Measure the superheat at the compressor suction line at least 6 inches (152 mm) away from the com-
pressor. Compare suction pressure and temperature reading between the dap4 and the manifolds. If
the difference between the manifold reading and dap4 reading is more than 5%, check for the EEV wir-
ing and any possible alarms on dap4, or EEV driver. Measure sub-cooling at the liquid line.
When charging is complete, add the correct amount of oil, if the line run exceeds longer than 20m or
66ft. This procedure must be conducted with the system running at high load (compressor at full speed).
ALWAYS use original Danfoss POE oil 160SZ from new cans.
Oil addition is calculated based on refrigerant charge, shown in the table below:
Additional Oil Required (oz)
Note: Additional oil is only needed if pipe run is longer than 20m or 66ft.
Total Refrigerant Weight
(lbs.)
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
190
200
210
220
230
240
250
Danfoss Variable Speed
Compressor
12
18
25
31
37
43
49
55
61
67
74
80
86
92
98
104
110
117
123
129
135
141
147
153
46
Danfoss Fixed Speed
Compressor
6
9
12
15
18
21
25
28
31
34
37
40
43
46
49
52
55
58
61
64
67
71
74
77
