OWNER'S MANUAL & SERVICE BOOKLET
Keep With Vehicle At All Times.
Contains Important Information
On Safety, Operation & Maintenance.
Part No. 99011M76M01-74E
ENG.
February, 2014

Advertisement

Table of Contents
loading

Related Manuals for MARUTI SUZUKI CELERIO

Summary of Contents for MARUTI SUZUKI CELERIO

  • Page 1 OWNER'S MANUAL & SERVICE BOOKLET Keep With Vehicle At All Times. Contains Important Information On Safety, Operation & Maintenance. Part No. 99011M76M01-74E ENG. February, 2014...
  • Page 2 This Owner’s manual & service booklet applies to CELERIO models produced by MARUTI SUZUKI INDIA LIMITED. Note : The illustrated model is one of the CELERIO series Accessories shown in the picture are not part of standard equipment c COPYRIGHT MARUTI SUZUKI INDIA LIMITED 2014...
  • Page 4 “WARNING” Vehicle may break-down , meet with an Avoid driving into or starting the vehicle in a accident catch fire due to heavily water logged area. Vehicle may break- down or engine may fail due to 1. Installation of - High wattage bulbs 1.
  • Page 5 “CAUTION” 1. Retro-fitment of LPG / CNG kit may deteriorate vehicle performance, reduce engine & engine related component’s life and also warranty will be null and void for such vehicles. 2. Do not use domestic LPG/LPG cylinder for your factory fitted LPG vehicles. 3.
  • Page 6 COST OF MATERIALS AND CONSUMABLES TO BE BORNE BY CUSTOMER Service Manager’s Signature * MODEL CODES : ALTO-MRF308/310/410/308C, BALENO-MY416, MARUTI 800-MB308, ESTEEM-MF413,MF415D, GYPSY KING-MG413W, OMNI-MT308, VERSA-MGA413, WAGON-R-MRD410, ZEN-MH410/MH415D, SWIFT-RS412/RS413/RS413D, Customer’s Signature SX-4-RW416/416, GRAND VITARA XL7-JA627, ZEN ESTILO-RK410/310/310C, SWIFT DZIRE-RN412/RN413/RN413D, A-STAR-AMF310, RITZ-A5E412/A5E413D, EECO-MGA412/412C, NEW WAGONR-A1J310/310C, ERTIGA-AVI414/413D, CELERIO-AVH310...
  • Page 7 3.0 : Please fill up customer details i.e. Address and Telephone No. legibly and correctly for the latest owner. For Selling Dealer 1.0 : Please send all Free Service Coupon to us once in a month after settlement of free service charges. Service Division Maruti Suzuki India Limited...
  • Page 8 ALTO-MRF308/310/410/308C, BALENO-MY416, MARUTI 800- MB308, ESTEEM-MF413,MF415D, GYPSY KING-MG413W, OMNI-MT308, VERSA- MGA413, WAGONR-MRD410, ZEN-MH410/MH415D, SWIFT--RS412/RS413/ RS413DSX-4-RW416/416, GRAND VITARA XL7-JA627, ZEN ESTILO-RK410/310/ 310C, SWIFT DZIRE-RN412/RN413/RN413D,A-STAR-AMF310, RITZ-A5E412/ COST OF MATERIALS AND CONSUMABLES TO BE BORNE BY CUSTOMER A5E413D, EECO-MGA412/412C, NEW WAGONR-A1J310/310C, ERTIGA-AVI414/413D, CELERIO-AVH310...
  • Page 9 3.0 : Please fill up customer details i.e. Address and Telephone No. legibly and correctly for the latest owner. For Selling Dealer 1.0 : Please send all Free Service Coupon to us once in a month after settlement of free service charges. Service Division Maruti Suzuki India Limited...
  • Page 10 ALTO-MRF308/310/410/308C, BALENO-MY416, MARUTI 800- MB308, ESTEEM-MF413,MF415D, GYPSY KING-MG413W, OMNI-MT308, VERSA- MGA413, WAGONR-MRD410, ZEN-MH410/MH415D, SWIFT--RS412/RS413/ RS413DSX-4-RW416/416, GRAND VITARA XL7-JA627, ZEN ESTILO-RK410/310/ 310C, SWIFT DZIRE-RN412/RN413/RN413D,A-STAR-AMF310, RITZ-A5E412/ COST OF MATERIALS AND CONSUMABLES TO BE BORNE BY CUSTOMER A5E413D, EECO-MGA412/412C, NEW WAGONR-A1J310/310C, ERTIGA-AVI414/413D, CELERIO-AVH310...
  • Page 11 3.0 : Please fill up customer details i.e. Address and Telephone No. legibly and correctly for the latest owner. For Selling Dealer 1.0 : Please send all Free Service Coupon to us once in a month after settlement of free service charges. Service Division Maruti Suzuki India Limited...

