- Page 1 Installation Guide for the ConferenceSHOT 10 Enterprise-Class PTZ Conferencing Camera Document 411-0002-31 Rev F November 2020...
-
Page 2: Table Of Contents
Contents Overview What's in this Guide Features Unpacking the Camera A Quick Look at the Camera Front of the Camera Back of the Camera Installation Don’t Void Your Warranty! Before You Install the Camera Cabling Notes Pre-Installation Functional Check Status Indicator Light Camera Behavior Settings About Ceiling-Mounted Cameras RS-232 Serial Communication Settings... -
Page 3: Overview
Instructions for installing the camera mount Information on connecting and mounting the camera Camera power-on Complete product information is available in the Complete Manual for the ConferenceSHOT 10 Enterprise-Class PTZ Conferencing Camera. Note If you are responsible for configuring the equipment after installing it, please use the Complete Manual instead of this guide. -
Page 4: Unpacking The Camera
Installation Guide for the ConferenceSHOT 10 Enterprise-Class PTZ Conferencing Camera Unpacking the Camera Make sure you received all the items you expected. Caution: Use the power supply shipped with or recommended for the camera. Using a different power supply may create an unsafe operating condition or damage the camera, and will void the warranty. -
Page 5: A Quick Look At The Camera
This section covers the physical features of the camera. Front of the Camera Camera and zoom lens – The ConferenceSHOT 10 camera features a 10X optical zoom lens (11X in Super-Wide mode). IR sensor – Receives signals from the IR remote. Make sure there's nothing directly in front of the camera base, and point the remote at the camera. -
Page 6: Back Of The Camera
Installation Guide for the ConferenceSHOT 10 Enterprise-Class PTZ Conferencing Camera Back of the Camera 12 VDC, 3.0 A – EIAJ-04 jack. Connect only the power supply shipped with the camera or approved replacement 12 VDC, 3A power supply. USB 3.0 – USB Type B connector. Connect to a computer for use with soft conferencing applications. -
Page 7: Installation
Installation Guide for the ConferenceSHOT 10 Enterprise-Class PTZ Conferencing Camera Installation This section covers: Selecting the location for the camera Verifying that the camera is ready to install Installing the mount RS-232 cable pin-out and communication settings Connection diagrams Mounting the camera Don’t Void Your Warranty! -
Page 8: Cabling Notes
Cabling Notes Caution When building cables for Vaddio products, do not use pass-through RJ-45 connectors. If they are crimped incorrectly, they can cause intermittent connections and degrade signal quality. Incorrectly crimped pass-through connectors can also damage the connectors on the product, which will void your warranty. -
Page 9: Pre-Installation Functional Check
Installation Guide for the ConferenceSHOT 10 Enterprise-Class PTZ Conferencing Camera Pre-Installation Functional Check If you're installing the camera where it's hard to reach, you may want to verify functionality before you install it. 1. Connect the camera in its minimum functional configuration. -
Page 10: Status Indicator Light
Installation Guide for the ConferenceSHOT 10 Enterprise-Class PTZ Conferencing Camera Status Indicator Light The light in the camera's base indicates its current state. Blue – Camera is active Purple – Standby mode or booting Yellow – Firmware update is in progress Blinking blue –... -
Page 11: About Ceiling-Mounted Cameras
Installation Guide for the ConferenceSHOT 10 Enterprise-Class PTZ Conferencing Camera About Ceiling-Mounted Cameras If you use an inverted mount, set the camera's Image Flip mode ON for inverted operation. This orients the video image correctly and sets the tilt motors to respond appropriately to tilt up and down commands from the remote, web interface, and connected control devices. -
Page 12: Installing The Wall Mount
Here is an example of how the camera might be set up in a medium-size conference room. In this setup, a PC uses a unified communications conferencing application to manage the camera and an EasyUSB Mixer/Amp with attached microphones and speakers. Note ConferenceSHOT 10 camera output is USB 3.0; EasyUSB Mixer/Amp is USB 2.0. -
Page 13: Installing The Camera
Installation Guide for the ConferenceSHOT 10 Enterprise-Class PTZ Conferencing Camera Installing the Camera Caution Before you start, be sure you can identify all cables correctly. Connecting a cable to the wrong port can result in equipment damage. Caution Check your cables. Connecting a cable to the wrong port or using the wrong pin-out can result in equipment damage and will void the warranty. -
Page 14: Powering Up The Camera
Installation Guide for the ConferenceSHOT 10 Enterprise-Class PTZ Conferencing Camera Powering Up the Camera Connect camera power. The camera will initialize and move. This will take a few seconds. When an image is available, the camera is ready to accept control information. -
Page 15: Next Steps
Installation Guide for the ConferenceSHOT 10 Enterprise-Class PTZ Conferencing Camera Next Steps The camera is now ready to configure and use. This information is available in the Complete Manual for the ConferenceSHOT 10 Enterprise-Class PTZ Conferencing Camera. Operation, Storage, and Care For smears or smudges on the product, wipe with a clean, soft cloth. -
Page 16: Compliance And Conformity Statements
Installation Guide for the ConferenceSHOT 10 Enterprise-Class PTZ Conferencing Camera Compliance and Conformity Statements Compliance testing was performed to the following regulations: FCC Part 15 (15.107, 15.109), Subpart B Class A ICES-003, Issue 54: 2012 Class A EMC Directive 2014/30/EU... -
Page 17: European Compliance
Installation Guide for the ConferenceSHOT 10 Enterprise-Class PTZ Conferencing Camera European Compliance This product has been evaluated for Electromagnetic Compatibility under the EMC Directive for Emissions and Immunity and meets the requirements for a Class A digital device. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. ... -
Page 18: Photo Credits
Installation Guide for the ConferenceSHOT 10 Enterprise-Class PTZ Conferencing Camera Photo Credits This guide may include some or all of these photos. European Space Agency (ESA) astronaut Samantha Cristoforetti, a Flight Engineer with Expedition 42, photographs the Earth through a window in the Cupola on the International Space Station By NASA - https://blogs.nasa.gov/ISS_Science_Blog/2015/03/06/women-in-space-part-two-whats-... -
Page 19: Index
Index operating environment 5, 13 packing list 2 anatomy of the camera 3-4 part numbers 2 pin-out, RS-232 connector 9 precautions 2, 5 cable connectors 4, 6 for operating the system 5 camera mount 5, 10-11 product capabilities 1 camera placement 5 capabilities 1 ceiling-mounted cameras 9 requirements 5... - Page 20 ©2020 Legrand AV Inc. Vaddio is a registered trademark of Legrand AV Inc. All other brand names or marks are used for identification purposes and are trademarks of their respective owners. All patents are protected under existing designations. Other patents pending.
