2. TECHNICAL SPECIFICATIONS

2.1 General Appearance
1. Electronic Display
2. Programme Dial
3. Upper Tray
4. Detergent Drawer
5. Drum
6. Pump Filter Cover
7. Water Inlet Valve
8. Power Cable
9. Discharging Hose
10. Transit Bolts
2.2 Technical Specifications
Operating voltage /
requency (V/Hz)
Total current (A)
Water pressure (Mpa)
Total power (W)
Maximum dry laundry
capacity (kg)
Spinning revolution
(rev / min)
Programme number
Dimensions (mm)
Height
Width
Depth

3. INSTALLATION

3.1 Removing the Transit Bolts
1. Before operating the washing machine,
remove the 4 transit bolts and rubber
spacers from the rear of the machine.
If the bolts are not removed, they
may cause heavy vibration, noise and
malfunction of the machine and void
the warranty.
EN - 78
(220 – 240)
V~ / 50 Hz
10
Max.: 1 Mpa
Min.: 0.1 Mpa
2100
6
1000
15
845
597
497
