- Page 1 Installation Guide for ClearSHOT 10 USB Enterprise-Class PTZ Conferencing Cameras Document 342-1119 Rev. B, November 2015...
-
Page 2: Table Of Contents
Contents What's in this Guide Overview Features Unpacking the Camera Back of the Camera Switch Settings Installation Before You Install the Camera Don’t Void Your Warranty! Cabling Notes Installing the Wall Mount About Ceiling-Mounted Cameras Installing the Camera Connecting the Camera Powering Up the Camera Next Steps Operation, Storage, and Care... -
Page 3: What's In This Guide
Unpacking the camera Tips for a successful installation Instructions for installing the camera mount Information on connecting and mounting the camera Camera power-on Complete product information is available in the Integrator's Complete Guide to ClearSHOT 10 USB Enterprise-Class PTZ Conferencing Cameras. -
Page 4: Overview
Installation Guide for ClearSHOT 10 USB Enterprise-Class PTZ Conferencing Cameras Overview This guide covers the ClearSHOT 10 USB enterprise- class PTZ conferencing cameras: ClearSHOT 10 USB camera (silver), North America – part number 999-9990-000 ClearSHOT 10 USB camera (silver), international –... -
Page 5: Unpacking The Camera
Installation Guide for ClearSHOT 10 USB Enterprise-Class PTZ Conferencing Cameras Unpacking the Camera Make sure you received all the items you expected. Here are the packing lists for the ClearSHOT 10 USB cameras. Caution: Use the power supply shipped with the camera. Using a different power supply may create an unsafe operating condition or damage the camera, and will void the warranty. - Page 6 Installation Guide for ClearSHOT 10 USB Enterprise-Class PTZ Conferencing Cameras For use outside North America: ClearSHOT 10 USB camera, silver/black, part number 999-9990-001 ClearSHOT 10 USB camera, white, part number 999-9990-001W The box should contain one of each item listed here:...
-
Page 7: Back Of The Camera
Installation Guide for ClearSHOT 10 USB Enterprise-Class PTZ Conferencing Cameras Back of the Camera From left to right: 12 VDC, 3.0 Amp power connector – Connect only the power supply shipped with the camera USB 3.0 video device connector for streaming uncompressed UVC standard video... -
Page 8: Installation
Installation Guide for ClearSHOT 10 USB Enterprise-Class PTZ Conferencing Cameras Installation This section covers siting the camera, installing the mount, and installing the camera. Before You Install the Camera All ClearSHOT cameras include a wall mount. Choose a camera mounting location that will optimize camera performance. Consider camera viewing angles, lighting conditions, line-of-sight obstructions, and in-wall obstructions where the camera is to be mounted. ... -
Page 9: Installing The Wall Mount
Installation Guide for ClearSHOT 10 USB Enterprise-Class PTZ Conferencing Cameras Installing the Wall Mount You can install the camera wall mount to a 2-gang wall box or directly to the drywall. If you mount it to drywall, use the wall anchors provided with the wall mount. -
Page 10: Installing The Camera
Installation Guide for ClearSHOT 10 USB Enterprise-Class PTZ Conferencing Cameras Installing the Camera Caution Before you start, be sure you can identify all cables correctly. Connecting a cable to the wrong port can result in equipment damage. 1. Route the cables through the mount, and install the mount on the wall or attach it to the wall box. Leave the screws loose enough to adjust the position of the mount. -
Page 11: Connecting The Camera
PC uses a unified communications conferencing application to manage the camera and an EasyUSB Mixer/Amp with attached microphones and speakers. Note ClearSHOT 10 USB camera output is USB 3.0; EasyUSB Mixer/Amp is USB 2.0. Powering Up the Camera Connect camera power. -
Page 12: Next Steps
The camera is now ready to configure and use. This information is available in the Configuration and Administration Guide for ClearSHOT 10 USB Enterprise-Class PTZ Conferencing Cameras. It is also included in the Integrator's Complete Guide to ClearSHOT 10 USB Enterprise-Class PTZ Conferencing Cameras. -
Page 13: Compliance Statements And Declarations Of Conformity
Installation Guide for ClearSHOT 10 USB Enterprise-Class PTZ Conferencing Cameras Compliance Statements and Declarations of Conformity Compliance testing was performed to the following regulations: FCC Part 15 (15.107, 15.109), Subpart B Class A ICES-003, Issue 54: 2012 Class A EMC Directive 2004/108/EC... -
Page 14: European Compliance
Installation Guide for ClearSHOT 10 USB Enterprise-Class PTZ Conferencing Cameras European Compliance This product has been evaluated for electromagnetic compatibility under the EMC Directive for Emissions and Immunity and meets the requirements for a Class A digital device. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. ... -
Page 15: Warranty Information
Vaddio receives notice of such defects during the warranty. Vaddio, at its option, will repair or replace products that prove to be defective. Vaddio manufactures its hardware products from parts and components that are new or... -
Page 16: Index
