BLACKMER
CARTRIDGE MECHANICAL SEAL INSTRUCTIONS
MODELS: GX, X, XH, TX, TXV, TXDI, TX1200, STX2, STX3,
This is a SAFETY ALERT SYMBOL.
When you see this symbol on the product, or in the
manual, look for one of the following signal words and be
alert to the potential for personal injury, death or major
property damage
Warns of hazards that WILL cause serious personal injury,
death or major property damage.
Warns of hazards that CAN cause serious personal injury,
death or major property damage.
Warns of hazards that CAN cause personal injury
or property damage.
NOTICE:
Indicates special instructions which are very
important and must be followed.
NOTICE:
Blackmer pumps MUST only be installed in systems,
which have been designed by qualified engineering
personnel.
The system MUST conform to all
applicable local and national regulations and safety
standards.
These instructions are intended to assist in the
installation of Blackmer cartridge mechanical seals,
and MUST be kept with the pump.
Blackmer pump service shall be performed by
qualified technicians ONLY. Service shall conform to
all applicable local and national regulations and
safety standards.
Thoroughly review the pump manual, all instructions
and hazard warnings, BEFORE performing any work
on the Blackmer pump.
Maintain ALL system and Blackmer pump operation
and hazard warning decals.
MECHANICAL SEAL INSTALLATION
STX1220, TX206, TX400
DISCONNECTING FLUID OR PRESSURE
CONTAINMENT COMPONENTS DURING
PUMP
OPERATION
SERIOUS PERSONAL INJURY, DEATH
OR MAJOR PROPERTY DAMAGE
Hazardous pressure
can cause personal
injury or property
damage
FAILURE TO DISCONNECT AND
LOCKOUT ELECTRICAL POWER
BEFORE ATTEMPTING MAINTENANCE
CAN CAUSE SHOCK, BURNS OR
DEATH
Hazardous voltage.
Can shock, burn or
cause death.
FAILURE TO DISCONNECT AND
LOCKOUT ELECTRICAL POWER OR
ENGINE DRIVE BEFORE ATTEMPTING
MAINTENANCE CAN CAUSE SEVERE
PERSONAL INJURY OR DEATH
Hazardous
machinery can
cause serious
personal injury.
FAILURE TO RELIEVE SYSTEM
PRESSURE PRIOR TO PERFORMING
PUMP SERVICE OR MAINTENANCE
CAN CAUSE
INJURY OR PROPERTY DAMAGE.
Hazardous pressure
can cause serious
personal injury or
property damage
FAILURE TO SET THE VEHICLE
EMERGENCY BRAKE AND CHOCK
WHEELS BEFORE PERFORMING
SERVICE CAN CAUSE SEVERE
PERSONAL INJURY OR PROPERTY
Hazardous pressure
DAMAGE.
can cause personal
injury or property
damage
IF PUMPING HAZARDOUS OR TOXIC
FLUIDS, SYSTEM MUST BE FLUSHED,
PRIOR TO PERFORMING SERVICE OR
MAINTENANCE
Hazardous or toxic
fluids can cause
serious injury.
960610
FORM
Page
of
522
1
2
Effective
FEB 2017
Replaces
MAR 2003
CAN
CAUSE
SERIOUS
PERSONAL
