MVC-CD200/CD300
SERVICE MANUAL
Ver 1.0 2001. 05
Level 2
On the SY-67 board and the DDX-G2100 COMPLETE ASSEMBLY (Including the MD-083 Board)
This service manual provides the information on the premised of the circuit board replacement service and not intended
repair inside the SY-67 board in case of trouble. It is also premised that the mechanism deck DDX-G2100 COMPLETE
ASSEMBLY (including the MD-083 board) shall be exchanged as an assembly in case of trouble.
Therefore, disassembling procedure and exploded view of the DDX-G2100 COMPLETE ASSEMBLY are not shown. The
block diagram, printed wiring board, schematic diagram and electrical parts list of the SY-67 board are also not shown.
Note that the following pages are lacking intentionally.
SY-67 board
Block diagram ............................... Page 3-15 to 3-20
Printed wiring board ..................... Page 4-19 to 4-22
Schematic diagram ....................... Page 4-23 to 4-42
Electrical parts list ........................ Page 6-18 to 6-24
The above-described information is shown in service manual Level 3.
System
Exposure control
Automatic exposure, Shutter
Image device
speed priority, Aperture
MVC-CD200: 6.64 mm
priority, Manual exposure
(1/2.7 type) color CCD
White balance
MVC-CD300: 8.93 mm
Automatic, Indoor, Outdoor,
(1/1.8 type) color CCD
One-push
Lens
Data system
3× zoom lens
Movie: MPEG1
MVC-CD200: f = 6.1 –
Still: JPEG, GIF (in TEXT
18.3 mm (1/4 – 3/4 inches)
mode, Clip Motion), TIFF
(39 – 117 mm (1 9/16 –
Audio with still image:
4 5/8 inches) when
MPEG1 (Monaural)
converted into a 35 mm still
Recording medium
camera)
8 cm CD-R/CD-RW
MVC-CD300: f = 7 – 21 mm
(9/32 – 27/32 inches) (34 –
Recommended flash
recording distance (ISO
102 mm (1 3/8 –
is set to AUTO):
4 1/8 inches) when
MVC-CD200: 0.3 m to
converted into a 35 mm still
2.5 m (11 7/8 inches to
camera)
8 1/3 feet)
MVC-CD200: F = 2.8 – 2.9
MVC-CD300: 0.3 m to
MVC-CD300: F = 2.0 – 2.5
3 m (11 7/8 inches to 9 feet
10 1/8 inches)
Photo : MVC-CD300
This service manual contains information for japanese model as well.
DDX-G2100 COMPLETE ASSEMBLY
Disassembly ................................. Page 2-15 to 2-16
Exploded view .............................. Page 6-8
MD-083 board
Block diagram ............................ Page 3-21 to 3-26
Printed wiring board ................... Page 4-43 to 4-46
Schematic diagram .................... Page 4-47 to 4-54
Electrical parts list ...................... Page 6-14 to 6-18
SPECIFICATIONS
Drive
ACC jack
Read: Maximum ×8
Mini-minijack (Ø 2.5 mm)
Write: ×4
USB jack
mini-B
Readout
Noncontact optical readout
LCD screen
(using semiconductor laser)
LCD panel
Laser
TFT (Thin Film Transistor
Wavelength: 777 to 787 nm
active matrix) drive
NA: 0.5
LCD size
Maximum output: 23 mW
2.5 type
Emission duration: 600 ns
Total number of dots
Input and Output
123 200 (560×220) dots
connector
A/V OUT (MONO)
(Monaural)
Minijack Video:
1 Vp-p, 75 Ω, unbalanced,
sync negative
Audio: 327 mV (at a 47 kΩ
load)
Output impedance: 2.2 kΩ
US Model
Canadian Model
AEP Model
UK Model
Hong Kong Model
Australian Model
Chinese Model
Tourist Model
Korea Model
Japanese Model
General
Application
Sony battery pack NP-FM50
(supplied)
Power requirements
7.2 V
Power consumption
(During shooting with
the LCD backlight
turned on)
MVC-CD200: 3.0 W
MVC-CD300: 3.5 W
Operating temperature
0°C to 40°C (32°F to 104°F)
— Continued on next page —
DIGITAL STILL CAMERA
E Model

Advertisement

Table of Contents
loading

Related Manuals for Sony MVC-CD200

Summary of Contents for Sony MVC-CD200

  • Page 1 Audio: 327 mV (at a 47 kΩ camera) 8 1/3 feet) load) MVC-CD200: F = 2.8 – 2.9 MVC-CD300: 0.3 m to Output impedance: 2.2 kΩ MVC-CD300: F = 2.0 – 2.5 3 m (11 7/8 inches to 9 feet...
  • Page 2 MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS DANS LES SUPPÉMENTS PUBLIÉS PAR SONY.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS SERVICE NOTE Troubleshooting ··································································· 1-22 ····································································· 6 Warning and notice messages ·············································· 1-24 Self-diagnosis display ·························································· 1-25 GENERAL LCD screen indicators ························································· 1-25 Introduction ··········································································· 1-1 Getting started DISASSEMBLY Identifying the parts ······························································· 1-1 2-1. LCD SECTION (PK-58 BOARD) ·································· 2-2 Preparing the power supply ···················································...
  • Page 4 3-1. Flange Back Adjustment (1) 6-2. ELECTRICAL PARTS LIST ·········································· 6-9 (Using Flange Back Adjustment Chart) ························ 5-14 3-2. Flange Back Adjustment (2)(MVC-CD200) ················· 5-14 Electrical parts list of the SY-67 and MD-083 boards are not shown. Flange Back Check ························································ 5-15 Picture Frame Setting ····················································...

  • Page 5: Service Note

    The electric shock is caused by the charged voltage which is kept without discharging when the main power of the MVC-CD200/CD300 is simply turned off. Therefore, the remaining voltage must be discharged as described below.
  • Page 6 [Description on Self-diagnosis Display] Self-diagnosis display • C: ss: ss The contents which can be handled by customer, are displayed. • E: ss: ss The contents which can be handled by engineer, are displayed. Display Code Countermeasure Cause Caution Display During Error Change the disk and turn off the main C:32:01 Defective base unit.

  • Page 7: General

    “InfoLITHIUM” is a lithium ion battery pack which can exchange information such as battery K Reset button (99) consumption with compatible video equipment. “InfoLITHIUM” M series battery packs have mark. “InfoLITHIUM” is a trademark of Sony Corporation. L DC IN cover/DC IN jack (10, 13)
  • Page 8 Connect the power cord (mains lead) to the AC power adaptor and then to a wall outlet (mains). Using a car battery Use a Sony DC adaptor/charger. Using your camera abroad For details, see page 90. When using the AC power adaptor Be sure to use it near the wall outlet (mains).

