FIGURE 9
DIMM0
DIMM2
DIMM1
DIMM3
DIMM fault
LEds in ejector
levers
Fault Remind
button
LEDs CR6,
CR7, and CR8
Pressing the Fault Remind button lights LEDs that indicate faulty CPU and DIMM.
See"Locating Faulty CPUs and DIMMs" on page 39
LEDs are described in
Physical Layout of Sun Fire X4600 CPU Module
TABLE 3
Module Fault LED (CR5)
Sun Fire X4600 to Sun Fire X4600 M2 Server Migration