  • Page 12: Table Of Contents

    MH0-74E TABLE OF CONTENTS VEHICLE DETAILS WARRANTY POLICY FUEL RECOMMENDATION BEFORE DRIVING OPERATING YOUR VEHICLE DRIVING TIPS OTHER CONTROLS AND EQUIPMENT VEHICLE LOADING AND TOWING INSPECTION AND MAINTENANCE EMERGENCY SERVICE APPEARANCE CARE GENERAL INFORMATION SPECIFICATION...
  • Page 13 Please built or sold. This vehicle may not show this manual to your comply with standards or regulations dealer while you take your MARUTI SUZUKI of other countries. Before attempting for any Service. to register this vehicle in any other...
  • Page 14 Indicates a potential hazard that could interference with your vehicle’s result in minor or moderate injury. ignition system, resulting in vehicle performance problems. Consult your MARUTI SUZUKI dealer for advice on NOTICE installing such mobile communication equipment. Indicates a potential hazard that could result in vehicle damage.

  • Page 15: Vehicle Details

    VEHICLE DETAILS MH0-74E VEHICLE DETAILS MODEL CHASSIS NO. ENGINE NO. KEY NO. DATE OF ODOMETER BATTERY DELIVERY READING (KM) MAKE SR. NO /BATCH CODE OWNER’S NAME & ADDRESS ____________________________________________________________________________ _____________________________________________________________________ TEL. NO. _________________________ ADDRESS/STAMP OF SELLING DEALER SELLING DEALER CODE SHOWROOM IMPORTANT INFORMATION TO CUSTOMER Dear Customer...

  • Page 16: Maintenance Service Record

    MH0-74E MAINTENANCE SERVICE RECORD DATE OF KIND OF MILEAGE DESCRIPTION OF JOB NAME OF SERVICING JOB CARD MECHANIC’S SERVICE SERVICE (km) DEALER/MASS SIGNATURE F..free Service P..Paid Service W..Warranty. A..Accident...

  • Page 17: Warranty Policy

    Maruti Suzuki vehicle distributed in India (1) normal maintenance service required other than the three by Maruti Suzuki and sold by an authorised Maruti Suzuki dealer free services, including without limitation, oil and fluid will be free, under normal use and service, from any defects in...
  • Page 18 This warranty is the entire written warranty given by Maruti or destroyed the owner should consult the authorised Maruti Suzuki for Maruti Suzuki vehicles and no dealer or its or his Suzuki dealer from whom the vehicle was purchased for agent or employee is authorised to extend or enlarge this instructions concerning replacement of the “Owner’s Manual...

  • Page 19: Emission Warranty

    (Engine oil, Transmission oil, Brake oil etc.) are also as per specification. The method of examination for deciding the warranty of the parts will be at the sole discretion of Maruti Suzuki and it's dea ler and results of the examination will be final and binding. If after examination, the warrantable condition is not established, Maruti Suzuki and it's dealer has the right to charge all, or part of the cost of such examination.
  • Page 20 Maruti Suzuki dealer. Maruti Suzuki will not be responsible for any penalty that may be charged by statutory authorities on account of failure to c omply with the EMISSION STANDARDS.
  • Page 21 EMISSION WARRANTY MH0-74E Annexure-A List of parts covered under Emission Warranty Fuel injection Assembly, Pressure Regulator, Throttle Body Assembly. Electronic Control Module (ECM). Intake Manifold. EGR valve. Distributor and internal parts. Ignitions coil. Canister Assembly. Vapour Liquid Separator. Fuel Tank and Filler Cap. 10.

  • Page 22: Fuel Recommendation

    MARUTI SUZUKI and may automatic system, initial vent not be covered under the New Vehicle blowback occurs.

  • Page 23: Before Driving

    BEFORE DRIVING MH0-74E BEFORE DRIVING Keys ............................4-1 Door Locks .......................... 4-2 Keyless Entry System Transmitter (if equipped) ............4-5 Security System (if equipped) ..................4-7 Windows ..........................4-10 Mirrors ..........................4-12 Front Seats ........................4-14 Rear Seats ......................... 4-14 Seat Belts and Child Restraint Systems ..............

  • Page 24: Keys

    NOTE: The engine can be started only with your  If you lose your immobilizer ignition key, contact your MARUTI SUZUKI dealer as vehicle’s original immobilizer ignition key EXAMPLE which has an electronic identification code soon as possible to have the lost one programmed into it.

  • Page 25: Door Locks

    BEFORE DRIVING MH0-74E Door Locks the key toward the rear of the vehicle. Central Door Locking System (if equipped) To lock a front passenger’s door from out- Side Door Locks side the vehicle, turn the lock knob forward, Driver’s door Driver’s door then pull and hold the door handle as you close the door.
  • Page 26 BEFORE DRIVING MH0-74E top of the key toward the rear of the vehi- Child-Proof Locks (rear door) NOTE: cle twice.  Individual doors can also be EXAMPLE NOTE: UNLOCKED anytime by using You can switch the function that unlocks all their respective "Door Lock doors from twice operations to once opera- Knob"...
  • Page 27 EXAMPLE If the tailgate cannot be unlatched by pull- ing up the tailgate handle (3), have the vehicle inspected by your MARUTI SUZUKI dealer. CAUTION 76MH0A086 Make sure there is no one near the 1) Driver’s door lock...