  • Page 9: Setting The Date And Time

    Setting the date and time Set the numeric value with on the control button, then press the center enter it. When you first use your camera, set the date and time. If these are not set, the CLOCK SET Y/M/D M/D/Y After entering the number, moves to the next...

  • Page 10: Basic Operations B Recording

    Basic operations B Recording Initializing a disc (INITIALIZE) What is initialization? The initialization is required to record images on a disc. In case that you have executed the finalization (page 32) using the camera to view When you use a new disc or the disc which was finalized with other equipment than images on a CD-ROM drive, the initialization is automatically executed.
  • Page 11 • When [ISO] is set to [AUTO] in the menu settings (page 49), the recommended shooting distance is 0.3 to 2.5 m (11 7/8 inches to 8 1/3 feet) (MVC-CD200) or 0.3 to 3.0 m (11 7/8 When you use the self-timer function, the subject is recorded about 10 seconds after inches to 9 feet 10 1/8 inches) (MVC-CD300).

  • Page 12: Recording Moving Images

    Recording moving images Set the mode dial to The preparation for recording a moving image is complete. Moving images with audio are recorded in MPEG format. Before recording moving images, push the POWER switch in the arrow direction to turn on the power and Press the shutter button fully down.

  • Page 13: Preparation For Viewing Images Using A Computer

    Press DISPLAY/LCD BACK LIGHT ON/OFF to turn on/off the indicators on the LCD screen. See page 107 for a detailed description of the indicators. Printed side of the adaptor (SONY is printed on this side and the other side is the luster side.) Pull the third tab out away from the disc and the disc will slip into place.

  • Page 14: Viewing Images Using A Computer

    Notes Viewing images using a • It takes for about one minute to execute the finalization. Do not shake or jar the camera during computer this operation. Place the camera on a stable surface during the finalization. • When you execute the finalization, we recommend that you use the external power source (page 13).
  • Page 15 DirectCD included in the supplied CD-ROM. For details on DirectCD, refer to the software operating instructions of DirectCD. Double-click the [SONY USB] folder in the file list, and then double- click [ SET UP]. E.g., for Windows Me users The installer of device driver starts and the necessary files are automatically copied to the computer.

  • Page 16: Image File Storage Destinations And Image File Names

    Image file storage destinations Double click the disc folder. and image file names Double-click the desired data file. For the detailed folder and file names, see “Image file storage destinations and Image files recorded with your camera are grouped in folders by recording mode. image file names”...

  • Page 17: How To Use The Control Button

    When you Yellow cases, go to step record high-quality images, use a low-number AUTO setting (except when the mode dial is set to SCN). 0.8m MVC-CD200 Selects the image size when recording still +2.0EV F5.6 (IMAGE images (page 53). 1600×1200 SIZE) 1600 (3:2) 1024×768...

  • Page 18: Setting The Image Size (Image Size)

    ∗ Only in single-image mode. Still image sizes: MVC-CD200: 1600×1200, 1600 (3:2)*, 1024×768, 640×480 MVC-CD300: 2048×1536, 2048 (3:2)*, 1600×1200, 1280×960, 640×480 ∗ The image is recorded in the ratio of three to two to fit the printing paper size. Using this image size, the margin of an image is not printed out.

  • Page 19: B Various Recording

    1/3 step. jog dial. then press the jog dial. The shutter speed can be selected Select the aperture value with from 8'' to 1/800 (MVC-CD200) or the jog dial, then press the 8'' to 1/1000 (MVC-CD300) by 1/3 jog dial. step.

  • Page 20: Recording Images According To Shooting Conditions

    E-MAIL mode in step 3. you use a tripod to prevent camera- Select [NORMAL] with shake as the shutter speed is set MVC-CD200 Notes slow in this mode. • You cannot use the flash in this mode. Image size Quality •...

  • Page 21: Recording Still Images As Uncompressed Files (Tiff)

    • When the mode dial is set to M or SCN, [2048×1536] (MVC-CD300) size other the image may be bleached out or may be than when [1600 (3:2)] (MVC-CD200) or turned black. [2048 (3:2)] (MVC-CD300) is selected. • The number of recordable images is the •...

  • Page 22: Setting The Distance To The Subject

    Setting the distance Recording images in Adjusting the Normally, the camera automatically to the subject macro exposure adjusts the exposure. If the color of the Mode dial: /S/A/M/SCN/ Mode dial: /S/A/M/SCN/ (EXPOSURE) image is too dark or bright as illustrated below, we recommend that you adjust the Mode dial: /S/A/SCN/...

  • Page 23: Recording The Date And Time On The Still Image

    Notes Recording the date Using the Spot light- • If you select [DATE] in step 3, the date is and time on the still imposed onto the image in the order metering function selected with “Setting the date and time” image (DATE/TIME) Mode dial: /S/A/M/SCN/...

  • Page 24: Playing Back The Still Images In Order (Slide)

    Notes To cancel the SLIDE SHOW Playing back the still Rotating a still image setting • Zoom scaling is up to 5× regardless of the original image size. images in order (ROTATE) Select [CANCEL] with in step 3, • The quality of enlarged images may be (SLIDE) then press Mode dial:...

  • Page 25: Preventing Accidental Erasure (Protect)

    Display the image you want to When marking the mark, you , then press print with cannot select [ALL]. MVC-CD200: 1600×1200, In triple-image mode The frame of the selected image 1024×768, 640×480 Press the zoom W button twice to turns green.

  • Page 26: Formatting A Cd-Rw

    Notes Press MENU. Formatting a CD-RW • When you format, be sure to use a fully The menu appears. charged battery pack or the AC power When deleting all the images in the adaptor as the power source. Select [OK] with , then •...

  • Page 27: Additional Information

    If this If any problem occurs, unplug your happens, a short may occur and the camera and contact your nearest Sony unit may be damaged. dealer. • Always keep metal contacts clean.

  • Page 28: Using Your Camera Abroad

    (If you press the reset button, the date and time remaining battery time is 5 to 10 setting is cleared.) Should your camera still not operate properly, consult your Sony minutes. dealer or local authorized Sony service facility. If code displays (C:...
  • Page 29 3 to 50 cm Set the flash to (no indication) or (page 24). (1 3/16 to 19 3/4 inches) (MVC-CD200) or about 4 • The mode dial is set to , SET UP, or to 50 cm (1 5/8 to 19 3/4 inches) (MVC-CD300) (MPEG MOVIE).

  • Page 30: Warning And Notice Messages

    • A malfunction has occurred in the battery pack. /CHG lamp flashes “System properties” is displayed. Click the [Hardware] tab located at the top, when charging a battery Contact your Sony dealer or local authorized then click the [Device Manager (D)] button. pack. Sony service facility.

