Ross ACO-2200 User Manual

Automatic changeover system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ACO-2200 User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACO-2200 and is the answer not in the manual?

Questions and answers

Related Manuals for Ross ACO-2200

Summary of Contents for Ross ACO-2200

  • Page 1 ACO-2200 User Guide...
  • Page 2 Ross has become well known for the Ross Video Code of Ethics. It guides our interactions and empowers our employees. I hope you enjoy reading it below. If anything at all with your Ross experience does not live up to your expectations be sure to reach out to us at solutions@rossvideo.com.
  • Page 3 Ross Video. While every precaution has been taken in the preparation of this document, Ross Video assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein.
  • Page 4 Maintenance/User Serviceable Parts Routine maintenance to this Ross Video product is not required. This product contains no user serviceable parts. If the module does not appear to be working properly, please contact Technical Support using the numbers listed under the “Contact Us”...

  • Page 5: Table Of Contents

    Initial Product Inspection ............................13 Operating Environment Requirements ........................13 Rack Mount Installation ............................14 Installing the ACO-2200 into a Rack Unit ......................14 Installing the Rear Support Brackets ........................ 14 Connecting Power ..............................15 Setting the Initial IP Address ..........................15 Configuring the DIP Switches ..........................
  • Page 6 Operating Modes ..............................25 Fault Reporting ...............................25 Software Field Upgrades ............................25 Uploading the Software Files ..........................25 DashBoard Menus Slot 0 - ACO-2200 Tabs ............................27 System Report Tab ..............................27 Events Tab ................................27 Temperature Tab ..............................28 Status Tab ................................28 PSU Status Tab ..............................28 Slot 1 - Channel Setup Tabs ...........................29...

  • Page 7: Introduction

    Introduction This guide covers the installation, configuration, and use of the ACO-2200 Automatic Changeover System. The following chapters are included: • “Introduction” summarizes the guide and provides important terms, and conventions. • “Before You Begin”provides a brief product overview and installation requirements for the ACO-2200.

  • Page 8: Important Instructions

    IP Address, Subnet Mask, and Gateway for your ACO-2200. Contacting Technical Support At Ross Video, we take pride in the quality of our products, but if problems occur, help is as close as the nearest telephone.

  • Page 9: Before You Begin

    ACO-2200 also provides internal termination for unswitched BNC inputs. The ACO-2200 includes 6 channels in a 1U rack. Each BNC channel consists of a Primary Input, a Backup Input, and an Output. All BNC channel relays switch in unison upon fault detection in any active BNC channel, front-panel command, or remote command.

  • Page 10: Functional Block Diagram

    Functional Block Diagram This section provides the functional block diagram that outlines the workflow of the ACO-2200. Primary Input RELAY Output Secondary Input Auto / Manual Operating Status/ LOGIC Fault Indications DECODE DISPLAY Primary / Backup BACKUP PRIMARY PEAK PEAK...

  • Page 11: Hardware Overview

    Hardware Overview This chapter outlines the basics of operating the ACO-2200. Front Panel Overview Figure 3.1 shows the ACO-2200 Front Panel. Descriptions of the Front Panel controls and indicators appear below. ACO-2200 CHANGEOVER AUTO PRIMARY LOCK FAULT MANUAL BACKUP UNLOCK...
  • Page 12 After installation, it may be used to upload software updates. 3. DIP Switches Use the DIP switches to force the IP Address and Subnet Mask for the ACO-2200 to known values. 4. PSU Connectors The ACO-2200 is designed to operate from an external +12VDC power source. A safety earth stud is provided for earth bonding the chassis if you so require.

  • Page 13: Physical Installation

    Always exercise proper grounding precautions when working on circuit boards and related equipment. Unpacking Unpack each ACO-2200 you received from the shipping container and ensure that all items are included. If any items are missing or damaged, contact your sales representative or Ross Video directly. Initial Product Inspection Perform the following Initial Product Inspection Procedure when you receive your ACO-2200: Inspect the shipping carton for external damage, which may indicate possible damage to the ACO-2200.