  • Page 28: Keyless Entry System Transmitter (If Equipped)

    BEFORE DRIVING MH0-74E Keyless Entry System tion, and vice versa, via the setting mode and then you unlock the doors using the of the information display. For details on transmitter, the siren will sound 4 times Transmitter (if equipped) how to use the information display, refer to to remind you.
  • Page 29  If you lose one of the transmitters key, the ignition switch to the “ON” position to EXAMPLE contact your MARUTI SUZUKI dealer as cancel the panic alarm. soon as possible for a replacement. Be NOTE: sure to have your dealer program the The panic alarm function will not activate new transmitter code in your vehicle’s...

  • Page 30: Security System (If Equipped)

    To set the shock sensor, theft. Do not leave money or things of value battery. Keep lithium batteries away ask your MARUTI SUZUKI dealer or use the in the vehicle. from children and pets. If swallowed, setting mode of the information display.
  • Page 31 BEFORE DRIVING MH0-74E Without tachometer locked, the security system will be armed in will be triggered again if any of the doors or about 5 seconds if the system is in the engine hood is opened, or the vehicle feels EXAMPLE enabled state.
  • Page 32 BEFORE DRIVING MH0-74E (If the shock sensor is in the enabled state) 1) Sit in the driver’s seat and make sure that 2) Turn the lock knob (1) on the driver’s • If the vehicle feels a shock, the siren all doors are closed.

  • Page 33: Windows

    BEFORE DRIVING MH0-74E Windows • If you cannot complete the operations in EXAMPLE step 3) and 4) within 15 seconds correctly, Manual Window Control the state of the security system will not 3 times change and the interior buzzer does not (if equipped) beep.
  • Page 34 BEFORE DRIVING MH0-74E Driver’s door Passenger’s door EXAMPLE EXAMPLE EXAMPLE 81A009 To open a window, push the top part of the 76MH0A022 76MH0A023 switch and to close the window, lift up the The driver’s door has a switch (1) to oper- The passenger’s door has a switch (5) to top part of the switch.

  • Page 35: Mirrors

    BEFORE DRIVING MH0-74E Lock switch Mirrors WARNING Inside Rearview Mirror  You should always lock the pas- EXAMPLE You can adjust the inside rearview mirror senger’s window operation when there are children in the vehicle. by hand so as to see the rear of your vehi- cle in the mirror.
  • Page 36 BEFORE DRIVING MH0-74E To adjust the mirror, set the selector tab (1) Type 1 Electric Mirrors (if equipped) to the day position, then move the mirror EXAMPLE up, down or sideways by hand to obtain the EXAMPLE best view. When driving at night, you can move the selector tab to the night position to reduce glare from the headlights of vehicles behind you.

  • Page 37: Front Seats

    BEFORE DRIVING MH0-74E Front Seats Rear Seats EXAMPLE Seat Adjustment Folding Rear Seats The rear seat(s) of your vehicle can be WARNING folded forward to provide additional cargo space. Never attempt to adjust the driver’s seat or seatback while driving. The To fold the rear seats forward: seat or seatback could move unex- pectedly, causing loss of control.
  • Page 38 BEFORE DRIVING MH0-74E NOTICE NOTICE CAUTION  When you move a seatback, make After folding the rear seatback for- When returning the rear seatback to sure the latch plate is inserted into ward, do not allow any foreign mate- the normal position, be careful that the slit securely so the seat belts rial to enter the lock opening.

  • Page 39: Seat Belts And Child Restraint Systems

    BEFORE DRIVING MH0-74E Seat Belts and Child Restraint NOTICE EXAMPLE Systems  When returning the rear seatback to the normal position, do not allow EXAMPLE any foreign material to enter the lock opening. This may prevent the seatback from being locked Across the pelvis securely.
  • Page 40 BEFORE DRIVING MH0-74E WARNING WARNING EXAMPLE  Pregnant women should use seat  Children age 12 and under should belts, although specific recommen- ride properly restrained in the rear dations about driving should be seat. as low as possible made by the woman’s medical ...
  • Page 41 BEFORE DRIVING MH0-74E Safety reminder upward through the latch plate. The length WARNING of the diagonal shoulder strap adjusts itself Sit up straight and to allow freedom of movement.  All seatbacks should always be in fully back an upright position when driving, or All Seat Belts Except Rear Center seat belt effectiveness may be All seat belts except rear center are the lap-...
  • Page 42 BEFORE DRIVING MH0-74E belt. The latch plate should then be refitted TO TIGHTEN into the buckle and the belt tightened as previously described. To unfasten the belt, press the release but- Low on hips ton on the buckle catch. MH0-07-014 MH0-07-014 To unfasten the seat belt, push the button To tighten the belt, pull the free end of the...
  • Page 43 BEFORE DRIVING MH0-74E Driver’s Seat Belt Reminder When the driver doesn’t buckle his or her NOTICE seat belt with the ignition switch in the “ON” (if equipped)  When you move a seatback, make position, the driver’s seat belt reminder light With tachometer sure the latch plate is inserted into in the instrument cluster will blink until the...
  • Page 44 MH0-07-014 MH0-07-014 MARUTI SUZUKI highly recommends that Child restraint Child Restraint Systems you use a child restraint system to restrain EXAMPLE infants and small children. Many different...
  • Page 45 BEFORE DRIVING MH0-74E If you must use a front-facing child restraint WARNING EXAMPLE in the front passenger’s seat, adjust the passenger’s seat as far back as possible. If you install a child restraint system in the rear seat, slide the front seat NOTE: far enough forward so that the child’s Observe any statutory regulation about child...

