Draeger BG4 Maintenance Manual
Draeger Training Department
Dräger PSS BG 4 plus
Reference Only - Material subject to change without notice
WARNING
!
Strictly follow the Instructions for Use.
The user must fully understand and strictly observe the
instructions. Use the product only for the purposes specified
in the Intended use section of this document.
i
Draeger Training 11/16 rev 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSS BG 4 plus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dräger PSS BG 4 plus

Summary of Contents for Dräger PSS BG 4 plus

  • Page 1 Draeger BG4 Maintenance Manual Draeger Training Department Dräger PSS BG 4 plus Reference Only - Material subject to change without notice WARNING Strictly follow the Instructions for Use. The user must fully understand and strictly observe the instructions. Use the product only for the purposes specified in the Intended use section of this document.

  • Page 2: Table Of Contents

    ......20 Cleaning and disinfecting ....20 Dräger PSS BG 4 plus Page 2...
  • Page 3 Content (cont.) - Bench Test Flow Chart ..... - Test It 6100 - Testing a BG4 ..... 37- 49 - RZ 25 - Testing a BG4 ...... 50 -61 - BG4 Test Checklist ......- Isolation Plug Kit ....... 63 - 66 - Isolation Testing / Troubleshooting ...

  • Page 4: For Your Safety

    Do not use a faulty or incomplete product. Do not modify  the product. Notify Dräger in the event of any product or component  fault or failure. Dräger PSS BG 4 plus Page 4 Draeger Training 11/16 rev 1...
  • Page 5 Fig A Fig. B 33321851_us Dräger PSS BG 4 plus Page 5 Draeger Training 11/16 rev 1...

  • Page 6: Description

    Functional description 2.2.1 Closed-circuit breathing apparatus Product overview The PSS BG 4 plus closed-circuit breathing apparatus is a regeneration unit with pure oxygen supply in excess pressure 2.1.1 Closed-circuit breathing apparatus version. A positive pressure in the breathing circuit prevents ambient air from entering the system.

  • Page 7: Intended Use

    The left button can be used to switch on the backlight for 5 seconds. The ambient temperature can be displayed using the right button. Dräger PSS BG 4 plus Page 7 Draeger Training 11/16 rev 1...

  • Page 8: Restrictions To The Usage Period

    (If the cylinder is not filled  to capacity, usage time is reduced proportionately. The cylinder pressure should amount to at least 2600 psi / 180 bar.) Dräger PSS BG 4 plus Page 8 Draeger Training 11/16 rev 1...

  • Page 9: Explanation Of Symbols And Type-Identifying Marks

    Open cylinder valve! Close cylinder valve! 900 (CP) Country code (information on which cylinder 902 (AP) threaded connection is programmed in the Sentinel): 900: W21.8x1/14" 902: AP 902 Dräger PSS BG 4 plus Page 9 Draeger Training 11/16 rev 1...

  • Page 10: Use

    5. Test the correct functioning of the closed-circuit breathing apparatus (see chapter 3.3.4 on page 12). CAUTION The closed-circuit breathing apparatus may only be used when the functional test has not produced any faults. Dräger PSS BG 4 plus Page 10 Draeger Training 11/16 rev 1...

  • Page 11: Fitting The Compressed Oxygen Cylinder

    2. Ensure that the cylinder mount is adjusted to the diameter loop fastener (1). of the cylinder. 30821851.eps 6. Tension the anti-vibration device and hook it into the hand wheel.(4) Strap should be at 12:00 position. 34621851.eps 30521851.eps Dräger PSS BG 4 plus Page 11 Draeger Training 11/16 rev 1...

  • Page 12: Inserting An Ice Pack

    LEDs flash. The Sentinel automatically powers off and any further operation is impossible. The battery must be replaced 20321851.eps before before any new operation. Dräger PSS BG 4 plus Page 12 Draeger Training 11/16 rev 1...

  • Page 13: Donning The Closed-Circuit Breathing Apparatus

    9. Insert the ends of the waist belt in the loops on the right and left-hand sides. 10. If required, loosen the shoulder straps slightly until comfortable. Dräger PSS BG 4 plus Page 13 Draeger Training 11/16 rev 1...

