MRC 0001916 Quick Start Manual

PROGRAMMING CV CHART
CV Register Description
CV1 R1 Short address
CV2 R2 Start voltage
CV3 R3 Acceleration, 1=1 sec, max is 63 sec to reach top speed
CV4 R4 Deceleration, 1=1 sec, max is 63 sec to stop at top speed
CV5 --- Top voltage, 63=full speed, 0=half of the top speed
CV6 Adaptive back EMF control enable, 1=enable, 0=disable
--- R6 Page number
CV29 R5 Basic configuration
CV7 R7 Manufacturer version number
CV8 R8 Manufacturer ID
CV17 --- Long address upper byte
CV18 --- Long address low er byte
CV19 --- Advanced consist address
When CV21=0, all accessory functions w ill follow its ow n
CV21 --- address. When CV21=1, all functions w ill follow the consist
address
CV49 Sound on/off- horn alw ays on
CV50 --- Horn type
CV51 --- Horn volume
CV52 --- Bell type
CV53 --- Bell volume
CV54 --- Bell ring rate
CV55 --- Prime mover volume (0=diesel of f)
CV56 --- Brake squeal volume
CV58 --- Air release volume
CV59 --- Air pump volume
CV60 --- Safety pop valve volume
CV61 --- Engine cooling fan volume
CV62 --- Coupling volume
CV63 --- Auto ditch lights flash w ith horn enable
CV64 --- Rail w heel clack volume
CV65 kick start voltage
CV67-94 28 speed steps table w hile CV29.4=1
CV105 --- User identification number
CV106 --- User identification number
CV113 Back EMF Load control proportional gain Kp
CV114 Back EMF Load control integral gain Ki
CV115 --- Auto brake squeal enable/disable
CV116 Brightness of dim light
CV120 Light brightness
CV121 Ditch lights flash (=1) or stay on (=0)
Diesel notch mode, 0=auto-notch
CV122 ---
3=manual notch
CV123 prime mover type
CV124 Back EMF Load control intensity (0=off)
Program it to1 w ill restore some the CV to factory default
CV125 ---
settng
SPEED TABLE CV67-CV94 FOR 28 SPEED STEPS
When CV29's bit 4 is set to "1" it will use the speed table formed by CV67-CV94
Range Default
to control speed (motor voltage). It allows you to setup each speed for all 28
1-127 3
speed steps. First, program CV29 to 18 for short addresses (1-127) or program
0-63 10
CV29 to 50 for long addresses (128-9999) to enable speed table control. Then
0-63 0 select throttle to 28 speed steps and run your loco at speed step 1. Use program
CV on the main to change CV67's value (1-255) to adjust step 1's speed. The
0-63 0
kick voltage, CV65 is only applied when the speed step changes from 0 to 1. You
0-63 63
should switch between 0 to 1 many times to check step 1's speed. When done
0-1 1
with CV67, select speed step 2 and program CV68. CV68's value must be
--- ---
greater then CV67's. When done with CV67-CV94, use read back CV to make
--- 2 sure their values are in increasing order.
Note: When using MRC Prodigy DCC to program addresses it will automatically
--- 2
disable the speed table (set CV29's bit 4 to "0"). Programming CV125 to 1 will
--- 143
also disable the speed table and re-program CV67-CV94 to a default linear
192-231 192
speed setting.
0-255 3
0-127 0 TROUBLE SHOOTING
Loco runing without sound click F12 or use CV 49 to turn on/off sound.
--- 0
Whenever the decoder doesn't work please use the program track to program
CV# 125 with value 1 to restore the decoder to factory settings. This should
0-1 1
bring the decoder to life with address #3. This decoder should perform well with all
0-22 13
DCC systems. The maximum DCC output should be less than 21 V. If the locomotive
0-15 12 does not respond to commands, it may have lost its address. Please re-program the
address and program CV19 to 0 (disable consist). If it responds to slowly, you
0-8 3
should clear its momentum by reprogramming CV3 and CV4 to zero. If step 1's
0-15 12
speed is too high, you should program start voltage, CV2 to zero. If its top speed is
0-50 3
too slow, program top voltage CV5 to 31. You should also clean the track to improve
0-13 12
electrical pickup. Read your DCC system manual to learn how to program and
0-15 7 operate the decoder. For more information about registers/CVs and their functions,
please refer to the NMRA DCC Standard & Recommended Practices, RP-9.2.2. This
0-15 12
is available directly from the NMRA or their website at www.nmra.org.
0-15 12
0-15 12 FCC COMPLIANCE
0-15 12
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions. (1) This device may not cause harmful interference,
0-15 12
and (2) This device must accept any interference received, including interfer-
0-1 1(enable)
ence that may cause undesired operation.
0-15 12
0-63 63
RETURN PROCEDURE
1-255 linear
This decoder carries a 6 month warranty against factory defects. This warranty
0-255 0
does not include abuse, misuse, neglect, improper installation, or any modifications
0-255 0
made to this decoder, including but not limited to the removal of the NMRA plug if
0-31 20 applicable. If it should become necessary to return the decoder for warranty repair/
replacement, please include a copy of the original sales receipt. Please
0-31 10
include a letter (printed clearly) with your name, address, daytime phone number,
0-1 1(enable)
and a detailed description of the problem you are experiencing. Please also include
0-255 255
a check or a money order for $11.00 to cover return shipping and handling. If the
0-255 255
decoder is no longer considered under warranty, then please include a check or a
0-1 0
money order for $35.00 to cover the cost of repair or replacement and return
shipping and handling. Be certain to return the decoder only.
0-3 3
Any questions regarding Warranty Policy can be directed to our Customer
Service Department by calling 732-225-6360 between the hours of 8:30am
0-2 0
and 6:00pm EST, or by emailing: rrtech@modelrectifier.com
0-255 160
Send the decoder to:
--- 0
Model Rectifier Corporation
Attn: Parts & Service
80 Newfield Avenue
Printed in USA
Edison, NJ 08837-3817 U.S.A
HO DC/DCC Diesel Sound Decoder
Drop in for Atlas Genset Locomotives
Item #0001916
Thank you for purchasing our most advanced DC/DCC
locomotive sound decoder. Combined with any DCC
System, MRC Blackbox or Tech 6, our true live capture
digital sound decoder will make your model railroad come
to life.
• Triple core processor generating three independent diesel
genset prime mover sounds
• 1.5 amp capacity
• 22 different types of horns and 8 types of bells
• Programmable individual sound volumes (16 levels)
• Programmable either 2-digit or 4-digit addresses
• Programmable start voltage and top voltage
• Programmable acceleration and decelaration rates
• Programmable 14, 28, 128 speed steps
• Back EMF load control
• Supports read back address and CV value
• Selectable factory default speed curve
• Advanced speed table control CV67-CV94
• Kick start voltage control CV65
• 17 light effects: ditch lights, mars light, gyra light,
strobe light, prime strobe...
• Replacement ditch light boards supplied for
flashing front and rear ditch lights
• 28 accessory functions (F1-F28)
• Supports advanced consisting (CV19)
• Supports programming on the main (OPS mode)
• Compatible with NMRA DCC standards
• Complies with Part 15 of FCC Rules
• 16x35 mm speaker included
• Dimensions: 73.0mm x 17.6mm x 8.4mm
