netvox R718F User Manual page 7

Example of ConfigureCmd
FPort：0x07
Bytes 1
CmdID
CmdID– 1 byte
DeviceType– 1 byte – Device Type of Device
NetvoxPayLoadData– var bytes (Max=9bytes)
Description Device
ConfigReport
Req
ConfigReport
Rsp
R718F
ReadConfig
ReportReq
ReadConfig
ReportRsp
1. Configure device parameters MinTime = 1min, MaxTime = 1min, BatteryChange = 0.1v
Downlink: 011D003C003C0100000000
Device returns:
811D000000000000000000 (configuration successful)
811D010000000000000000 (configuration failed)
2. Read device parameters
Downlink: 021D000000000000000000
Device returns:
821D003C003C0100000000 (current configuration parameters)
1
DeviceType
Device
CmdID
Type
MinTime
0x01
(2bytes Unit: s)
0x81
0x1D
0x02
MinTime
0x82
(2bytes Unit: s)
Var (Fix =9 Bytes)
NetvoxPayLoadData
NetvoxPayLoadData
MaxTime BatteryChange
(2bytes Unit: s) (1byte Unit: 0.1v)
Status
(0x00_success)
Reserved
(9Bytes, Fixed 0x00)
MaxTime BatteryChange
(2bytes Unit: s) (1byte Unit: 0.1v)
6
Reserved
(4Bytes, Fixed 0x00)
Reserved
(8Bytes, Fixed 0x00)
Reserved
(4Bytes, Fixed 0x00)