  • Page 14: During Use

    Sentinel briefly. Instead of the remaining period of use, the temperature is displayed in °C. The display changes back automatically to the remaining period of use. Dräger PSS BG 4 plus Page 14 Draeger Training 11/16 rev 1...

  • Page 15: After Use

    Do not drop the apparatus! 7. Have the closed-circuit breathing apparatus serviced (see chapter 4 on page 16). Dräger PSS BG 4 plus Page 15 Draeger Training 11/16 rev 1...

  • Page 16: Maintenance

    4.5 on page 25 and the connecting piece of which is sealed with the corresponding protective cap. Hydro-testing in accordance with the local requirements. Composite cylinder: Life cycle = 15 years from date of manufacture. Dräger PSS BG 4 plus Page 16 Draeger Training 11/16 rev 1...

  • Page 17: Disassembly Of The Closed-Circuit Breathing Apparatus

    5. Remove the compressed oxygen cylinder from the closed- circuit breathing apparatus and seal with the lock nut. Re-fill the compressed oxygen cylinder 30921851.eps see the instructions for use for the compressed oxygen cylinder Dräger PSS BG 4 plus Page 17 Draeger Training 11/16 rev 1...

  • Page 18: Removing And Testing The Pressure Relief Valve

    6. Take valve disk (5) and O-ring (6) out and check. They must be clean and undamaged. Replace faulty parts. Apply Molykote 111 thinly to the 31421851.eps O-ring. Dräger PSS BG 4 plus Page 18 Draeger Training 11/16 rev 1...

  • Page 19: Removing Breathing Bag, Drain Valve, Minimum Valve And Where Applicable The Water Absorber

    Insert the shaft of the valve disk into the hole. d. Position the springs (10) centrally onto the valve disk. e. Screw the cover on securely. Dräger PSS BG 4 plus Page 19 Draeger Training 11/16 rev 1...

  • Page 20: 4.2.10 Disassembling Waist Belt And Shoulder Straps

    Make sure to follow the procedure that is suitable for your country. For further information please contact Dräger or your local dealer. Part of test set R 33 777 Dräger PSS BG 4 plus Page 20 Draeger Training 11/16 rev 1...

  • Page 21: Cleaning And Disinfecting Procedure For The Usa Only

    Breathing bag and breathing hoses should be dried using the hose drying unit. NOTICE It is important to dry waist belt and shoulder straps before storage to prevent fungus and mold growth. Clean as necessary Dräger PSS BG 4 plus Page 21 Draeger Training 11/16 rev 1...

  • Page 22: Fitting The Breathing Bag

    2. Insert the CO absorber into the carrying frame and fasten to the tensioning bar (5). 3. Attach the breathing bag sleeve onto the CO absorber connecting piece (6). 32521851.eps Dräger PSS BG 4 plus Page 22 Draeger Training 11/16 rev 1...

  • Page 23: Assembling The Connecting Piece

    9. Label the CO absorber: Mark installation date permanently and clearly on the housing. 10. Fit the two springs between the pressure plate on the breathing bag and the spring holder. Dräger PSS BG 4 plus Page 23 Draeger Training 11/16 rev 1...

  • Page 24: 4.4.10 Fitting The Breathing Hoses

    6 months, even if breathing bag, breathing hose and pressure relief valve are connected and the breathing circuit is sealed with the R 33 588 sealing cap. Dräger PSS BG 4 plus Page 24 Draeger Training 11/16 rev 1...

  • Page 25: Testing Of The Closed-Circuit Breathing Apparatus

    L/min 34921851.eps 1 Display 2 Selector switch 3 Pump 4 Switch for venting 5 Connection for closed-circuit breathing apparatus 6 Connecting piece 7 Protective cap Dräger PSS BG 4 plus Page 25 Draeger Training 11/16 rev 1...

