Summary of Contents for Viavi SmartPocket OLP-35V2
- Page 1 OLP-35V2 OLP-35SC OLP-38V2 SmartPocket™ Optical Power Meters Operating manual BN 2333/98.11 2021.01 English...
- Page 2 ITU-T and/or ETSI. Copyright © Copyright 2021 Viavi Solutions Inc. All rights reserved. Viavi and the Viavi logo are trademarks of Viavi Solutions Inc. All other trademarks and registered trademarks are the property of their respective owners.
-
Page 3: Table Of Contents
ONTENTS ONTENTS ....... . 5 NTRODUCTION OLP-35V2/-35SC/-38V2 Optical Power Meters....... . 5 Operating manual update . - Page 4 ONTENTS ....28 XPORT AND IRMWARE PDATE USB and SmartReporter ......28 Bluetooth®...
-
Page 5: Introduction
UPP adapter for 1.25 and 2.5 mm ferrules (OLP-35V2/-38V2 only). A suitable optical source is required for measuring attenuation. The Viavi OLS-3x and OLS-3xV2 Optical Light Sources are ideal for this application. Both modulated and unmodulated light signals can be measured. -
Page 6: Operating Manual Update
InGaAs Operating manual update If the operating instructions about features provided by your device are missing, please visit the Viavi web site to check if additional information is available. To download the latest operating instructions: Visit the Viavi web site at www.viavisolutions.com . -
Page 7: Symbols Used In This Operating Manual
NTRODUCTION YMBOLS USED IN THIS OPERATING MANUAL Symbols used in this operating manual Various elements are used in this operating manual to draw attention to special meanings or important points in the text. Symbols and terms used in warnings The following warnings, symbols and terms are used in this document in compliance with the American National Standard ANSI Z535.6-2011: NOTICE... - Page 8 NTRODUCTION YMBOLS USED IN THIS OPERATING MANUAL Warning format All warnings have the following format: WARNING Type and source of danger Consequences of ignoring the warning Action needed to avoid danger. The following character formats are used in this operating manual: Requirement This requirement must be met first;...
-
Page 9: Safety Information
AFETY NFORMATION ARNING SYMBOLS ON THE DEVICE AFETY NFORMATION Warning symbols on the device Warning symbols indicating a potential hazard A warning symbol on the device indicates a potential hazard. In all cases where the a warning symbol is shown on the display or labeled on the device, the operating manual must be consulted to learn more about the nature of the potential hazard and any actions that have to be taken. -
Page 10: Laser Safety
AFETY NFORMATION ASER SAFETY Laser safety WARNING Dangerous laser radiation Laser radiation can cause irreparable damage to the eyes and skin. The maximum permitted power for the OLP-3xV2 means that the optical input signals can reach Hazard Level 4, depending on the device type. -
Page 11: Ventilation
AFETY NFORMATION ENTILATION WARNING Explosion danger Dry batteries must not be recharged. The OLP-3xV2 does not have a recharge function for rechargeable batteries, so there is no danger when using dry batteries. Read the manual of the external charging device. Ventilation NOTICE Insufficient ventilation... -
Page 12: Getting Started
If there is damage, do not attempt to operate the device. Doing so can cause further damage. In case of damage, please contact your local Viavi Sales Company. Addresses can be found at www.viavisolutions.com. Recover y following storage/shipping Condensation can occur if a device that is stored or shipped at a low temperature is brought into a warm environment. -
Page 13: Device Overview
ETTING TARTED EVICE OVERVIEW Device overview OLP-35SC OLP-35V2 Test head cover UPP (OLP-35V2/38V2), SC Adapter (OLP-35SC) Display Key pad Representation in the user manual: [] Context sensitive keys (here left key is selected) [MODE] Mode/Settings key Save/Results key Power key USB interface For power supply and measurement data downloads and updates. -
Page 14: Power Supply
ETTING TARTED OWER UPPLY Keys The key pad contains two types of keys: • Contex t sensitive keys: The functions of these keys depend on the selected mode or menu and is shown in the display above the key. • Function keys: The functions of these keys are always the same and shown on the key itself. - Page 15 ETTING TARTED OWER UPPLY Battery operation WARNING Dangers in handling batteries Handling batteries may be dangerous. Please note the following safety instructions. Please note the battery operation safety information in the section “Battery operation” on page 10 . Replacing the batteries Do not replace individual batteries.
