Alfresco ALX2-30 Specifications

ALX2 SERIES GRILL SPECIFICATIONS
ALX2-30
ALX2-30C
ALX2-30SZ
ALX2-30SZC
ALX2-30IR
ALX2-30IRC
LX2
30 INCH ALX2 GRILLS
54"
30"
12"
35 1/2"
30 INCH GRILLS
28 1/4"
26 7/8"
15 3/8"
57 1/2"
50 1/2"
36"
1 5/16"
END VIEW
MODEL NUMBER
GRILLING AREA
MAIN GRILL BURNERS
ROTISSERIE BURNER
SMOKER BURNER
APPLIANCE TOTAL BTU
SHIPPING WEIGHT (built-in)
SHIPPING WEIGHT (on cart)
7039 East Slauson Avenue Commerce, CA 90040
PH: (323)-722-7900 FAX: (323) 726-4700 Toll Free (888) 383-8800
ALX2-42
ALX2-42C
ALX2-42SZ
ALX2-42SZC
42 INCH ALX2 GRILLS
12"
12"
42 INCH GRILLS
FRONT VIEW
21 1/2"
10"
8 3/4"
gas connection
REAR VIEW
ALX2-30
5 4 2 SQ. INCHES
2 @ 2 7, 5 0 0 BTU EA.
1 5, 0 0 0 BTU
7, 0 0 0 BTU
7 7, 0 0 0 BTU
1 8 5 lbs
3 0 5 lbs
Alfresco Open Air Culinary Systems
www.alfrescogrills.com
LX2
66"
42"
12"
47 1/2"
6 ft. power cord std.
6 1/2"
7"
ALX2-42
7 7 0 SQ. INCHES
3 @ 2 7, 5 0 0 BTU EA.
1 8, 0 0 0 BTU
7, 0 0 0 BTU
1 0 7, 5 0 0 BTU
2 6 5 lbs
3 9 5 lbs
ISLAND PREPARATION
Open To Floor
Recommended
30 " grills 28 - 1/2"
42 " grills 40 - 1/2"
- 7/8"
COUNTERTOP DETAIL
GAS REQUIREMENTS
Natural
1 / 2" NPT
Gas Supply Pressure: 0.0" W.C
Propane (LP)
1 / 2" NPT
Supply Pressure: 11" W.C
LP Hose With Regulator Included
ELECTRICAL REQUIREMENTS
115 V 50/60 Hz / 1.5 Amps (for Rotisserie Motor
and light accessory)
"Create The Ultimate Outdoor Kitchen"
ACCESSORIES & OTHER PRODUCTS
Heavy Duty Vinyl Cover (recommended)
Drop-in Steamer Fryer
Drop-on Stainless Steel Griddle
Cart Mount Double Side Burner
Drop-on Griddle For Side Burner
Stainless Steel Access Doors For Islands
Stainless Steel Storage Drawers
Built-in Sterno-fired Food Warmers
Prep & Waste Centers For Island Installations
Plating & Garnish centers
Warming Drawers
Built-in & Cart Model Cocktail Stations
Built-in Prep & Hand Sink
Refrigerator / Keggerator
Under-Grill Refrigerator w/ Marinating Drawers
Built-in Countertop Refrigerator
Completely Sealed Dry Storage Pantry Centers
10"
115 V Electrical
Duplex Outlet Req.
Here
Depth Equals
Countertop Overhang