  • Page 26: Preparation Of Test

    Read the value on the display. The drain valve must open between +15 mbar and +25 mbar. NOTICE The low-pressure warning generated by the Sentinel during this test is irrelevant here. Dräger PSS BG 4 plus Page 26 Draeger Training 11/16 rev 1...

  • Page 27: Performing The Leak Test With Positive Pressure

    Sentinel display. A single alarm tone sounds. The bar chart runs once again from left to right. Only applies at a cylinder pressure of 2600 psi to 2900 psi/ 180 bar to 200 bar. Dräger PSS BG 4 plus Page 27 Draeger Training 11/16 rev 1...

  • Page 28: 4.5.11 Checking The Residual Pressure Warning

    8. Release the buttons. operation is impossible. The Sentinel switches off. The battery must be replaced 20321851.eps before any new operation. Dräger PSS BG 4 plus Page 28 Draeger Training 11/16 rev 1...

  • Page 29: Testing The Functional Capability Of The Sentinel

    With normal use of the Sentinel, the closed-circuit breathing apparatus remains fully functional for up to 4 hours. To ensure safe 20221851.eps usage, the battery should be replaced, however. Dräger PSS BG 4 plus Page 29 Draeger Training 11/16 rev 1...

  • Page 30: Replacing The Pressure Reducer

    They must engage into place. Pull gently on the plugs to check that the medium-pressure hoses fit correctly. 7. Fit the compressed oxygen cylinder (see chapter 3.3.2 on page 11). Dräger PSS BG 4 plus Page 30 Draeger Training 11/16 rev 1...

  • Page 31: Technical Data

    When consuming 30 L/min. Even if the recommended period of use is exceeded, the closed- circuit breathing apparatus will operate correctly. Only the tempe- rature of the inhaled air will increase. Dräger PSS BG 4 plus Page 31 Draeger Training 11/16 rev 1...

  • Page 32: Order List

    Drying cabinet On request absorber (disposable cartridge) R34360 "klar-pilot" anti-fogging fluid R52550 absorber (refillable cartridge, grey, R34277 "klar-pilot" anti-fogging spray R56542 empty) absorber (refillable cartridge, R34367 transparent, empty) Dräger PSS BG 4 plus Page 32 Draeger Training 11/16 rev 1...
  • Page 33 Name and description number Test accessories: Dräger RZ 7000 R62500 Dräger Quaestor 5000 CCBA R58317 Test set PSS BG 4 Plus R33777 Accessories for the Sentinel: IR-Link II (IR-Link cable with RS232 plug and 3351818 IR-Link software) Windows-Software on request...

  • Page 34: Annex

    R58136 R56672 R58138 R27082 B03390 R34320 R57675 B30229 B30230 R34680 R34360 R34277 R57676 R33125 R34367 R34295 R33870 R34299 R57677 R34140 R34152 4057102 3350994 R56197 R33960 R57678 R34600 R56670 Dräger PSS BG 4 plus Page 34 Draeger Training 11/16 rev 1...

  • Page 35: Bench Test Flow Chart

    Flow Chart - Testing a BG4 - Training Reference Only "Low Pressure Warning" "High Pressure Leak Test" "Check Battery Life" Positive Pressure Leak Test (optional) <1.4 mbar "Inhalation Valve" "Exhalation Valve" "Relief Valve" Positive Pressure Negative Pressure Positive Pressure Crimp Exhalation Hose Crimp Inhalation Hose Pump to Activate >10 mbar...
  • Page 36 Dräger Safety AG & Co. KGaA Revalstraße 1 23560 Lübeck, Germany Tel +49 451 882 0 Fax +49 451 882 20 80 www.draeger.com Subject to alteration Page 36 Draeger Training 11/16 rev 1...