  • Page 46: Supplemental Restraint System (Air Bags) (If Equipped)

    MARUTI SUZUKI’s SUPPLEMEN- 1) Driver's front air bag module (if equipped) TAL RESTRAINT SYSTEM (air bags). 2) Front passenger's front air bag module (if...
  • Page 47 Have the air further movements during the accident. bag system inspected by an authorized MARUTI SUZUKI dealer as soon as Therefore, an air bag is NOT a substitute possible. for seat belts. To maximize your protection, ALWAYS WEAR YOUR SEAT BELTS.
  • Page 48 BEFORE DRIVING MH0-74E Driver’s front air bag (if equipped) The driver’s front air bag is located behind Conditions of front air bags deployment the center pad of the steering wheel and the (inflation) front passenger’s front air bag is located EXAMPLE EXAMPLE behind the passenger’s side of the dashboard.
  • Page 49 BEFORE DRIVING MH0-74E Conditions of front air bags may inflate  Falling into a deep hole or ditch  Collision from the rear Receiving a strong impact to the lower body EXAMPLE of your vehicle, the front air bags will inflate EXAMPLE in many cases.
  • Page 50 BEFORE DRIVING MH0-74E Front air bags may not inflate  Collision that the front of your vehicle EXAMPLE goes under the bed of a truck etc. The front air bags may not inflate when the impact is absorbed since the collision object EXAMPLE moved, vehicle body deformed, or collision angle was greater than about 30 degrees...
  • Page 51 A seat belt helps keep you in the proper age, have the air bag system inspected by position for maximum protection when an air an authorized MARUTI SUZUKI dealer to bag inflates. Adjust your seat as far back ensure it is in proper working order.
  • Page 52 Servicing the air bag system service work on your MARUTI SUZUKI. Do If the air bags inflate, have the air bags and not touch air bag system components or related components replaced by an authori- wires.

  • Page 53: Instrument Cluster

    BEFORE DRIVING MH0-74E Instrument Cluster With tachometer 1) Speedometer EXAMPLE 2) Tachometer (if equipped) 3) Information display 4) Trip meter selector knob 5) Indicator selector knob 6) Warning and indicator lights MH0-07-014 Without tachometer EXAMPLE MH0-07-014 4-30...

  • Page 54: Tachometer (If Equipped)

    BEFORE DRIVING MH0-74E Speedometer Fuel Gauge When the ignition switch is in the “ON” position, this gauge gives an approximate The speedometer indicates vehicle speed. With tachometer indication of the amount of fuel in the fuel Tachometer (if equipped) tank. “F” stands for full and “E” stands for EXAMPLE empty.

  • Page 55: Brightness Control

    BEFORE DRIVING MH0-74E Brightness Control Information Display WARNING If you attempt to adjust the display EXAMPLE EXAMPLE while driving, you could lose control of the vehicle. Do not attempt to adjust the display while driving. NOTE:  If you do not turn the brightness control knob within about 5 seconds of activat- ing the brightness control display, the brightness control display will be can-...
  • Page 56 BEFORE DRIVING MH0-74E without tachometer Display (E) NOTE: Thermometer (if equipped) When you reconnect the negative (–) ter- EXAMPLE minal to the battery, the clock indication will Clock be reinitialized. Change the indication again When the ignition switch is in the “ON” to your preference.
  • Page 57 BEFORE DRIVING MH0-74E (a) Trip meter A NOTE: EXAMPLE (b) Trip meter B The indicated maximum value of the trip (c) Odometer meter is 9999.9. When you run past the (d) Instantaneous fuel consumption maximum value, the indicated value will (e) Average fuel consumption return to 0.0.
  • Page 58 BEFORE DRIVING MH0-74E  The indication on the display may be To change the unit of average fuel con- the current driving range when the ignition delayed if fuel consumption is greatly sumption, while pushing and holding the trip switch is turned to the “ON” position. affected by driving conditions.
  • Page 59 BEFORE DRIVING MH0-74E Gear position indicator (for auto- NOTE: NOTE:  The outside temperature indication is not When you reconnect the negative (–) ter- mated manual transaxle vehicles) the actual outside temperature when minal to the battery, the unit of temperature EXAMPLE driving at low speed, or when stopped.
  • Page 60 BEFORE DRIVING MH0-74E 4-37...
  • Page 61 BEFORE DRIVING MH0-74E 4-38...
  • Page 62 BEFORE DRIVING MH0-74E 4-39...