  • Page 31: Self-Diagnosis Display

    If you are unable to rectify the problem even if you try corrective actions a H Sharpness indicator few times when C: ss : ss is indicated, contact your Sony dealer or local U Self-timer indicator I Picture effect indicator authorized Sony service facility.

  • Page 32: Disassembly

    MVC-CD200/CD300 SECTION 2 DISASSEMBLY The following flow chart shows the disassembly procedure. 2-1. LCD section (PK-58 board) PK-58 board service position 2-3. Lens section (CD-333/334 board) 2-2. Cabinet (front) section 2-4. Cabinet (front) assembly (TK-61 board), CD-333/334, TK-61 boards service position Control switch block (RL-503) 2-5.

  • Page 33: Lcd Section (Pk-58 Board)

    NOTE: Follow the disassembly procedure in the numerical order given. 2-1. LCD SECTION (PK-58 BOARD) 3 Two precision screws (DIA 1.7 × 4) 5 PK-58 board Upper stay assembly Remove the CD rear lid in the direction of the arrow A. Remove the PK-58 board in the direction of the arrow B.

  • Page 34: Cabinet (Front) Section

    2-2. CABINET (FRONT) SECTION 9 Screw (M 2 × 4), lock ace, P2 3 Two screws 6 Screw (M 2 × 4), (M 2 × 3.5) lock ace, P2 4 Accessory shoe 2 Special (step) screw (M 2) qf FP-369 flexible board (5P) qg Control switch block - 6 7 (RL-503) (6P)

  • Page 35: Lens Section (Cd-333/334 Board)

    2-3. LENS SECTION (CD-333/334 BOARD) (CD200) 5 Four screws 5 CCD fitting adaptor (CL) 4 Four claws 6 Optical filter block 7 Seal rubber (CL) 6 Zoom motor unit 8 Remove the solderings 0 CCD heat sink (M) 8 Zoom lens qa CD-333 board 7 Focus motor unit...

  • Page 36: Cabinet (Front) Assembly (Tk-61 Board), Control Switch Block (Rl-503)

    2-4. CABINET (FRONT) ASSEMBLY (TK-61 BOARD), CONTROL SWITCH BLOCK (RL-503) 1 Two screws (M 1.7 × 2), lock ace, P2 2 Two claws 6 Microphone holder assembly 1 Two precision 7 Microphone cushion screws (DIA 1.7 × 4) 8 Microphone 9 Retainer sheet metal...

  • Page 37: Battery Holder (Jk-208 Board)

    2-5. BATTERY HOLDER (JK-208 BOARD) 5 Battery terminal board (3P) 4 Remove the BT holder assembly in the direction of the arrow A. REMOVING THE BATTERY HOLDER - 6 7 6 BT holder 8 Battery holder assembly 3 BT lid retainer 7 Battery spring 3 Precision...

  • Page 38: Stroboscope Section (Flash Unit)

    2-7. STROBOSCOPE SECTION (FLASH UNIT) Note: The charging capacitor is charged to the maximum of 300V. There is a danger of electric shock due to the high voltage when the capacitor is touched by bare hand. Discharge the voltage remained in the capacitor, referring to the Service Note (See page 5). 3 Discharging the capacitor 4 Two precision Capacitor cap...

  • Page 39: Base Unit (Ddx-G2100 Complete Assembly)

    2-8. BASE UNIT (DDX-G2100 COMPLETE ASSEMBLY) Precautions during handling 7 Remove the DDX-G2100 complete assembly in the direction of the arrow. • Do not turn the side of the optical lens downward. 1 Harness (FS-138) (2P) (door look plunger) • Hold the frame. •...

  • Page 40: Lid Cd Section

    2-9. LID CD SECTION Remove the PRE open spring in the direction of the arrow C. - 8 3 1 Open the lid CD section 3 PRE open spring 2 Remove the Parallel pin (DIA 3) - 8 3 in the direction of the arrow A. 2 Remove the lid CD section in 2 Parallel 5 FP-363 flexible...

  • Page 41: Solenoid Plunger

    2-11.SOLENOID PLUNGER (DOOR LOCK/STROBOSCOPE), CD LOCK SLIDER 1 CD lock lever spring 2 CD lock lever 2 Two precision 3 Parallel pin screws (DIA 1.6 × 6) (DIA 1.7 × 4) 1 CD opener spring 3 Solenoid cover 1 Solenoid plunger (door lock), Harness (FS-138) 2 CD opener assembly...

  • Page 42: Control Switch Block (Zk-503)

    2-12.CONTROL SWITCH BLOCK (ZK-503), STRAP SHAFT Remove the PO spring stay in 1 Open the lid the direction of the arrow A. CD section - 8 3 - 8 3 PRE open 3 PO spring spring stay 2 Two screws (DIA 1.7 ×...

  • Page 43: Mode Knob, Power Spring

    2-13.MODE KNOB, POWER SPRING "S" position set in live A When attaching it, coat the 7 Mode knob hatched portion with grease. 6 Dial base 5 Click plate Click plate Rear view 4 Three EG grip screws (M 1.4 × 2.5) Note: Perform the running-in rotation of the click plate several times.

  • Page 44: Circuit Boards Location

    2-14.CIRCUIT BOARDS LOCATION SY-67 LD, PEARL, VIDEO OUT, SH, 16M FLASH MEMORY, 64M SDRAM, CLK GEN, CW, HI CONTROL, AUDIO PROCESS, DC/DC CONVERTER, FLASH UNIT TK-61 (LENS CAP DETECT) CD-334 (CD300) (LENS DRIVE, CAMERA PROCESS, CCD IMAGER) MD-083 CD-RF PROCESS, SERVO, CD, DSP, CD-R/RW GA, MD SYSTEM CONTROL, EFM/ENC CONTROL PK-58...

  • Page 45: Flexible Boards Location

    2-15.FLEXIBLE BOARDS LOCATION The flexible boards contained in the mechanism deck and that in the zoom lens are not shown. CONTROL SWITCH BLOCK (ZK-503) FP-362 FP-248 FP-370 FP-369 CONTROL SWITCH BLOCK (RL-503) FP-363 FP-361 FP-364 Disassembling procedure of Mechanism deck (DDX-G2100 COMPLETE ASSEMBLY) are not shown.

  • Page 46: Block Diagrams

    MVC-CD200/CD300 SECTION 3 BLOCK DIAGRAMS 3-1. OVERALL BLOCK DIAGRAM (1/2) ( ) : Page No. shown in ( ) indicates the page to refer on the schematic diagram. CD-333 BOARD SY-67 BOARD(1/2) (MVC-CD200) CD-334 BOARD (MVC-CD300) (4-25) (4-14) ZOOM (4-15)

  • Page 47: Overall Block Diagram (2/2)

    MVC-CD200/CD300 3-2. OVERALL BLOCK DIAGRAM (2/2) ( ) : Page No. shown in ( ) indicates the page to refer on the schematic diagram. BASE UNIT OPTICAL MD-083 BOARD SY-67 BOARD(2/2) DEVICE (DDX-G2100) FMDT,FMCK FMDT,FMCK (4-33) PH901 IC154 IC207 IC414...