  • Page 14: Rack Mount Installation

    Rack Mount Installation You can install the ACO-2200 into an equipment rack. It is recommended to loom the cables so that they do not introduce extra weight or twisting force on the front panel rack mountings or rear panel connectors. If installed in a mobile application, the rack mount kit is essential.

  • Page 15: Connecting Power

    Figure 4.2 DIP Switches on ACO-2200 Rear Panel are used in conjunction with the DashBoard menus to set the IP Address of the ACO-2200. Refer to Table 4.1 and the rear panel labeling for DIP Switch positions. Table 4.1 SW1 and SW2 Positions...

  • Page 16: Accessories And Options

    A Documentation Resources disk is included with your ACO-2200. DC Power Supply Bricks Two +12V DC, 4A power supply bricks with suitable connectors are supplied with the ACO-2200. Power Cords All ACO-2200 are shipped with one of the following power cord options: •...

  • Page 17: Functional Check Procedures

    Functional Check Procedures Perform the following procedures if you are operating the ACO-2200 for the first time (to verify that the ACO-2200 shipped without damage), or you suspect that the ACO-2200 is not working properly. Required Equipment The following equipment is required for the functional check: •...

  • Page 18: Recommendation

    This is especially true of the Calibration menu, where settings relating to the fundamental operation of each individual ACO-2200 are stored. If memory corruption occurs, some or all of the settings may need to be re-instated.

  • Page 19: Using Dashboard

    The New TCP openGear Frame Connection dialog opens. Type the IP address of the ACO-2200 in the IP Address field. Type a unique name for the ACO-2200 in the Display Name field. This name makes the ACO-2200 easily identifiable in the Tree View.

  • Page 20: Initial Configuration

    To ensure that you have a suitable channel configuration for the purposes of this Functional Check, you should perform the following procedures. The procedures in this section assume that you have launched the DashBoard client and the ACO-2200 is displayed in the Tree View.

  • Page 21: Performing Functional Checks

    Select the channel type from the drop-down menu. For initial configuration, select Color Black. Performing Functional Checks The procedures in this section assume that you have launched the DashBoard client and the ACO-2200 is displayed in the Tree View. ACO-2200 User Guide (v5.0)

  • Page 22: Normal Operation (No Faults)

    Select the Configuration tab. c. Use the Changeover Mode menu to select Backup. The channel output switches to the Backup signal (Analog Color Black). Re-connect the Primary input signal (Composite Video). From DashBoard: 22 • Functional Check Procedures ACO-2200 User Guide (v5.0)

  • Page 23: Loss Of Power

    “Input Missing” errors will always be reported, leading to inconsistent operation. You can now connect your signals to the ACO-2200 rear panel BNCs (Figure 5.2 as an example), according to the configuration settings made in the previous paragraph. The example in Figure 5.2 shows six channels from the list of supported signal types ACO-2200 User Guide (v5.0)
  • Page 24 Primary 6 Backup 6 Figure 5.2 Example of ACO-2200 Connections You should produce a master reference sheet, in order to log how each channel is configured and connected (an example is shown below in Table 5.1). This will be helpful to refer to in the future in order to quickly find out whether, for example, a previously unused channel requires a menu change relating to the new signal to be monitored.

  • Page 25: Operating Basics

    Operating Basics Overview The ACO-2200 can be thought of as an automatic multi-pole switch that actuates whenever an error is detected in any BNC signal channel. All channels will switch at the same time. Any unused BNC input channel should be configured to disable error checking. If unused channels are not disabled, they will always produce error signals leading to improper operation.
  • Page 26 ” displays in the window. is in BOOT_mode. If the ACO-2200 is “not found”, check again that all connections have been made then try repeating the above procedure after powering down the ACO-2200, and then resuming from the update program start-up line.

  • Page 27: Dashboard Menus

    ACO-2200. Events Tab The Events tab provides access to the last 99 events recorded by the ACO-2200. These events may relate to normal expected functionality or to systemic errors. This information might be useful in monitoring and diagnosing a system problem outside the ACO-2200, or a reliability problem within the ACO-2200.