  • Page 37: Test It 6100 - Testing A Bg4

    Test-it 6100 - BG4 Testing (discontinued replaced with RZ7000) Page 37 Draeger Training 11/16 rev 1...
  • Page 38 Testing Testing Before starting up for the first time and whenever the PSS BG 4 has been serviced. Testing the PSS BG 4 with Inserted Absorber During the shelf life of the apparatus (see table “Technical Data” on page 66, section CO absorber (factory-packed cartridge with footnotes 4 and 5 and refill cartridge with footnotes 5 and 7)) the operating test can be run a total of six times, each test lasting no...
  • Page 39 Testing Preparing for Tests Align the zero point of test unit. Note the Instructions for Use of the test unit. Test Setup Position the PSS BG 4 on the left and the test unit on the right. This ensures that the closed-circuit breathing apparatus is easily accessible to the tester and the test unit can be operated without difficulty.
  • Page 40 Testing Checking the Response Threshold of the Low Pressure Warning The function test for low pressure warning should only be carried out after the Sentinel has been switched off. 1 Screw the test adapter R 50 028 into the connector of the test unit.
  • Page 41 Testing Checking the Inhalation Valve 1 Tightly pinch the exhalation hose with your hand. Use peg spanner 16 28 089 of test set R 33 777 if required. 2 Pump slowly until 3 at least 10 mbar are indicated on test unit. If the system does not reach 10 mbar: Replace inhalation valve or exhalation valve disc (see “Fit- ting the Plug-in Coupling”...
  • Page 42 Testing Checking the Drain Valve Connect pressure side of the pump to the test unit. 1 Continue pumping 2 until at least 10 mbar are indicated on the test unit. While pumping: 3 Fit the open side of sealing cap R 22 086 over the tappet of the relief valve and hold it tightly until it is pressed into place by the inflated breathing bag.
  • Page 43 Testing Checking the Relief Valve 1 Open shut-off valve at the test unit. 2 Pump slowly until 3 the relief valve opens (flow sound). 4 The opening pressure indicated at the test unit should amount to 2 to 5 mbar. Disconnect pump from the test unit.
  • Page 44 Testing When the cylinder pressure is over 2600 psi/165 bar: — Icon "Close cylinder valve" appears on the display. 2x Bleep — Alarm bleeps two times. Close the cylinder valve. — The bar graph counts down (left to right). When the display shows 165 bar, the high-pressure leak test 1x Bleep starts: The "remaining period of use"...
  • Page 45 Testing Checking the Constant Metering Valve 1 Connect pump connection and flow connection of the test unit using the flow hose. 2 Set test unit so that it indicates the flow (display shows "l/min"). 3 Open the shut-off valve at the test unit. 4 Fit the open side of the sealing cap R 22 086 over the tap- pet of the relief valve and hold it tightly until it is pressed into place by the inflated breathing bag.
  • Page 46 Testing Checking the Bypass Valve 1 Close the shut-off valve at the test unit. on the rear: 2 Press the red button for the bypass valve slightly. Oxygen must be heard to flow into the circuit (flow noise). 3 The breathing bag inflates. Page 46 Draeger Training 11/16 rev 1...
  • Page 47 Testing Checking the Residual Pressure Warning 1 Close the cylinder valve. 2 Watch the Sentinel. A warning should be generated at approx. 700 psi/ 55 bar. The acoustic alarm sounds intermittently and the red LEDs flash. 3 Unplug the coupling from the test unit and put the sealing cap on the plug-in coupling.
  • Page 48 Testing Symbol "Battery warning 2" 5x Bleep — In this case the red LEDs flash constantly. On power up 5 short beeps will sound and the display will show the "Battery warning 2" icon. Sentinel automatically powers off and any further operation is impossible.
  • Page 49 Storage Completion of Testing DANGER The PSS BG 4 is only ready for use when all the above pre- parations are complete! If one test failed, the PSS BG 4 must not be used. In this case , it must be serviced by trained personnel or by Dräger Safety prior to the next use.