  • Page 48: Mode Control Block Diagram

    MVC-CD200/CD300 3-3. MODE CONTROL BLOCK DIAGRAM ( ) : Page No. shown in ( ) indicates the page to refer on the schematic diagram. FS-83 BOARD SY-67 BOARD(3/3) S001 (SEE PAGE 4-57) (CONTROL BUTTON) IC403 RIGHT D405 BACKUP VCC, RESET...

  • Page 49: Lcd Block Diagram

    MVC-CD200/CD300 3-4. LCD BLOCK DIAGRAM ( ) : Page No. shown in ( ) indicates the page to refer on the schematic diagram. BACK LIGHT UNIT PK-58 BOARD(3/3) Q206 SWITCHING ND901 (BACK LIGHT) (4-67) L201 L202 L203 IC301 IC302 ws IC302 wf 4.5Vp-p...

  • Page 50: Power Block Diagram (1/3)

    MVC-CD200/CD300 3-5. POWER BLOCK DIAGRAM (1/3) ( ) : Page No. shown in ( ) indicates the page to refer on the schematic diagram. FS-83 BOARD(1/2) CN001 CN708 CN701 (4-33,34) BATT SIG BACK UP VCC (SEE PAGE 4-57) BATT/XEXT BT901 D 3.4V...

  • Page 51: Power Block Diagram (2/3)

    MVC-CD200/CD300 3-6. POWER BLOCK DIAGRAM (2/3) ( ) : Page No. shown in ( ) indicates the page to refer on the schematic diagram. FS-83 BOARD(1/2) SY-67 BOARD(2/2) POWER LED D004 (POWER) (SEE PAGE 4-57) D 3.4V CN708 CN001 CONTROL SWITCH...

  • Page 52: Power Block Diagram (3/3)

    MVC-CD200/CD300 3-7. POWER BLOCK DIAGRAM (3/3) ( ) : Page No. shown in ( ) indicates the page to refer on the schematic diagram. (4-51,52) (4-51,53) MD-083 BOARD (4-51) (4-48) IC402,403 IC400,407 IC401 IC406 IC404 IC022 IC406,418 IC419,422,423 D405 BACKUP VCC...

  • Page 53: Printed Wiring Boards And Schematic Diagrams

    MVC-CD200/CD300 SECTION 4 PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS 4-1. FRAME SCHEMATIC DIAGRAM (1/2) LENS UNIT MVC-CD300 MVC-CD200 IMAGER CD-333 BOARD (MVC-CD200) CD-334 BOARD (MVC-CD300) 1/3 LD BLOCK 2/3 CH BLOCK 3/3 CCD BLOCK PL901 STROB DEW SENSOR PLUNGER FP-364...
  • Page 54 MVC-CD200/CD300 FRAME SCHEMATIC DIAGRAM (2/2) CONTROL SWITCH BLOCK(ZK-503) S003 S001 S002 (MODE SWITCH) (EXEC) CONTROL SWITCH (P_AUTO) BLOCK(RL-503) POWER ON/OFF(CHG) FLASH UNIT (PLAY) S(AE-S) S004,005 (MOVIE) (SHUTTER) (SET UP) A(AE-A) (ZOOM) LOCK SCN(SCENE) M(MANUAL) PK-58 BOARD 1/3 RGB BLOCK 2/3 TG BLOCK...

  • Page 55: Printed Wiring Boards And

    (For schematic diagrams) • All capacitors are in µF unless otherwise noted. p: pF. 50V or less are not indicated except for electrolytics and tantalums. About 34cm (MVC-CD200) • Chip resistors are 1/10W unless otherwise noted. About 28cm (MVC-CD300) kΩ=1000Ω, MΩ=1000kΩ.

  • Page 56: Lens Drive, Camera Process, Ccd Imager) Printed Wiring Board (Cd200)

    MVC-CD200/CD300 CD-333 (LENS DRIVE, CAMERA PROCESS, CCD IMAGER) PRINTED WIRING BOARD (CD200) — Ref. No. CD-333 Board; 1,000 Series — For printed wiring board MD-083 • Refer to page 4-78 for parts location. CD-RF PROCESS, SERVO, CD, DSP, CD-R/RW GA, MD SYSTEM CONTROL, •...
  • Page 57 MVC-CD200/CD300 CD-334 (LENS DRIVE, CAMERA PROCESS, CCD IMAGER) PRINTED WIRING BOARD (CD300) — Ref. No. CD-334 Board; 1,000 Series — For printed wiring board SY-67 • Refer to page 4-78 for parts location. LD, PEARL, VIDEO OUT, SH, 16M FLASH MEMORY, •...
  • Page 58 MVC-CD200/CD300 For Schematic Diagram • Refer to page 4-7 for CD-333 printed wiring board. • Refer to page 4-9 for CD-334 printed wiring board. C306 MVC-CD200 0.033u R330 R309 CD-333 BOARD(1/3) 2200 (MVC-CD200) 100k 1608 1005 1005 HALL_AD CD-334 BOARD(1/3)
  • Page 59 MVC-CD200/CD300 For Schematic Diagram • Refer to page 4-7 for CD-333 printed wiring board. • Refer to page 4-9 for CD-334 printed wiring board. • Refer to page 4-73 for waveforms. CD-333 BOARD(2/3) NO MARK:STILL/PB MODE (MVC-CD200) S :STILL MODE...

  • Page 60: Ccd Imager

    MVC-CD200/CD300 For Schematic Diagram For Schematic Diagram • Refer to page 4-7 for CD-333 printed wiring board. • Refer to page 4-9 for CD-334 printed wiring board. • Refer to page 4-73 for waveforms. • Refer to page 4-73 for waveforms.

