MRC 0001956 Quick Start Manual

PROGRAMMING
This decoder supports all program modes and read back features.
CV Description
CV1 Short address
CV2 Start voltage
CV3 Acceleration
CV4 Deceleration
CV5 Top voltage
CV29 Basic configuration
CV7 Manufacturer version number
CV8 Manufacturer ID
CV17 Long address upper byte
CV18 Long address low er byte
CV19 Advanced consist address
CV21=0, all accessory function w ill follow its ow n address.
CV21
CV21=1, all functions w ill follow the consist address
CV49 Master sound volume
CV50 Whistle type
CV51 Whistle volume
CV52 Bell type
CV53 Bell volume
CV54 Bell ring rate
CV55 Chuff type (10 types)
CV56 Chuff volume
CV57 Brake squeal volume
CV58 Air release volume
CV59 Blow er hiss volume
CV60 Fire box door volume
CV61 Water injector volume
CV62 Coupling volume
CV63 Water filling volume
CV64 Rail clack volume
CV65 Kick start voltage
CV67-94 28 speed steps table w hile CV29.4=1
CV112 Metal crank volume
CV113 Back EMF Load control proportional gain Kp
CV114 Back EMF Load control integral gain Ki
CV115 Auto brake squeal enable/disable
CV116 Sand drop volume
CV117 Coal volume
CV118 Shoveling volume
CV120 Chuff rate
CV121 Chuff start point
CV122 Double chuff enable
C123 Safety valve type
CV124 Back EMF Load control intensity (0=off)
CV125 Set it to1 to restore some factory default CV settnings
SPEED TABLE CV67-CV94 FOR 28 SPEED STEPS
When CV29's bit 4 is set to "1" it will use the speed table formed by CV67-CV94
to control speed (motor voltage). It allows you to setup each speed for all 28
Range Default
speed steps. First, program CV29 to 18 for short addresses (1-127) or program
CV29 to 50 for long addresses (128-9999) to enable speed table control. Then
1-127 3
select throttle to 28 speed steps and run your loco at speed step 1. Use program
0-32 10
CV on the main to change CV67's value (1-255) to adjust step 1's speed. The
0-32 0
kick voltage, CV65 is only applied when the speed step changes from 0 to 1. You
0-32 0 should switch between 0 to 1 many times to check step 1's speed. When done
with CV67, select speed step 2 and program CV68. CV68's value must be
0-32 32
greater then CV67's. When done with CV67-CV94, use read back CV to make
--- 2
sure their values are in increasing order.
--- 19
Note: When using MRC Prodigy DCC to program addresses it will automatically
disable the speed table (set CV29's bit 4 to "0"). Programming CV125 to 1 will
--- 143
also disable the speed table and re-program CV67-CV94 to a default linear
192-231 192
speed setting.
0-255 3
0-127 0
TROUBLE SHOOTING
Loco running without chuff sound click F12. Whenever the decoder doesn't
0-1 0
work please use the program track to program CV #125 with value 1 to restore
the decoder to factory settings. This should bring the decoder to life with
0-63 63
address #3. This decoder should perform well with all DCC systems. The maximum
0-17 4
DCC output should be less than 18 V. If the locomotive does not respond to
0-63 60
commands, it may have lost its address. Please re-program the address and
0-7 60
program CV19 to 0 (disable consist). If it responds slowly, you should clear its
momentum by reprogramming CV3 and CV4 to zero. If step 1's speed is too high,
0-63 3
you should program start voltage, CV2 to zero. If its top speed is too slow, program
0-50 10
top voltage CV5 to 31. You should also clean the track to improve electrical pickup.
0-9 0
Read your DCC system manual to learn how to program and operate the decoder.
0-63 60 For more information about registers/CVs and their functions, please refer to the
NMRA DCC Standard & Recommended Practices, RP-9.2.2. This is available
0-63 40
directly from the NMRA or their website at www.nmra.org.
0-63 60
FCC COMPLIANCE
0-63 60
This device complies with part 15 of the FCC Rules. Operation is subject to the
0-63 60
following two conditions. (1) This device may not cause harmful interference,
0-63 60
and (2) This device must accept any interference received, including interfer-
0-63 60
ence that may cause undesired operation.
0-63 60
RETURN PROCEDURE
0-63 60
This decoder carries a 6 month warranty against factory defects. This warranty does
0-63 63
not include abuse, misuse, neglect, improper installation, or any modifications made
1-255 linear
to this decoder, including but not limited to the removal of the NMRA plug if applicable.
0-3 3
If it should become necessary to return the decoder for warranty repair/replacement,
0-31 20
please include a copy of the original sales receipt. Please include a letter (printed
clearly) with your name, address, daytime phone number, and a detailed description of
0-31 10
the problem you are experiencing. Please also include a check or a money order for
0-1 1(enable)
$10.00 to cover return shipping and handling. If the decoder is no longer considered
0-63 60
under warranty, then please include a check or a money order for $50.00 to cover the
0-63 60 cost of repair or replacement and return shipping and handling. Be certain to return
the decoder only.
0-63 60
Any questions regarding Warranty Policy can be directed to our Customer
0-60 30
Service Department by calling 732-225-6360 between the hours of 8:30am
0-10 3
and 6:00pm EST, or by emailing: rrtech@modelrectifier.com
0-1 1(enable)
Send the decoder to:
0-2 0
0-255 160
0-1 0
Model Rectifier Corporation
Attn: Parts & Service
80 Newfield Avenue
Edison, NJ 08837-3817 U.S.A Printed in USA
N Gauge Steam Sound Decoder
with 20 different chuff sounds
Item #0001956
Thank you for purchasing our most advanced DCC locomo-
tive sound decoder. Combined with any DCC System or
Tech 6 Sound Controller, our true live capture digital sound
decoder will make your model railroad come to life.
• Adjustable back EMF load control with utlra slow speed
control
• 20 types of synchronized chuff sounds
• Double chuff enabling
• 1.0 amp capacity
• 17 different types of whistles
• Programmable individual sound volumes (64-
levels)
• Programmable master sound volumes (64-levels)
• Programmable either 2-digit or 4-digit addresses
• Programmable start voltage and top voltage
• Programmable acceleration and decelaration rates
• Programmable 14, 28, 128 speed steps
• Supports full read back of address and CV values
• Advanced speed table control CV67-CV94
• Directional Head lights
• 28 accessory functions (F1-F28)
• Supports full read back of CV's
• Supports advanced consisting (CV19)
• Supports programming on the main (OPS mode)
• Compatible with NMRA DCC standards
• Complies with Part 15 of FCC Rules
• 17 mm speaker included
• Dimensions: 29.50mm x 10.60mm x 5.0mm