  • Page 63: Warning And Indicator Lights

    BEFORE DRIVING MH0-74E Warning and Indicator Lights Brake System Warning Light MH0-07-001 Three different types of operations exist depending on the vehicle’s specification. 1) The light comes on briefly when the ignition switch is turned to the “ON” position. 2) The light comes on when the parking brake is engaged with the ignition switch in the “ON”...
  • Page 64 (proportioning valve function) occur, you should immediately ask of the ABS system fails. your MARUTI SUZUKI dealer to If the brake system warning light comes on inspect the brake system. while you are driving the vehicle, it may ...
  • Page 65 Warning Light (if equipped) If one of these happens, have the system ual transaxle system. Have the system inspected by your MARUTI SUZUKI dealer. inspected by an authorized MARUTI If the ABS becomes inoperative, the brake SUZUKI dealer.
  • Page 66  The steering wheel is operated very often. MARUTI SUZUKI dealer to have the system as you can and stop the engine.  The steering wheel is kept in a fully inspected.
  • Page 67 MARUTI SUZUKI dealer. Low Fuel Warning Light High Engine Coolant Temperature MH0-07-001 Warning Light (red color) When the ignition switch is turn to the “ON”...

  • Page 68: Lighting Control Lever

    BEFORE DRIVING MH0-74E to the “ON” position. This indicator comes on when headlight Lighting Control Lever main beams (high beams) are turned on. NOTE: EXAMPLE The activation point of this light varies Security System Indicator (if depending on road conditions (for example, equipped) slope or curve) and driving conditions because of fuel moving in the tank.

  • Page 69: Front Fog Light Switch (If Equipped)

    BEFORE DRIVING MH0-74E OFF (1) slightly toward you and release it when you Headlight Leveling Switch All lights are off. have completed the signal. EXAMPLE Lights “On” reminder (if equipped) Front position lights, tail lights, license plate A buzzer/chime sounds to remind you to light and instrument lights are on, but turn off the lights if they are left on when headlights are off.

  • Page 70: Turn Signal Control Lever

    BEFORE DRIVING MH0-74E Turn Signal Control Lever Turn Signal Operation Lane change signal With the ignition switch in the “ON” position, EXAMPLE move the lever up or down to activate the EXAMPLE left or right turn signals. Normal turn signal EXAMPLE MH0-07-014 MH0-07-014...

  • Page 71: Hazard Warning Switch

    BEFORE DRIVING MH0-74E Hazard Warning Switch Windshield Wiper and Washer Windshield Wipers Lever EXAMPLE EXAMPLE EXAMPLE MH0-07-014 MH0-07-014 MH0-07-014 Push in the hazard warning switch to To turn the windshield wipers on, move the activate the hazard warning lights. All turn lever down to one of the three operating WARNING signal lights and both turn signal indicators...
  • Page 72 BEFORE DRIVING MH0-74E Windshield Washer Rear Window Wiper/Washer Switch NOTICE (if equipped) To help prevent damage to the EXAMPLE Washer EXAMPLE windshield wiper and washer system components, you should take the following precautions:  Do not continue to hold in the lever when there is no windshield washer Wiper fluid being sprayed or the washer...

  • Page 73: Tilt Steering Lock Lever (If Equipped)

    BEFORE DRIVING MH0-74E Tilt Steering Lock Lever When the rear window is misted, push this WARNING switch (1) to clear the window. (if equipped) Never attempt to adjust the steering An indicator light will be lit when the wheel while the vehicle is moving or EXAMPLE defogger is on.

  • Page 74: Operating Your Vehicle

    OPERATING YOUR VEHICLE MH0-74E OPERATING YOUR VEHICLE Exhaust Gas Warning ......................5-1 Daily Inspection Checklist ....................5-1 Engine Oil Consumption ....................5-2 Ignition Switch ........................5-3 Parking Brake Lever ......................5-4 Pedal ............................. 5-5 Starting the Engine ......................5-6 Using the Transaxl e ......................5-6 Braking ..........................

  • Page 75: Exhaust Gas Warning

    OPERATING YOUR VEHICLE MH0-74E Exhaust Gas Warning Daily Inspection Checklist WARNING Before Driving  Do not park with the engine running EXAMPLE for a long period of time, even in an EXAMPLE open area. If it is necessary to sit for a short time in a parked vehicle with the engine running, make sure the air intake selector is set to...