  • Page 61: Pages From 4-19 To 4-54 Are Not Shown

    MVC-CD200/CD300 TK-61 (LENS CAP DETECT) PRINTED WIRING BOARD — Ref. No. TK-61 Board; 6,000 Series — TK-61 BOARD LENS CAP DETECT FP-370 R511 -REF.NO.:6000 SERIES- FLEXIBLE CN503 XX MARK:NO MOUNT CAM_P_5V R503 CAM_P_5V R512 NO MARK:STILL/PB MODE LED901 CN501 IC501...
  • Page 62 MVC-CD200/CD300 FS-83 (CHARGER) PRINTED WIRING BOARD — Ref. No. FS-83 Board; 1,000 Series — CONTROL SWITCH BLOCK(ZK-503) S001 (MODE SWITCH) (P_AUTO) (PLAY) S(AE-S) R005 (MOVIE) R001 (SET UP) A(AE-A) CAM_3.1V R003 R006 MODE_DIAL M(MANUAL) XSET_UP SCN(SCENE) XPB_ON R004 SY-67 BOARD(9/10)

  • Page 63: Charger

    MVC-CD200/CD300 For Schematic Diagram • Refer to page 4-56 for printed wiring board. FS-83 BOARD NO MARK:STILL/PB MODE CHARGER -REF.NO.:1000 SERIES- C001 C002 XX MARK:NO MOUNT CN004 CN002 LF001 REG_GND ACV_UNREG Q002 J901 REG_GND TPC8305(TE12L) R013 ACV_GND DC IN R014...
  • Page 64 MVC-CD200/CD300 JK-208 (USB INTERFACE) PRINTED WIRING BOARD — Ref. No. JK-208 Board; 2,000 Series — For printed wiring board MD-083 • Refer to page 4-79 for parts location. CD-RF PROCESS, SERVO, CD, DSP, CD-R/RW GA, MD SYSTEM CONTROL, • JK-208 board consists of multiple layers. However, only EFM/ENC CONTROL the sides (layers) A and B are shown.
  • Page 65 MVC-CD200/CD300 For Schematic Diagram • Refer to page 4-59 for printed wiring board. JK-208 BOARD FB102 J101 FB103 USB INTERFACE FB104 -REF.NO.:2000 SERIES- R103 R104 FB105 100k XX MARK:NO MOUNT FB106 0uH NO MARK:STILL/PB MODE R109 470k C106 Q102 Q101...

  • Page 66: Rgb Drive, Timing Generator, Back Light) Printed Wiring Board

    MVC-CD200/CD300 PK-58 (RGB DRIVE, TIMING GENERATOR, BACK LIGHT) PRINTED WIRING BOARD — Ref. No. PK-58 Board; 4,000 Series — For printed wiring board • Refer to page 4-79 for parts location. • PK-58 board consists of multiple layers. However, only the sides (layers) A and B are shown.
  • Page 67 MVC-CD200/CD300 (EXPOSURE) (SPOT METER) RGB DRIVE, TIMING GENERATOR, BACK LIGHT 4-65 PK-58...

  • Page 68: Rgb Drive)(1/3)

    MVC-CD200/CD300 For Schematic Diagram • Refer to page 4-63 for printed wiring board. • Refer to page 4-74 for waveforms. PK-58 BOARD(1/3) NO MARK:STILL/PB MODE RGB DRIVE(RGB BLOCK) -REF.NO.:4000 SERIES- XX MARK:NO MOUNT D304 TLAU1008(T05,SOY) R322 470k /CHG (AMBER) R307...

  • Page 69: Timing Generator

    MVC-CD200/CD300 For Schematic Diagram • Refer to page 4-63 for printed wiring board. PK-58 BOARD(2/3) NO MARK:STILL/PB MODE S :STILL MODE TIMING GENERATOR(TG BLOCK) P :PB MODE -REF.NO.:4000 SERIES- Q401-Q404 XX MARK:NO MOUNT COM DRIVE SIGNAL PATH TO(1/3) P_4.9V L401...

  • Page 70: Back Light)(3/3)

    MVC-CD200/CD300 For Schematic Diagram • Refer to page 4-63 for printed wiring board. PK-58 BOARD(3/3) NO MARK:STILL/PB MODE BACK LIGHT(BL BLOCK) -REF.NO.:4000 SERIES- Q206 R217 FP102-TL 1800 XX MARK:NO MOUNT SWITCHING Q204 L202 L201 L203 1/10W 4.7uH 2SD2216J-QR(K8).SO 22uH 100uH...

  • Page 71: Waveforms

    MVC-CD200/CD300 4-3. WAVEFORMS CD-333 CD-334 BOARD BOARD IC101 1,3 IC202 qh IC401 1,3 IC202 qh 2µsec 3.475µsec 7.5Vp-p 7.5Vp-p 100µsec 3.4Vp-p 3.4Vp-p 124µsec 54nsec 54nsec IC101 2 IC202 w; IC401 2 IC202 w; 3.1Vp-p 3.1Vp-p 24.0Vp-p 22.0Vp-p 33.3msec 124µsec 33.3msec 124µsec...
  • Page 72 MVC-CD200/CD300 PK-58 BOARD IC302 8 0.5Vp-p IC302 9 0.2Vp-p IC302 q; 0.2Vp-p IC302 w; 4.5Vp-p IC302 ws 4.5Vp-p IC302 wf 4.5Vp-p WAVEFORMS 4-74 PK-58...
  • Page 73 Waveforms and parts location of the SY-67 and MD-083 boards are not shown. Pages from 4-75 to 4-77 are not shown.

  • Page 74: Mounted Parts Location

    MVC-CD200/CD300 no mark : side A 4-4. MOUNTED PARTS LOCATION * mark : side B CD-333 BOARD CD-334 BOARD C101 FB101 * R219 C201 FB203 R225 C102 * FB201 * R220 * C202 * FB204 R226 C103 * FB202 R221...
  • Page 75 MVC-CD200/CD300 no mark : side A * mark : side B FS-83 BOARD JK-208 BOARD PK-58 BOARD * C001 * BT101 C201 IC302 R401 * C002 C202 IC401 * R402 B-11 * C003 C101 C203 IC402 R403 * C004 C102...

  • Page 76: Adjustments

    Serial No. input Mechanism Mechanical adj. *1: MVC-CD200 model only. *2: When replacing the Base unit, reset the data of page: D, address: EC to EF to “00”. (Refer to “Record of Use check” of “5-2. SERVICE MODE”.) Table. 5-1-1.

  • Page 77: Adjustment

    5-1. ADJUSTMENT 1-1. PREPARATIONS BEFORE ADJUSTMENT 1-1-1. List of Service Tools • Oscilloscope • Color monitor • Vectorscope • AC power adapter • Regulated power supply • Digital voltmeter • Frequency counter Ref. No. Name Parts Code Usage Auto white balance adjustment/check Filter for color temperature correction (C14) J-6080-058-A White balance adjustment/check...

  • Page 78: Preparations

    Connect the equipment for adjustments according to Fig. 5-1-5. The lens block (CD-333/334 board) must be connected, because About 34cm (MVC-CD200) the timing generator (IC201) is provided on the CD-333/334 About 28cm (MVC-CD300) board of the lens block.
  • Page 79 Adjustment remote commander AUDIO (Black) CPC-9 jig (J-6082-393-C) Color monitor Vector scope VIDEO (Yellow) Terminated at 75 Ω 18 pins 12 pins LANC jack Lid open/close detect switch (S101,S103) Must be pressed when using the CD-R/RW AV OUT Must be connected when performing drive unit.

