  • Page 1 Switched Mult 1U Chainable, Passive Switched Multiplier Manual (English) Revision: 2021.03.21...
  • Page 2 TABLE OF CONTENTS   COMPLIANCE INSTALLATION OVERVIEW FRONT PANEL BACK PANEL TECHNICAL SPECIFICATIONS     Switched Mult 1U Manual...
  • Page 3 (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by Intellijel Designs, Inc. could void the user’s authority to operate the equipment. Any digital equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 4 INSTALLATION   This module is designed for use within an Intellijel-standard 1U row, such as contained within the Intellijel 4U, 7U and Palette Eurorack cases. Intellijel’s 1U specification is derived from the Eurorack mechanical specification set by Doepfer that is designed to support the use of lipped rails within industry standard rack heights.
  • Page 5 In order to accomplish this, you need a signal multiplier. In addition, each Switched Mult 1U features a pair of 3-pin Link connectors on the rear panel. These let you connect other 3-pin Link devices, such as an XY I/O 1U module, or even additional Switched Mult 1U modules (handy for distributing mults across the width of your case).
  • Page 6 X input (jack 1 ); if you were to switch jack 6 to the Y position (down), it will carry a mult of the Y input (jack 2 ). Switched Mult 1U Manual...
  • Page 7 3-pin Link connectors on the back of the Switched Mult 1U . Now, any signal patched into the X jack on the XY I/O 1U is multed to any Switched Mult 1U jacks that have their Bus Switches set to the X (up) position. Similarly, any signal patched into the Y jack on the XY I/O 1U is multed to any Switched Mult 1U jacks that have their Bus Switches set to the Y (down) position.