  • Page 76: Engine Oil Consumption

    OPERATING YOUR VEHICLE MH0-74E NOTE: Pull the hood release handle inside the More oil is consumed during high-speed It is normal for water to drip from the air vehicle. Make sure that you cannot open driving and when there is frequent accele- conditioning system after use.

  • Page 77: Ignition Switch

    OPERATING YOUR VEHICLE MH0-74E Ignition Switch only position in which the key can be START removed. This is the position for starting the engine using the starter motor. The key should be EXAMPLE EXAMPLE released from this position as soon as the engine starts.

  • Page 78: Parking Brake Lever

    They fully release, have your vehicle also could suffer from heat stroke inspected immediately in warm or hot weather. These could authorized MARUTI SUZUKI dealer. result in severe injury or even death. MH0-07-014 WARNING 1) To set...
  • Page 79 Brake Pedal (2) 3) Get out of the vehicle and put MH0-07-014 chocks under the wheels. Your MARUTI SUZUKI vehicle is equipped Automated manual transaxle 4) Release the parking brake. with front disc brakes and rear drum brakes. When you return to your vehicle,...

  • Page 80: Starting The Engine

    OPERATING YOUR VEHICLE MH0-74E 2) Manual transaxle – Shift into “N” then press down the accelerator pedal to 1/ WARNING (Neutral) and depress the clutch pedal 3 of its travel and try cranking the engine Do not “ride” the brakes by applying all the way to the floor.
  • Page 81 OPERATING YOUR VEHICLE MH0-74E accelerator while continuing to gradually Automated Manual Transaxle WARNING release the clutch. (Auto Gear Shift)  Reduce your speed and downshift Automated manual transaxle is a 5-speed Shifting to a lower gear before going down forward/reverse transaxle. All forward gears are synchronized, which a long or steep hill.
  • Page 82 OPERATING YOUR VEHICLE MH0-74E This light will also come on if one of the the vehicle starts slowly without depressing EXAMPLE gears cannot be engaged and the system the accelerator pedal. The creeping function is unable to re-try shifting when you shift is disabled if you depress the brake pedal the gearshift lever from “N”...
  • Page 83 (6 mph), there may be a “D” position, the gear will be shifted to 4) Depress the accelerator pedal slowly. systematic malfunction. In this case, 1st. ask your MARUTI SUZUKI dealer to WARNING inspect automated manual transaxle system as soon as possible.
  • Page 84 OPERATING YOUR VEHICLE MH0-74E Starting off on an uphill/downhill: 2) Release the brake pedal and depress Upshift and downshift: the accelerator pedal slowly. Even if the Uphill Upshifting accelerator pedal is not depressed, the 1) Apply the parking brake firmly so that clutch will be engaged when the vehicle EXAMPLE the vehicle does not roll backwards.
  • Page 85 MH0-07-014 systematic malfunction. In this case, Push the gearshift lever to the “–” direction WARNING ask your MARUTI SUZUKI dealer to and release it. Every time the lever is inspect the automated manual  Be careful when accelerating, operated, the transaxle is downshifted in the transaxle system as soon as possible.
  • Page 86 OPERATING YOUR VEHICLE MH0-74E the engine” in this section. pedal. Depress the accelerator pedal Starting off on an uphill/downhill slope: 2) With your foot on the brake pedal, shift slowly for smooth starting. Uphill the gearshift lever to the “M” position. 1) Apply the parking brake firmly so that WARNING When the gearshift lever is shifted to the...
  • Page 87 OPERATING YOUR VEHICLE MH0-74E 2) Release the brake pedal and depress a warning buzzer (long pulse sound) will Stopping the accelerator pedal slowly. Even sound if any of the following cases The vehicle can be stopped by depressing though the accelerator pedal is not occur;...
  • Page 88 OPERATING YOUR VEHICLE MH0-74E Parking WARNING WARNING Unlike an automatic transaxle, automated If the gear is not engaged properly manual transaxle does not have a parking  When leaving the vehicle, stop the and completely before the ignition position. The vehicle can be parked with the engine and park the vehicle with a switch is turned off, the vehicle may gearshift lever in any position.

  • Page 89: Braking

    “N” position, then and then ask your MARUTI SUZUKI shift to “R” position again a few seconds and unpredictable. dealer to inspect your vehicle.
  • Page 90 ABS system. Ask (if equipped)  On regular paved roads, some your MARUTI SUZUKI dealer to ABS will help you avoid skidding by drivers may be able to obtain inspect the ABS system immediately. electronically controlling braking pressure. It...
  • Page 91 Ask your MARUTI SUZUKI dealer to inspect the ABS system immediately. Drive carefully, avoiding hard braking as much as possible.

  • Page 92: Driving Tips

    DRIVING TIPS MH0-74E DRIVING TIPS Running-in ..........................6-1 Catalytic Converter ......................6-1 Improving Fuel Economy ....................6-2 Highway Driving ........................6-3 Driving on Hills ........................6-3 Driving on Slippery Roads ....................6-3 Driving on Wet Roads ....................... 6-5 Do's and Don'ts for Safe Driving ................... 6-5 Margin for Safety ........................

