Anleitung_Anleitung 10.04.14 09:56 Seite 1
Operating Instructions
electronic pendulum jig saw
EPJ 500-E
Art.-No.: 43.206.02
I.-Nr.: 015r.:

Advertisement

loading
Need help?

Need help?

Do you have a question about the EPJ 500-E and is the answer not in the manual?

Questions and answers

Summary of Contents for Power Craft EPJ 500-E

  • Page 1 Anleitung_Anleitung 10.04.14 09:56 Seite 1 Operating Instructions electronic pendulum jig saw EPJ 500-E Art.-No.: 43.206.02 I.-Nr.: 015r.:...
  • Page 2 Anleitung_Anleitung 10.04.14 09:56 Seite 2 Please read the operating instructions carefully before Please pull out pages 2-3 assembling and using...
  • Page 3 Anleitung_Anleitung 10.04.14 09:56 Seite 3...
  • Page 4: General Safety And Accident Prevention Regulations

    Anleitung_Anleitung 10.04.14 09:56 Seite 4 Description It is prohibited to use the machine on asbestos materials. Please note the accident 1 Power cable prevention regulations in force in your country. 2 Locking button 3 On/Off switch Use only original spare parts. 4 Knurled screw for regulating the speed Repairs are to be carried out by qualified 5 Inspection guard...
  • Page 5: Technical Data

    Anleitung_Anleitung 10.04.14 09:56 Seite 5 Operating instructions for the ten the two screws. The teeth of the saw blade must face in cutting direction. Make sure that the saw EPJ 500 E electronic jig saw blade sits properly in the guide slot of the ram and roller.
  • Page 6 Anleitung_Anleitung 10.04.14 09:56 Seite 6 Turn the speed controller to increase the cutting rate Fitting the inspection guard Inspection guard 0 = no pendulum; used for thin workpiece 1 = low pendulum; used for Important! Wear goggles! thicker workpiece 2 = high pendulum; used for fast cutting Changing the saw blade...
  • Page 7 Anleitung_Anleitung 10.04.14 09:56 Seite 7...
  • Page 8 Anleitung_Anleitung 10.04.14 09:56 Seite 8 Replacement parts drawing EPJ 500-E Art.-No.: 43.206.02, I.-No.: 91019...
  • Page 9 Anleitung_Anleitung 10.04.14 09:56 Seite 9 Replacement parts list EPJ 500-E Art.-No.: 43.206.02, I.-No.: 91019 Item Designation Replacement Part No. Mains cable 43.206.10.03 Anti-kink sleeve 43.206.00.01 Cable grip 43.206.00.02 Left half of case 43.206.00.03 Compression spring 43.206.00.04 Rotary knob 43.206.00.05 43.206.00.06 Circlip ring 43.206.00.07 Bolt 43.206.00.08...
  • Page 10: Warranty Certificate

    Anleitung_Anleitung 10.04.14 09:56 Seite 10 WARRANTY CERTIFICATE The guarantee period begins on the sales date and is valid for 1 year. Responsibility is assumed for faulty construction or material or functional defects. Any necessary replacement parts and necessary repair work are free of charge. We do not assume responsibility for consequential damage.
