MRC 0001960 Quick Start Manual

PROGRAMMING
This decoder supports all program modes and read back features. With MRC
Prodigy Advance DCC you can read its address and CV values.
Description
CV
CV1 Short address
Start voltage
CV2
Acceleration
CV3
CV4 Deceleration
Top voltage
CV5
Basic configuration
CV29
Manufacturer version number
CV7
Manufacturer ID
CV8
CV17 Long address upper byte
Long address low er byte
CV18
Advanced consist address
CV19
CV21=0, all accessory function w ill follow its ow n
CV21 address. CV21=1, all functions w ill follow the consist
address
CV49 Master volume control (0=off)
CV50 Horn type (22 types plus off, 22=off)
CV51 Horn volume
CV52 Bell type (8 types plus off, 8=off)
CV53 Bell volume
CV54 Bell ring rate
CV55 Diesel rumble volume
CV56 Brake squeal volume
CV57 Dynamic brake volume
CV58 Air release volume
CV59 Air pump volume
CV60 Safety pop valve volume
CV61 Engine cooling fan volume
CV62 Coupling volume
CV64 Rail w heel clack volume
CV65 kick start voltage
CV67-94 28 speed steps table w hile CV29.4=1
CV105 User identification number
CV106 User identification number
CV112 Sand dropping volume
CV116 Flange squeal volume
CV117 Light brightness
CV122 Diesel notch mode, 0=auto notch, 3=manual notch
CV123 prime mover type, 6 types (See CV123 table)
Set it to1 to restore some factory default CV settings
CV125
SPEED TABLE CV67-CV94 FOR 28 SPEED STEPS
When CV29's bit 4 is set to "1" it will use the speed table formed by CV67-
CV94 to control speed (motor voltage). It allows you to setup each speed for
all 28 speed steps. First, program CV29 to 18 for short addresses (1-127) or
Range Default
program CV29 to 50 for long addresses (128-9999) to enable speed table
control. Then select throttle to 28 speed steps and run your loco at speed step
1-127 3
1. Use program CV on the main to change CV67's value (1-255) to adjust step
0-32 0
1's speed. The kick voltage, CV65 is only applied when the speed step
changes from 0 to 1. You should switch between 0 to 1 many times to check
0-32 0
step 1's speed. When done with CV67, select speed step 2 and program
0-32 0
CV68. CV68's value must be greater then CV67's. When done with CV67-
CV94, use read back CV to make sure their values are in increasing order.
0-32 32
Note: When using MRC Prodigy DCC to program addresses it will automatically
--- 2
disable the speed table (set CV29's bit 4 to "0"). Programming CV125 to 1 will
--- 32 also disable the speed table and re-program CV67-CV94 to a default linear
speed setting.
--- 143
192-231 192
TROUBLE SHOOTING
Whenever the decoder doesn't work please use the program track to program
0-255 3
CV# 125 with value 1 to restore the decoder to factory settings. This should
0-127 0
bring the decoder to life with address #3. This decoder should perform well
with all DCC systems. The maximum DCC output should be less than 15 V. If
0-1 0 the locomotive does not respond to commands, it may have lost its address.
Please re-program the address and program CV19 to 0 (disable consist). If it
responds slowly, you should clear its momentum by reprogramming CV3 and
0-16 16
CV4 to zero. If step 1's speed is too high, you should program start voltage,
0-22 13
CV2 to zero. If its top speed is too slow, program top voltage CV5 to 31. You
should also clean the track to improve electrical pickup. Read your DCC
0-15 15
system manual to learn how to program and operate the decoder. For more
0-8 5
information about registers/CVs and their functions, please refer to the NMRA
DCC Standard & Recommended Practices, RP-9.2.2. This is available directly
0-15 15
from the NMRA or their website at www.nmra.org.
0-50 20
FCC COMPLIANCE
0-15 15
This device complies with part 15 of the FCC Rules. Operation is subject to the
0-15 10
following two conditions. (1) This device may not cause harmful interference,
0-15 15
and (2) This device must accept any interference received, including interfer-
ence that cause undesired operation.
0-15 15
0-15 15
RETURN PROCEDURE
0-15 10
This decoder carries a 6 month warranty against factory defects. This warranty
does not include abuse, misuse, neglect, improper installation, or any
0-15 15
modifications made to this decoder, including but not limited to the removal of the
0-15 15
NMRA plug if applicable. If it should become necessary to return the decoder for
0-15 15
warranty repair/replacement, please include a copy of the original sales
receipt. Please include a letter (printed clearly) with your name, address,
0-63 63
daytime phone number, and a detailed description of the problem you are
1-255 linear
experiencing. Please also include a check or a money order for $10.00 to cover
return shipping and handling. If the decoder is no longer considered under
0-255 0
warranty, then please include a check or a money order for $50.00 to cover the
0-255 0
cost of repair or replacement and return shipping and handling. Be certain to
0-15 12
return the decoder only. Any questions regarding Warranty Policy can be
directed to our Customer Service Department by calling 732-225-6360
0-15 12
between the hours of 8:30am and 6:00pm EST, or by emailing:
0-255 200
rrtech@modelrectifier.com
0-3 3
Send the decoder to:
0-5 0
0-1 0
Model Rectifier Corporation
Attn: Parts & Service
80 Newfield Avenue
Edison, NJ 08837-3817 U.S.A
N Gauge DCC Diesel Sound
Decoder with 28 Functions
Item #0001960 ( for Kato SD45/SD70MAC/AC4400)
Thank you for purchasing our highly advanced dual mode DCC
locomotive sound decoder. Combined with any DCC System
our new decoder with authentic diesel sounds will bring your
locomotive come to life.
• Digital Signal Processor (DSP) and reverb effect
• Choice of six types of diesel prime mover sounds
making it suitable for many types of diesel locomo-
tives
•
Built in 22 user selectable horns and 8 bells
•
Lifelike, randomly associated locomotive sounds
•
28 accessory functions allowing more sound
control than ever
• Programmable master and individual sound
volumes (16 levels)
• 1.0 amp capacity
• 2-digit (1-127) or 4-digit (1-9999) addresses
• Supports full read back of CV's
• Programmable start and top voltage
• Programmable acceleration and deceleration
rate
• Programmable 14, 28, 128 speed steps
• Supports custom speed tables
• Supports advanced consisting (CV19)
• Supports programming on the main (OPS
mode)
• Compatible with NMRA DCC standards
• Board mounted 10mm, 32 ohm speaker
• Directly replaces the circuit board in Kato
SD45, SD70MAC and AC4400 and many other
locomotive's
