GUWX-070XX
GUGX-070XX
GUWX-091XX
GUGX-091XX
GUWX-125XX
GUGX-125XX
NOTE: Risk of a leaking coil due to freezing and/or corrosion. Can cause
equipment and serious building damage.
NOTE: Risk of corrosion can cause equipment damage. Contact a water
consultant about water quality, corrosion and freeze protection requirements.
Water chemistry varies greatly by location, as do the required additives, called
inhibitors that reduce the corrosive effect of the fluids on the piping systems
and components. The chemistry of the water used must be considered, be-
cause water from some sources may contain corrosive elements that reduce
the effectiveness of the inhibited formulation. Preferably, surface waters that
are classified as soft and are low in chloride and sulfate ion content should
be employed. Proper inhibitor maintenance must be performed to prevent
corrosion of system components. Consult glycol manufacturer for testing
and maintenance of inhibitors.
Commercial ethylene glycol, when pure, is generally less corrosive to the
common metals of construction than water itself. It will, however, assume the
corrosively of the water from which it is prepared and may become increas-
ingly corrosive with use if not properly inhibited.
6.4 Internal (Fluid) Volume – Fluid Coolers

6.4.1 Fluid Cooler Information

The information regarding fluid cooler (or often referred to as a "dry cooler") internal volume, the vol-
ume of the inter-connecting piping and the freezing point of aqueous solutions can be found in the
individual Fluid Cooler User Manuals which should be referred to for more complete details.
9.9 (37.4)
12.2 (46.1)
16.2 (61.3)
53
15.9 (60.2)
16.3 (61.7)
23.1 (87.4)