- Page 16 Any dry or rechargeable batteries that you purchased from Viavi can be returned to one of our Service Centers for disposal. Operation from AC power To fit one of the mains plug adapters: See Fig.
-
Page 17: Operation
PERATION WITCHING THE DEVICE ON PERATION Switching the device on/off The OLP-3xV2 has two battery power modes: Mode Icon Description Permanent ON The device is switched on (PERM) permanently. Automatic OFF The device switches off 20 minutes (ECON) after the last operation. This function is only available when the device is powered from batteries. -
Page 18: Display Elements
PERATION ISPLAY ELEMENTS Display elements The following elements can be found in the display. - - Display of one value in Auto mode. Display of two values in Multi mode. 1 – Status bar Expert/ Selected/active mode OptiChek [MODE] The mode can be changed via the key. -
Page 19: Settings Menu
PERATION ETTINGS MENU Settings menu The following settings can be changed in the settings menu. To open the settings menu long press [MENU]. Item Settings Description 1...12 Press [ ] to change Hour setting: 1...59 – Press once to change one Minute step at a time. - Page 20 PERATION ELECTING A WAVELENGTH The wavelengths that can be selected by pressing this key are an extract of those contained in the internal wavelength table. Wavelength 1 Wavelength 2 Wavelength 3 Wavelength 4 Wavelength 5 Wavelength 6 Fig. 2 Wavelength entries Editing the wavelength table The wavelength table supports the definition of up to 6 wavelengths.
-
Page 21: Selecting An Operating Mode
PERATION ELECTING XPERT HEK MODE Selecting Ex pert/OptiChek mode The OLP-3xV2 provides two operating modes: Expert All functions are available, like selecting a wavelength and loss measurement. Use this mode for in depth evaluation of your test environment. All following described functions are available in Expert mode only. -
Page 22: Absolute Power Level Mode
PERATION BSOLUTE POWER LEVEL MODE Absolute power level mode The power level is displayed in dBm or Watts (nW, µW, mW). Long press [] to toggle dBm/Watts. NOTE: The context sensitive field shows the selected unit. Display range Model BN... Watt OLP-35V2 2333/12... -
Page 23: Pass/Fail Mode
PERATION AIL MODE Pass/Fail mode An integrated pass/fail analysis feature simplifies standard conformity testing and provides unambiguous measurement result presentation. The OLP-3xV2 provides two Pass/Fail modes: • PF Abs: Pass/Fail indication based on a absolute power threshold • PF Loss: Pass/Fail indication based on a loss threshold To select a Pass/Fail mode: Press [] until PF Abs or PF Loss is displayed. -
Page 24: Displaying Modulated Signals
Lambda mode” on page 24 ). Enabling Auto-Lambda mode Auto- is a special feature developed by Viavi that allows you to identify wavelengths automatically. To do this, the signal is modulated at a certain frequency (by a light source equipped with Auto-... -
Page 25: Multi-Lambda Mode
The OLP-3xV2 can receive Multi- signals and display up to three wavelengths simultaneously. To enable Multi- it has to be activated on the optical source, connected with the OLP-3xV2 (e.g. Viavi OLS-34/35/38) and Auto- must be switched on at the OLP-3xV2. Fig. 4... -
Page 26: Memory Management
EMORY ANAGEMENT ENERAL INFORMATION EMORY ANAGEMENT General information The OLP-3xV2 allows you to save the measured power level values in a data memory and recall them as required. Up to 1000 results can be stored. See also “Specifications” on page 31 for additional data NOTE: management tools. -