  • Page 93: Running-In

    DRIVING TIPS MH0-74E Running-in Catalytic Converter NOTICE EXAMPLE The future performance and reliability of the engine depends on the care MH0-07-001 and restraint exercised during its early life. It is especially important to WARNING observe the following precautions  Wear Your Seat Belts at All Times. during the initial 960 km (600 miles) Even though air bags are equipped of vehicle operation.

  • Page 94: Improving Fuel Economy

    DRIVING TIPS MH0-74E engine, do not allow the engine to idle or NOTICE EXAMPLE apply full throttle until the engine has To avoid damaging catalyst or other reached operating temperature. Allow the vehicle damage: engine to warm up by driving. ...

  • Page 95: Highway Driving

    DRIVING TIPS MH0-74E If the air cleaner is clogged with dust, there  At high speeds, the vehicle may be WARNING will be greater intake resistance, resulting affected by side winds. Therefore, reduce Try not to hold the brake pedal down in decreased power output and increased speed and be prepared for unexpected too long or too often while going...
  • Page 96 DRIVING TIPS MH0-74E at a lower speed than on dry roads due to If Your Vehicle Gets Stuck NOTICE possible slippage of tires during braking. If your vehicle gets stuck in snow, mud, or Do not continue rocking the vehicle When driving on icy, snow-covered, or sand, follow the directions below: for more than a few minutes.

  • Page 97: Driving On Wet Roads

     Do not use tires other than those This section contains basic rules for safe  When driving on wet roads, avoid specified by MARUTI SUZUKI. Never driving. Read it carefully for good driving through large amount of use different sizes or types of tires understanding of the content so that you standing water on the road.
  • Page 98 DRIVING TIPS MH0-74E General driving carefully confirm the safety. 1. Be sure to stop before the stop light and 6. Don’t attempt zigzag driving which will stop sign. When moving into the hinder your control over the vehicle and intersection without any traffic lights or cause an accident.
  • Page 99 DRIVING TIPS MH0-74E 60M-04-012 60M-04-013 60M-04-014 Night time driving 5. The higher the speed, the narrower the driver’s visual range becomes. In such 1. Drive more slowly at night than in the a state, it is difficult to anticipate any daytime, for the visual range is restricted hazard and the driver feels much at night.

  • Page 100: Margin For Safety

    DRIVING TIPS MH0-74E MARGIN FOR SAFETY It is important to allow yourself a margin for safety during driving so that you can cope with erroneous or unexpected driving of other drivers. For that, obser ve the following.  Drive at a safe speed. ...

  • Page 101: Other Controls And Equipment

    OTHER CONTROLS AND EQUIPMENT MH0-74E OTHER CONTROLS AND EQUIPMENT Fuel Filler Cap ........................7-1 Engine Hood ........................7-2 Sun Visor ..........................7-3 Interior Light ........................7-4 Accessory Socket (if equipped) ..................7-5 AUX/USB Socket (if equipped) ..................7-5 Assist Grips (if equipped) ....................7-5 Glove Box ..........................

  • Page 102: Fuel Filler Cap

    OTHER CONTROLS AND EQUIPMENT MH0-74E Fuel Filler Cap The fuel filler cap is located on the left rear EXAMPLE side of the vehicle. The fuel filler door can be unlocked by pulling up the opener lever EXAMPLE located on the outboard side of the driver’s seat and locked by simply closing the door.

  • Page 103: Engine Hood

    OTHER CONTROLS AND EQUIPMENT MH0-74E WARNING EXAMPLE EXAMPLE If you need to replace the fuel cap, use a Maruti genuine cap. Use of an improper cap can result in a malfunction of the fuel system or emission control sys- tem. It may also result in fuel leakage in the event of an accident.

  • Page 104: Sun Visor

    OTHER CONTROLS AND EQUIPMENT MH0-74E To close the engine hood: Sun Visor Card holder (if equipped) 1) Lift the hood up slightly and remove the prop rod from the hole. Put the prop rod EXAMPLE EXAMPLE back to the holding clip. 2) Lower the hood close to the bumper, then let it drop down.

  • Page 105: Interior Light

    OTHER CONTROLS AND EQUIPMENT MH0-74E Vanity mirror (if equipped) Interior Light ON (1) The light comes on and stays on regardless Type A of whether the door is open or closed. EXAMPLE EXAMPLE DOOR (2) The light comes on when the door is opened.

  • Page 106: Accessory Socket (If Equipped)

    OTHER CONTROLS AND EQUIPMENT MH0-74E NOTE: NOTICE NOTICE The number of doors involved in the lighting Always close the lid when not in use, operation of the interior light depends on the inappropriate electrical since entry of foreign material, dust, accessories can cause damage to vehicle specification.