  • Page 28: Temperature Tab

    PSU Status Tab The PSU Status tab, located on the right side of the Slot 0 - ACO-2200 interface in DashBoard, displays read-only values for the number of times each power supply has been cycled, and the running hours count.

  • Page 29: Slot 1 - Channel Setup Tabs

    • Recovery Delay in HHMMSS — indicates how much time optional recovery delay is set for. • Recovery Delay Countdown — when a fault occurs and is then fixed, if the ACO-2200 is set to auto recovery after delay, this timer shows the time until the ACO-2200 switches back to the Primary SRG-2200.

  • Page 30: Channels 1-6 Tab

    SRG-2200 Slot 16 - System Setup Tabs Select the Slot 16 - System Setup node to view the operational status of the ACO-2200, configure and monitor Network settings and status. It is also possible to view the factory Calibration settings.

  • Page 31: Network Tabs

    The Ethernet tab allows the user to configure and control the behavior of the Ethernet system within the ACO-2200. Before proceeding, the user must contact their Network Administrator, and obtain suitable IP addresses, etc., that will need to be programmed within this menu.

  • Page 32: Calibration 01 - 06 Tab

    Calibration 01 - 06 Tab The Calibration 01-06 tab enables the user to see the factory calibration data for the ACO-2200. Figure 7.4 Example of Calibration 01-06 Tab 32 • DashBoard Menus ACO-2200 User Guide (v5.0)

  • Page 33: Technical Specifications

    “Environment Characteristics” on page 34. • The ACO-2200 must have a warm-up period of at least 20 minutes. • The ACO-2200 must have been calibrated and adjusted at an ambient temperature between +20°C and +30°C. BNC Channels Table 8.1 Technical Specifications —...

  • Page 34: Ethernet Interface

    Height 43.5 mm (1.71”) Width 482.5 mm (19.00”) Depth 235 mm (9.25”) Environment Characteristics Table 8.6 Technical Specifications — Environmental Category Performance Requirement Temperature Operating 0°C to +40°C Non-operating -20°C to +60°C 34 • Technical Specifications ACO-2200 User Guide (v5.0)
  • Page 35 Vibration Operating 2.65m/s2 (0.27Grms), 5Hz to 500Hz, 10 minutes per axis, three axes Non-operating 22.3m/s2 (2.28Grms), 5Hz to 500Hz, 10 minutes per axes, three axes Shock Non-operating 294m/s2 (30G), half-sine, 11ms duration ACO-2200 User Guide (v5.0) Technical Specifications • 35...
  • Page 36 36 • Technical Specifications ACO-2200 User Guide (v5.0)

  • Page 37: Service Information

    Service Information Generally speaking, the ACO-2200 is reliable under normal steady-state operating conditions. If you are having problems, select the symptom from the list in this chapter that closely relates to your particular problem, and perform the checks / actions listed.

  • Page 38: Preventive Maintenance

    If your problem cannot be resolved, contact Ross Video for further advice. If you ordered a Service Option, then removing the unit from the bay and returning it to Ross Video for updating will provide the user with the opportunity to inspect the unit for any problems relating to the operating conditions/environment.

  • Page 39: Troubleshooting Checklist

    Troubleshooting Checklist Routine maintenance to this Ross Video product is not required. In the event of problems with your ACO-2200, the following basic troubleshooting checklist may help identify the source of the problem. If the frame still does not appear to be working properly after checking all possible causes, please contact your Ross Video products distributor, or the Technical Support department at the numbers listed under the “Contact Us”...
  • Page 40 Ross Video Limited will be shipped collect. The Ross Video Technical Support Department will continue to provide advice on any product manufactured by Ross Video Limited, beyond the warranty period without charge, for the life of the equipment.

  • Page 41: Glossary

    • “GLONASS” refers to the Global Navigation Satellite System. • “GPS” refers to global positioning system. • “Operator” and “User” refer to the person who uses ACO-2200. • “RF interference” refers to radio frequency interference • “System” and “Video system” refer to the mix of interconnected production and terminal equipment in your environment.
  • Page 42 42 • Glossary ACO-2200 User Guide (v5.0)
