:55:09...
-
Page 2: Table Of Contents
CONTENTS Safety requirements Purpose Delivery set Designation key Technical data Unit design and operating principle Mounting and set-up Connection to power mains Technical maintenance Transportation and storage regulations Manufacturer's warranty Acceptance certificate Seller information Installation certificate Warranty card V119EN-01.indd 2 02.09.2015 7:55:09... -
Page 3: Safety Requirements
This user’s manual consisting of the technical details, operating instructions and technical specification covers the installation and mounting of the VDK fan for solid fuel boiler (hereinafter referred to as «the fan» or «the unit» as mentioned in the «Safety requirements» and «Manufacturer’s warranty» sections as well as in warnings and information blocks). - Page 4 • • Do not use damaged equipment or Unpack the unit with care. cables when connecting the unit to power mains. • • Do not touch the unit controls with Do not wash the unit with water. • wet hands. Protect the electric parts of the •...
-
Page 5: Purpose
PURPOSE The fan is designed for pumping the air in the combustion chamber of the solid fuel boiler and for optimizing fuel combustion. The fan facilitates the controlled process of fuel burning and combustion, boiler efficiency improving and combustion process automation. May be used for ventilation of premises and processing equipment. -
Page 6: Technical Data
TECHNICAL DATA The fan is designed for indoor application. The unit design is constantly being improved, so some models can slightly differ from those ones described in this manual. Ød Dimensions [mm] Model Ød VDK 120 Model Technical data VDK 120 Voltage [V] 1~ 230... -
Page 7: Unit Design And Operating Principle
DESIGN AND OPERATING PRINCIPLE The motor with an external rotor and an impeller with forward-curved blades is attached to the fan casing. Casing material is aluminium alloy or painted cold rolled sheet steel. The fan inlet is protected by a grid. -
Page 8: Connection To Power Mains
CONNECTION TO POWER MAINS Connect the fan to single-phase AC 230 V / 50(60) Hz power mains by using the 3x0,75 mm pre-wired power cord with the IEC power connector compliant with the EN 60320 C13 10 A / 250 V standard. The connection is made to the control unit of the boiler. - Page 9 The warranty repair does not include: • routine technical maintenance • unit installation / dismantling • unit setup To benefit from warranty repair the user must provide the unit, the user’s manual with the purchase date stamp and the payment document certifying the purchase. The unit model must comply with the one stated in the user’s manual.
-
Page 10: Acceptance Certificate
ACCEPTANCE CERTIFICATE Unit Type Fan for solid fuel boiler Model VDK __________________ Serial Number Manufacture Date is compliant with the technical specifications and is hereby declared ready for service. We hereby declare that the product complies with the essential protection requirements of Electromagnetic Council Directive2004/108/ EC, 89/336/EEC and Low Voltage Directive 2006/95/EC, 73/23/EEC and CE-marking Directive 93/68/EEC on the approximation of the laws of the Member States relating to electromagnetic compatibility. -
Page 11: Installation Certificate
MOUNTING CERTIFICATE The unit has been connected to power mains pursuant to the requirements stated in the present user’s manual. Company Name Address Phone Number Installation Technician's Full Name Installation Installation Date: Signature: Company Stamp The unit has been installed in accordance with the provisions of all the applicable local and national construction, electrical and technical codes and standards. - Page 12 V119EN-01 V119EN-01.indd 12 02.09.2015 7:55:10...
