STT-869 – wireless
thermostatic actuator
C-2 – window sensor
C-8f – floor sensor
MW-1 – executive module
- Opening/closing the valve in
order to maintain desired
temperature value
- It sends information to the
main controller when the
window is opened/closed.
- It sends information about
current floor temperature.
- It enables wireless activation of
a given output in the external
controller. Depending on
selected operation mode, MW-1
may be used to activate CH
boiler operation, the pump or
valve actuators.
13
The actuator should be
registered in the external
controller
The sensor should be installed
in the window of a given zone
and it should registered to a
the zone.
The sensor should be
registered in a given zone.
The module should be
registered i the fitter's menu.