  • Page 80: Precaution

    ISO ................AUTO EV (PK-58 board) ............0EV IMAGE SIZE ......2048 × 1536 (MVC-CD300) AE LOCK (PK-58 board) ..........Off ......1600 × 1200 (MVC-CD200) PICTURE EFFECT ............OFF 2. Order of Adjustments Basically carry out adjustments in the order given.

  • Page 81: Initialization Of D Page Data

    Initializing Method: Order Page Address Data Procedure Set the data. Set the following data. 95 to B5 Fixed data-1 12: MVC-CD200 Battery end adj. 11: MVC-CD300 Set the data. B8 to C5 Fixed data-1 Set the data, and press PAUSE Video output level adj.

  • Page 82: Initializing The B, E, F, 7, 9 Page Data

    “01”. Perform “Modification of B, E, F, 7, 9 Page Data”. HALL adj. (MVC-CD200) Fixed data-1 (MVC-CD300) 2. Modification of B, E, F, 7, 9 Page Data If the B, E, F, 7, 9 Page data has been initialized, change the data of...
  • Page 83 Address Remark CD200CD300 CD200CD300 4F to 58 Fixed data-1 Flange back adj.(MVC-CD300) AWB standard data input Fixed data-1 (MVC-CD200) Mechanical shutter adj. 9C to 9F Fixed data-1 Fixed data-1 Mixed color cancel adj. Color reproduction adj. A4 to A8 Fixed data-1...

  • Page 84: Page Table

    4. 7 Page Table Note: Fixed data-1: Initialized data. (Refer to “1. Initializing the B, E, F, Initial value Address Remark 7, 9 Page Data”.) CD200CD300 Fixed data-2: Modified data. (Refer to “2. Modification of B, E, F, CCD white defect compensation 7, 9 Page Data”.) Initial value Address...

  • Page 85: Page Table

    5. 9 Page Table 7. B Page Table Note: Fixed data-1: Initialized data. (Refer to “1. Initializing the B, E, F, Note: Fixed data-1: Initialized data. (Refer to “1. Initializing the B, E, F, 7, 9 Page Data”.) 7, 9 Page Data”.) Fixed data-2: Modified data.

  • Page 86: Video System Adjustments

    1-3. VIDEO SYSTEM ADJUSTMENTS 1. Video Output Level Adjustment (SY-67 board) Adjust the sync level and burst level of the composite video signal output. Mode Still (Auto ( Subject Arbitrary Measurement Point Video terminal of AV OUT jack (75Ω terminated) Measuring Instrument Oscilloscope Adjustment Page...

  • Page 87: Camera System Adjustments

    RadarW RadarW 1-4. CAMERA SYSTEM ADJUSTMENTS 1. HALL Adjustment (MVC-CD200) For detecting the position of the lens iris, adjust the hall AMP gain Before perform the camera system adjustments, check that the and offset. specified values of “VIDEO SYSTEM ADJUSTMENT” are satisfied.

  • Page 88: Flange Back Adjustment (Using Minipattern Box)

    Measuring Instrument Adjustment remote commander Adjustment Page Adjustment Address 14 to 25, 87, 8A , 8B (MVC-CD200) 14 to 25, 87 to 9B (MVC-CD300) Specified value Note1: Dark siemens star chart. Note2: Check that the data of page: 6, address: 02 is “00”. If not, turn the power of the unit OFF/ON.

  • Page 89: Flange Back Adjustment

    14 to 25, 87, 8A , 8B Adjustment Page Note1: Make the lens horizontal and perform this adjustment. Adjustment Address 14 to 25, 87, 8A , 8B (MVC-CD200) 14 to 25, 87 to 9B (MVC-CD300) Preparations: Specified value 1) Set the zoom lens to the TELE end and expose a subject that is more than 500m away (subject with clear contrast such as Note1: Check that the data of page: 6, address: 02 is “00”.

  • Page 90: Flange Back Check

    4. Flange Back Check Mode Still (Auto ( Subject Siemens star (1.0 m from the front of the lens) (Luminance : approx. 300 lux) Measurement Point Check operation on TV monitor Measuring Instrument Specified Value The lens is focused. SETUP setting: DIGITAL ZOOM .............

  • Page 91: Picture Frame Setting

    5. Picture Frame Setting Mode Still (Auto ( Subject Color bar chart (Color reproduction adjustment frame) [MVC-CD200] Approx. 34cm from the front of the lens [MVC-CD300] Approx. 28cm from the front of the lens Measurement Point Video output terminal Measuring Instrument...

  • Page 92: F No. Standard Data Input

    RadarW RadarW RadarW RadarW RadarW RadarW RadarW RadarW RadarW RadarW 6. F No. Standard Data Input 7. Mechanical Shutter Adjustment Compensate the unevenness of the iris meter sensitivity. Adjust the period which the mechanical shutter is closed, and compensate the exposure. Mode Still (Auto ( Mode...

  • Page 93: Light Value Adjustment

    26 to 28 Note1: This adjustment should be carried out upon completion of “Data Specified value 0FE0 to 1020 (MVC-CD200) Setting during Camera System Adjustments”. 0FC0 to 1040 (MVC-CD300) Note2: Check that the data of page: 6, address: 02 is “00”. If not, to page: 6, address: 01, set data: 00, and press the PAUSE button.

  • Page 94: Auto White Balance Standard Data Input

    Write down the data. Adjusting method: Set the following data, and press PAUSE button. Order Page Address Data Procedure 28 (MVC-CD200), 27 (MVC-CD300) Set the data. Write down the data. Set the data, and press PAUSE Set the following data, and press button.

  • Page 95: Color Reproduction Adjustment

    RadarW RadarW RadarW RadarW RadarW 12. Color Reproduction Adjustment 12-2. Color Reproduction Check Adjust the color Separation matrix coefficient so that proper color Mode Still (Auto ( reproduction is produced. Subject Color bar chart (Color bar standard picture frame) 12-1. Color Reproduction Adjustment Measurement Point Video output terminal Mode...

  • Page 96: White Balance Check

    FOCUS ............Manual (0.3m) Checking method: Fig. 5-1-14 (A). Order Page Address Data Procedure Check that the lens is not covered MVC-CD200 with any filter. 1.0mm Set the data. Set the data. Write down the data. Set the data, and press PAUSE 1.5mm...

  • Page 97: Ccd White Defect Compensation And Check

    RadarW RadarW RadarW RadarW RadarW RadarW RadarW RadarW RadarW RadarW 14. CCD White Defect Compensation and Check 15. CCD Black Defect Compensation and Check Mode Still (Auto ( Mode Still (Auto ( Subject Arbitrary Subject Clear chart (Color bar standard picture frame) (Note2) Measurement Point Display data of page 6, address: 55...