Page 27: Deleting Measurements
EMORY ANAGEMENT ELETING MEASUREMENTS []/[] Press to browse through the list. Press [ ] to open the highlighted entry. The selected measurement data is displayed. []/[] Press [ ] to return to the list or, press to show next/previous result or press [MODE] to exit. Deleting measurements The device shows the list of saved measurements. -
Page 28: Data Export And Firmware Update
When using the USB interface the SmartReporter allows you to easily transfer stored measurement data to a PC and to update the firmware. The SmartReporter reporting tool is offered by Viavi for free and can be download from: https://updatemyunit.net/ > Application Software. -
Page 29: Maintenance
Do not open the instrument for maintenance or service. Service shall be performed by Viavi trained personnel only. Cleaning the test port It is a good idea to check that the optical connections are clean and to clean them if necessary before starting measurements. -
Page 30: Cleaning The Instrument
AINTENANCE LEANING THE INSTRUMENT Cleaning the instrument If the device gets dirty through use, you can clean it using a soft cloth moistened with a mild solution of detergent. NOTICE Water and cleaning fluids The instrument may be damaged or destroyed if water or cleaning fluids penetrate it. -
Page 31: Specifications
PECIFICATIONS OLP-35V2/-35SC PECIFICATIONS OLP-35V2/-35SC Adjustable wavelength range 800 to 1650 nm (1 nm incr.) Calibrated wavelengths 850 nm, 980 nm, 1310 nm, 1490 nm, 1550 nm, 1577 nm, 1625 nm, 1650 nm Photo diode InGaAs Fiber type 9/125 to 50/125 Display range -65 to +10 dBm Resolution... -
Page 32: General Specifications
UPP 2.5 mm (1.25 mm optional) OLS-35SC Fixed SC both suitable for PC and APC systems 1) Only in conjunction with Viavi OLS-3x Optical Light Sources. 2) BN 2333/12/14 for levels > -50 dBm BN 2333/13 for levels > -35 dBm Memory... -
Page 33: Ordering Information
RDERING INFORMATION EVICES RDERING INFORMATION Devices OLP-35V2 Optical Power Meter InGaAs OLP-35V2 OLP-35SC Optical Power Meter with fixed SC Adapter InGaAs OLP-35SC OLP-38V2 Optical Power Meter, High Power InGaAs (coated) OLP-38V2 Calibration report OLP-35V2, OLP-35SC, OLP-38V2 BN 2333/90.03 Accessories Cleaning materials, power supplies OCK-10 Optical cleaning kit BN 2229/90.21 Cleaning tape for optical connectors... - Page 34 Hazardous materials Viavi avoids or uses with care any hazardous or dangerous material in the manufacturing process or the end product. If the use of a dangerous material cannot be avoided, it is identified in product documentation and clearly labeled on the product itself.
- Page 35 EU Waste Electrical and Electronic Equipment (WEEE) Directive, 2012/ 19/EU, and the EU Battery Directive, 2006/66/EC. Instructions for returning waste equipment and batteries to JDSU can be found in the WEEE section of Viavi's Standards and Policies web page (https://www.viavisolutions.com/en-us/ corporate/legal/policies-standards#sustain).
- Page 36 RODUCT EGULATORY OMPLIANCE OLP-35V2/-35SC/-38V2...
- Page 37 RODUCT EGULATORY OMPLIANCE OLP-35V2/-35SC/-38V2...
- Page 38 North America +1 844-468 4284 Viavi product specifications and descriptions in Latin America +1 954 688 5660 this document are subject to change without China +86 21 6859 5260 notice. Germany +49 7121 86 0 © 2021 Operating manual SmartPocket Optical Power Meters OLP-35V2/-35SC/-38V2 viavisolutions.com...
