Alfresco ALX2-56 Specifications

ALX2 SERIES GRILL SPECIFICATIONS
ALX2-56
ALX2-56C
ALX2-56SZ
ALX2-56SZC
56 INCH ALX2 DELUXE GRILLS
80"
42"
12"
61 1/2"
56 INCH LX2 DELUXE GRILLS
28 1/4"
26 7/8"
15 3/8"
57 1/2"
50 1/2"
36"
1 5/16"
END VIEW
MODEL NUMBER
GRILLING AREA
MAIN GRILL BURNERS
SIDE BURNERS
ROTISSERIE BURNER
SMOKER BURNER
APPLIANCE TOTAL BTU
SHIPPING WEIGHT (built-in)
SHIPPING WEIGHT (on cart)
SHIPPING WEIGHT (w/ refrig.)
Alfresco Open Air Culinary Systems
7039 East Slauson Avenue Commerce, CA 90040
PH: (323)-722-7900 FAX: (323) 726-4700 Toll Free (888) 383-8800
LX2
A56 INCH LX2 BFG GRILLS
14"
12" 12"
LX2
56 INCH LX2 BFG GRILLS
FRONT VIEW
21 1/2"
10"
gas connection
8 3/4"
REAR VIEW
ALX2-5 6
7 7 0 SQ. INCHES
3 @ 2 7 , 5 0 0 BTU EA.
2 @ 17, 0 0 BTU EA.
1 8, 0 0 0 BTU
7 , 0 0 0 BTU
1 7 5 , 5 0 0 BTU
3 1 5 lbs
4 5 5 lbs
6 2 1 lbs
www.alfrescogrills.com
ALX2-56BFG
ALX2-56BFGC
LX2
80"
56"
12"
LX2
61 1/2"
6 1/2"
6 ft. power cord std.
7"
ALX2-5 6 BFG
9 9 8 SQ. INCHES
4 @ 2 7 , 5 0 0 BTU EA.
2 @ 1 5 , 0 0 0 BTU
7 , 0 0 0 BTU
1 4 7 , 0 0 0 BTU
3 2 0 lbs
4 6 0 lbs
6 2 1 lbs
ISLAND PREPARATION
Open To Floor
Recommended
5 4 - 1/2"
- 7/8"
COUNTERTOP DETAIL
GAS REQUIREMENTS
Natural
1 / 2" NPT
Gas Supply Pressure: 0.0" W.C
Propane (LP)
1 / 2" NPT
Supply Pressure: 11" W.C
LP Hose With Regulator Included
ELECTRICAL REQUIREMENTS
115 V 50/60 Hz 1.5 Amps (for Rotisserie Motor
and light accessory)
Create The Ultimate Outdoor Kitchen
ACCESSORIES & OTHER PRODUCTS
Heavy Duty Vinyl Cover (recommended)
Drop-in Steamer Fryer
Drop-on Stainless Steel Griddle
Cart Mount Double Side Burner
Drop-on Griddle For Side Burner
Stainless Steel Access Doors For Islands
Stainless Steel Storage Drawers
Built-in Sterno-fired Food Warmers
Prep & Waste Centers For Island Installations
Plating & Garnish centers
Warming Drawers
Built-in & Cart Model Cocktail Stations
Built-in Prep & Hand Sink
Refrigerator / Keggerator
Under-Grill Refrigerator w/ Marinating Drawers
Built-in Countertop Refrigerator
Completely Sealed Dry Storage Pantry Centers
10"
115 V Electrical
Duplex Outlet Req.
Here
Depth Equals
Countertop Overhang