  • Page 98: Strobe Adjustment

    RadarW RadarW RadarW 16. Strobe Adjustment Adjusting method: Adjust the light level and white balance when the strobe light flashes. Order Page Address Data Procedure Mode Still (Auto ( Set the data. Subject Paper which reflection rate is 18% Set the data, and press PAUSE (Note2) (1.0m from the front of the lens) button.

  • Page 99: Led Illumination Check

    Set the data. Set the data. Set the data. Set the following data, and press PAUSE button. E0 (MVC-CD200), 00 (MVC-CD300) Set the following data, and press PAUSE button. 26 (MVC-CD200), 50 (MVC-CD300) Set the data, and press PAUSE button.

  • Page 100: Lcd System Adjustment

    1-5. LCD SYSTEM ADJUSTMENT 1. LCD Initial Data Input (1) Mode Still (Auto ( Note1: The back light (fluorescent tube) is driven by a high voltage AC Subject Arbitrary power supply. Therefore, do not touch the back light holder to Adjustment Page avoid electrical shock.

  • Page 101: Lcd Initial Data Input (2)

    2. LCD Initial Data Input (2) 3. VCO Adjustment (PK-58 board) Set the VCO free-run frequency. If deviated, the LCD screen will Mode Still (Auto ( be blurred. Subject Arbitrary Mode Still (Auto ( Adjustment Page Subject Arbitrary Adjustment Address 3A to 3F Measurement Point Pin 7 of CN302 (HSY)

  • Page 102: D Range Adjustment (Pk-58 Board)

    4. D Range Adjustment (PK-58 board) 5. Bright Adjustment (PK-58 board) Set the D range of the LCD driver to the specified value. If deviated, Set the level of the VIDEO signal for driving the LCD to the specified the LCD screen will become blackish or saturated (whitish). value.

  • Page 103: Contrast Adjustment (Pk-58 Board)

    6. Contrast Adjustment (PK-58 board) 7. Color Adjustment (PK-58 board) Set the level of the VIDEO signal for driving the LCD to the specified Set the color saturation to the standard value. If deviated, the color value. If deviated, the screen image will be blackish or saturated will be too dark or light.

  • Page 104: V-Com Level Adjustment (Pk-58 Board)

    8. V-COM Level Adjustment (PK-58 board) 9. V-COM Adjustment (PK-58 board) Set the common electrode drive signal level of LCD to the specified Set the DC bias of the common electrode drive signal of LCD to the value. specified value. If deviated, the LCD display will move, producing flicker and Mode Still (Auto (...

  • Page 105: White Balance Adjustment (Pk-58 Board)

    10. White Balance Adjustment (PK-58 board) Correct the white balance. If deviated, the LCD screen color cannot be reproduced. Mode Still (Auto ( Subject Arbitrary Measurement Point Check on LCD display Measuring Instrument Adjustment Page Adjustment Address D2, D3 Specified Value The LCD screen should not be colored.

  • Page 106: System Control System Adjustment

    1-6. SYSTEM CONTROL SYSTEM ADJUSTMENT Adjusting method: Order Page Address Data Procedure 1. Battery End Adjustment (SY-67 board) Set the data. Check the battery end voltage. Decrease the output voltage of the Mode Still (Auto ( regulated power supply so that the Subject All black digital voltmeter display is 5.50 ±...

  • Page 107: Serial No. Input

    2. Serial No. Input Write the serial No. in the EEPROM (nonvolatile memory). Convert the serial No. on the name plate from decimal to ASCII code, and write in the EEPROM. Page Address 32 to 37 Input method: Select page: 0, address: 01, and set data: 01. Read the 6-digit serial No.

  • Page 108: Service Mode

    5-2. SERVICE MODE 2-1. ADJUSTMENT REMOTE COMMANDER The adjustment remote commander is used for changing the calculation coefficient in signal processing, EVR data, etc. The adjustment remote commander performs bi-directional communication with the unit using the remote commander signal line (LANC). The resultant data of this bi-directional communication is written in the non-volatile memory.

  • Page 109: Data Process

    2-2. DATA PROCESS The calculation of the DDS display and the adjustment remote commander display data (hexadecimal notation) are required for obtaining the adjustment data of some adjustment items. In this case, after converting the hexadecimal notation to decimal notation, calculate and convert the result to hexadecimal notation, and use it as the adjustment data.

  • Page 110: Service Mode

    2-3. SERVICE MODE 2. Bit Value Discrimination Bit values must be discriminated using the display data of the adjustment remote commander for following items. Use the table 1. Setting the Test Mode below to discriminate if the bit value is “1” or “0”. Page D Address 10 Display on the adjustment remote commander...

  • Page 111: Switch Check (1)

    3. Switch check (1) Page 2 Address 80 Function When bit value = 1 When bit value = 0 Power switch (XPOWER ON) Power switch off Power switch on (Control switch block (ZK-503)) PLAY ( Mode dial (XPB ON) *1 Except PLAY (Control switch block (ZK-503)) Lens cap switch *2...

  • Page 112: Switch Check (4)

    6. Switch check (4) Page 2 Address 90 to 93 Using method: Select page: 2, address: 90 to 93. By discriminating the display data, the pressed key can be discriminated. Data Address 00 to 14 15 to 46 47 to 70 71 to A5 A6 to DE DF to FF...

  • Page 113: Self Diagnosis Log Check

    9. Self Diagnosis Log check Example: C : 32 : 01 Page 2 Address B3 to B5 Address : B5 Address : B4 Address Initial value Function Address : B3 (Note) Last error occurrence code Note: “C” → “01” “E” → “03” Using method: 1) The self diagnosis log is displayed at page: 2, addresses: B3 to B5.

  • Page 114: Repair Parts List

    MVC-CD200/CD300 SECTION 6 REPAIR PARTS LIST 6-1. EXPLODED VIEWS NOTE: • -XX, -X mean standardized parts, so they may • Abbreviation The components identified by mark 0 or have some differences from the original one. CND : Canadian model. dotted line with mark 0 are critical for safety.

  • Page 115: Section (Cd300)

    6-1-2. CABINET (FRONT) SECTION, LENS CABINET SECTION (CD200) Lens section (See page 6-4) MIC901 LED901 supplied supplied Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 3-968-729-71 SCREW (M2), LOCK ACE, P2 3-068-488-01 CUSHION, MICROPHONE X-3951-650-1 CABINET ASSY, LENS 3-062-299-01 SHEET, MICROPHONE 3-914-366-01 SCREW (DIA.
  • Page 116 6-1-3. CABINET (FRONT) SECTION, LENS CABINET SECTION (CD300) Lens section (See page 6-4) MIC901 LED901 supplied supplied supplied Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 3-068-411-01 RING, FILTER 3-068-402-01 SHEET METAL, RETAINER 3-968-729-71 SCREW (M2), LOCK ACE, P2 3-068-488-01 CUSHION, MICROPHONE 3-060-271-01 SCREW (M1.7X7) 3-062-299-01 SHEET, MICROPHONE...