  • Page 50: Rz 25 - Testing A Bg4

    Draeger Safety, Inc. Testing with an RZ 25 (replaced with RZ 7000) Before starting up for the first time and whenever the PSS BG 4 has been serviced. Testing the PSS BG 4 with Inserted Absorber During the shelf life of the apparatus (see table “Maintenance Intervals”, section CO2 absorber (factory-packed cartridge) with footnotes 1 and 2) the operating test can be run a total of six times, each...
  • Page 51 Draeger Safety, Inc. Checking the Response threshold of the Low Pressure Warning NOTE The function test for low pressure warning can only be carried out after the Sentinel has been switched off. 1 Screw the test adapter into the connector of the test unit RZ 25.
  • Page 52 Draeger Safety, Inc. Checking the Inhalation Valve 1 Set “set positive pressure pumping”. 2 Tightly pinch the exhalation hose with your hand. 3 Start pumping slowly until 4 10 mbar is indicated on the pressure gauge. If the system does not reach 10 mbar: •...
  • Page 53 Draeger Safety, Inc. Checking the Drain Valve 1 Set “positive pressure pumping”. 2 Continue pumping until 10 mbar is indicated on the pressure gauge. While pumping: 3 Fit the open side of the sealing cap over the tappet of the relief valve and hold it tightly until it is pressed into place by the inflated breathing bag.
  • Page 54 Draeger Safety, Inc. Check Relief Valve 1 Set “positive pressure pumping”. 2 Continue pumping until 3 the relief valve opens. 4 Read off the opening pressure on the pressure gauge: It should lie between 2 and 5 mbar. The low-pressure warning generated by the Sentinel during this test is irrelevant here.
  • Page 55 Draeger Safety, Inc. High-Pressure Leak Test 1 Set “Leak test”. 2 Open the cylinder valve. 3 Watch the Sentinel: the cylinder pressure is indicated here. If cylinder pressure is lower than 2600 psi / 180 bar: • Charge the oxygen cylinder. When the cylinder pressure is over 2600 psi / 180 bar: –...
  • Page 56 Draeger Safety, Inc. Checking the Constant Dosage Valve 1 Set “positive pressure pumping”. 2 Continue pumping until the breathing bag has inflated. 4 While pumping, fit the open side of the sealing cap over the tappet of the relief valve and hold it tightly until it is pressed into position by the inflated breathing bag.
  • Page 57 Draeger Safety, Inc. Checking the Bypass Valve 1 Set “Leak test”. on the rear: 2 Press red button of the bypass valve slightly. – Oxygen must be heard to flow into the circuit (flow noise). 3 The breathing bag inflates. PSS BG 4 Service Manual Page 57 Draeger Training 11/16 rev 1...
  • Page 58 Draeger Safety, Inc. Checking the Residual Pressure Warning • Close the cylinder valve. 1 Watch the Sentinel. A warning should be generated at approximately 700 psi / 48 bar. The acoustic alarm sounds intermittently and the red LEDs flash. 2 Unplug the coupling from the test unit RZ 25 and replace the sealing cap on the plug-in coupling.
  • Page 59 Draeger Safety, Inc. Checking the Battery Capacity On activation and deactivation the Sentinel automati- cally checks and displays the battery capacity. There are three icons used to represent the capacity left in the battery. Symbol “Battery OK” Battery does not need to be replaced. Symbol “Battery warning 1”...
  • Page 60 Draeger Safety, Inc. Switching Off the Sentinel • Simultaneously press the right and left hand button until a single sharp audible “bleep” sounds. • Release buttons. • For 3 seconds Sentinel shows the battery status. • Sentinel switches off. Completion of Testing DANGER! The PSS BG 4 is only ready for use when all the above preparations are complete!
  • Page 61 Draeger Safety, Inc. Closing the Protective Cover • First slide in rim of lip, then hook the two plugs at the bottom edge of protective cover. • Close protective cover, then • Tilt the two sliding bolts to the front and •...

  • Page 62: Bg4 Test Checklist

    Draeger Safety, Inc. Date ____________ BG4 Test Checklist Backplate serial no. _______________________ Mask serial no. ___________________________ Cylinder serial no. _________________________ Hydrotest _________________________________ Monitron Battery Installation _________________ Visual Inspection _______________ Tech. Initial Cylinder Pressure _______________ PSI/BA Low Pressure Warning _______________ Tech. Initial Inhalation Valve _______________ Tech.

  • Page 63: Isolation Plug Kit

    Page 63 Draeger Training 11/16 rev 1...
