1B-18 AIR CONDITIONING (OPTIONAL)

RADIATOR (AND CONDENSER) COOLING

Check continuity between each two terminals about the radiator

(and condenser) cooling fan motor (1).

If check results are continuity, proceed to next operation check.

If not, replace.

Connect battery to radiator (and condenser) cooling fan motor (1)

as shown in figure, then check that the radiator (and condenser)

cooling fan motor operates smoothly.

Reference current : approx. 8.5 – 11.5 A at 12 V

REMOVAL AND INSTALLATION

Refer to RADIATOR in ENGINE COOLING SYSTEM Section.