  • Page 117: Lens Section

    6-1-4. LENS SECTION (CD300) (CD200) supplied M002 M001 supplied IC401 supplied supplied IC101 Be sure to read “Precautions Upon Replacing CCD Imager” on pages 4-15 (CD200) and 4-16 (CD300) when changing the CCD imager. Ref. No. Part No. Description Remarks Ref.

  • Page 118: Cabinet (Rear) Section-1

    6-1-5. CABINET (REAR) SECTION-1 Lid CD section (See page 6-7) Cabinet (rear) section-2 (See page 6-6) SP901 - 8 3 J901 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 3-069-046-01 SCREW (Y) (DIA. 1.7X5.5) 1-961-144-11 HARNESS (FS-140) 3-070-017-01 STAY, PO SPRING 3-068-496-01 PIN (DIA.

  • Page 119: Cabinet (Rear) Section-2

    6-1-6. CABINET (REAR) SECTION-2 PL902 supplied supplied PL901 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 3-068-467-01 SPRING, CD OPENER 3-068-536-01 KNOB (M), MODE (CD200) 3-914-366-01 SCREW (DIA. 1.7X4), PRECISION * 270 3-064-250-01 SPRING, F BUTTON 3-068-470-01 COVER, SOLENOID 3-067-942-01 BUTTON, FUNCTION (CD300) 3-068-469-01 SPRING, CD LOCK LEVER...

  • Page 120: Lid Cd Section

    6-1-7. LID CD SECTION LCD901 supplied ND901 - 5 8 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 3-914-366-01 SCREW (DIA. 1.7X4), PRECISION X-3951-644-1 LID ASSY, CD (CD300) 3-068-459-01 LID, CD REAR X-3951-654-1 LID ASSY, CD (CD200) A-7074-838-A PK-58 (SH) BOARD, COMPLETE LCD901 1-803-858-22 INDICATOR MODULE LIQUID CRYSTAL 1-681-547-11 FP-363 FLEXIBLE BOARD...

  • Page 121: Electrical Parts List

    CD-333 CD-334 6-2. ELECTRICAL PARTS LIST NOTE: • Due to standardization, replacements in the • RESISTORS When indicating parts by reference number, parts list may be different from the parts All resistors are in ohms. please include the board name. specified in the diagrams or the components METAL: metal-film resistor The components identified by mark 0 or...
  • Page 122 CD-333 CD-334 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks C323 1-125-777-11 CERAMIC CHIP 0.1uF FB220 1-414-229-11 FERRITE C401 1-107-690-11 TANTAL. CHIP 6.8uF 20.00% 35V FB221 1-414-229-11 FERRITE (CD300) FB222 1-414-229-11 FERRITE C402 1-119-751-11 TANTAL. CHIP 22uF FB223 1-414-229-11 FERRITE...
  • Page 123 CD-333 CD-334 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks < RESISTOR > R306 1-218-961-11 RES-CHIP 4.7K 1/16W (CD200) R101 1-218-977-11 RES-CHIP 100K 1/16W R307 1-218-977-11 RES-CHIP 100K 1/16W (CD200) (CD200) R102 1-218-931-11 RES-CHIP 1/16W R308 1-218-965-11 RES-CHIP 1/16W (CD200)
  • Page 124 CD-333 CD-334 FS-83 JK-208 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks R407 1-218-961-11 RES-CHIP 4.7K 1/16W R009 1-218-959-11 RES-CHIP 3.3K 1/16W (CD300) R010 1-218-989-11 RES-CHIP 1/16W R409 1-218-977-11 RES-CHIP 100K 1/16W R011 1-218-959-11 RES-CHIP 3.3K 1/16W (CD300) R012...

  • Page 125: Pages From 6-14 To 6-24 Are Not Shown

    JK-208 MD-083 SY-67 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks FB111 1-469-084-21 FERRITE A-7074-899-A MD-083 BOARD, COMPLETE (SERVICE) FB112 1-469-084-21 FERRITE ******************************* (Ref.No.;3000 Series) < IC > ************************************************************** IC101 8-759-657-69 IC PDIUSBP11APW,118 A-7074-898-A SY-67 (300) BOARD, COMPLETE (SERVICE) <...
  • Page 126 PK-58 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks A-7074-838-A PK-58 (SH) BOARD, COMPLETE < DIODE > ************************** (Ref.No.;4000 Series) D202 8-719-073-01 DIODE MA111-(K8).S0 D301 8-719-075-15 DIODE MAZT082H08S0 < CAPACITOR > D302 8-719-070-91 DIODE TLSU1008(T05,SOY) D303 8-719-016-74 DIODE 1SS352-TPH3 C201 1-164-943-11 CERAMIC CHIP...
  • Page 127 PK-58 TK-61 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks R208 1-218-950-11 RES-CHIP 1/16W R436 1-208-715-11 METAL CHIP 0.5% 1/16W R209 1-218-961-11 RES-CHIP 4.7K 1/16W R437 1-208-719-11 METAL CHIP 0.5% 1/16W R210 1-208-707-11 METAL CHIP 0.5% 1/16W R438 1-208-715-11 METAL CHIP...
  • Page 128 TK-61 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks < SWITCH > 3-067-952-11 MANUAL,INSTRUCTION (DIRECT CD) (ENGLISH) (CD200:US,CND,AEP,UK,AUS,CN,E,JE,HK/ S502 1-771-331-81 SWITCH, PUSH (1 KEY) (LENS CAP DETECT) CD300:US,CND,AEP,UK,AUS,CN,E,JE,HK) (CD300) 3-067-952-21 MANUAL,INSTRUCTION (DIRECT CD) ************************************************************** (FRENCH/GERMAN) (CD200:CND,AEP,JE/CD300:CND,AEP,JE) ACCESSORIES 3-067-952-31 MANUAL,INSTRUCTION (DIRECT CD) (SPANISH/PORTUGUESE)
  • Page 129 〈 〉 LED ILLUMINATION AXIS FRAME MVC-CD200 MVC-CD300 Take a copy of LED ILLUMINATION AXIS FRAME with a clear sheet for use. — 160 —...
  • Page 130 〈 〉 FOR CAMERA COLOR REPRODUCTION ADJUSTMENT For NTSC mode Take a copy of CAMERA COLOR REPRODUCTION FRAME with a clear sheet for use. MVC-CD200/CD300 — 161 —...
  • Page 131 MVC-CD200/CD300 2001E1600-1 Sony EMCS Co. Kohda TEC 9-929-900-31 ©2001.5 — 162 — Published by PV Customer Center...
  • Page 132 Reverse 992990031.pdf Revision History S.M. Rev. Ver. Date History Contents issued 2001.05 Official Release — —...

This manual is also suitable for:

Mvc-cd300

Table of Contents