  • Page 107: Glove Box

    OTHER CONTROLS AND EQUIPMENT MH0-74E Glove Box Cup Holder and Storage Area EXAMPLE EXAMPLE 76MH0A073 To open the glove box, pull the latch lever. To close it, push the lid until it latches securely. WARNING Never drive with the glove box lid open.
  • Page 108 OTHER CONTROLS AND EQUIPMENT MH0-74E Instrument Panel Pocket Front Cup Holders (3) Rear Cup Holder (2) (driver’s side) (1) / Instrument Panel Pocket (center) (2) WARNING EXAMPLE Failure to take the precautions listed WARNING below could cause personal injury or Do not place any objects which may vehicle damage.

  • Page 109: Floor Mats (If Equipped)

    To prevent the driver’s side floor mat from sliding forward and possibly interfering with EXAMPLE the operation of the pedals, genuine MARUTI SUZUKI floor mats are recommen- ded. Whenever you put the driver’s side floor mat EXAMPLE back in the vehicle after it has been...

  • Page 110: Frame Hooks

    OTHER CONTROLS AND EQUIPMENT MH0-74E Frame Hooks WARNING NOTICE Front Do not carry items on top of the When you use the frame hook (1), luggage compartment cover, even if avoid the driving that gives significant they are small and light. Objects on physical shock on hook.

  • Page 111: Manual Heating And Air Conditioning System

    OTHER CONTROLS AND EQUIPMENT MH0-74E Manual Heating and Air Conditioning Center outlet WARNING System (if equipped) Do not use the frame hooks to tow Air Outlet another vehicle or to have your vehicle towed on the road or highway. EXAMPLE The hook (2) is designed for use in emergency situations only, such as if your vehicle or another vehicle gets...
  • Page 112 OTHER CONTROLS AND EQUIPMENT MH0-74E Temperature selector (1) Bi-level (b) Heat & defrost (d) This is used to select the temperature by turning the selector. Blower speed selector (2) This is used to turn on the blower and to select blower speed by turning the selector. Air flow selector (3) 76MH0A084 76MH0A087...
  • Page 113 OTHER CONTROLS AND EQUIPMENT MH0-74E Air intake selector (4) With this “A/C” switch operation, an indicator to a higher blower speed position increases light will come on when the airconditioning heating efficiency. system is on. To turn off the air conditioning Quick heating (using recirculated air) system, push the “A/C”...
  • Page 114 OTHER CONTROLS AND EQUIPMENT MH0-74E You can switch the air intake selector to Therefore, you should occasionally select EXAMPLE either “FRESH AIR” or “RECIRCULATED “FRESH AIR”.  If your vehicle has been left in the sun AIR” as you desire. Choosing “RECIRCULA- TED AIR”...

  • Page 115: Radio Antenna

    OTHER CONTROLS AND EQUIPMENT MH0-74E engine idling. This circulates the refrigerant Radio Antenna Audio System (if equipped) and oil and helps protect the internal components. EXAMPLE NOTE: Your vehicle uses the air conditioning refrigerant HFC-134a, commonly called “R- 134a”. R-134a replaced R-12 around 1993 automotive applications.
  • Page 116  Please bring the unit to an authorized quickly tune to them using the MARUTI SUZUKI dealer. presets.  Set the sound volume to a level that Cautions on Handling will allow you to continue to be aware of road and traffic conditions while driving.
  • Page 117 OTHER CONTROLS AND EQUIPMENT MH0-74E NOTE: EXAMPLE  Do not use commercially available CD protection sheets or discs equipped with stabilizers, etc.  These may get caught in the internal mechanism and damage the disc. 52D349  It may be impossible to play CD-R discs Do not use any solvents such as commer- with this unit due to the recording cially available cleaners, anti-static spray, or...
  • Page 118 OTHER CONTROLS AND EQUIPMENT MH0-74E Basic Operations Mute Press the MUTE button (3) to mute the EXAMPLE sound. To cancel the mute, press the MUTE The Bluetooth® word mark and logo are button (3) again. registered trademarks and are owned by the ®...
  • Page 119 OTHER CONTROLS AND EQUIPMENT MH0-74E Adjusting bass/treble/balance /fader 1) Press the TUNE FOLDER PUSH Listening to the Radio 1) Press the TUNE FOLDER PUSH SOUND knob (2) until the AVC EXAMPLE SOUND knob (2). adjustment mode is selected. Each time the knob is pressed, sound 2) Turn the TUNE FOLDER PUSH SOUND adjustment will change as follows: knob (2) to select the desired AVC...
  • Page 120 OTHER CONTROLS AND EQUIPMENT MH0-74E Selecting the FM band Auto store Radio Reception Press the FM button (1). Hold down the AS button (7) for 2 seconds Radio reception can be affected by Each time the button is pressed, the or longer.
  • Page 121 OTHER CONTROLS AND EQUIPMENT MH0-74E 1) Insertion slot longer will automatically be drawn inside the 2) Eject button unit. (Auto reload function) 3) CD button The backup eject function: 4) Up button This function allows you to eject a CD by 5) Down button pressing the Eject button (2) even when the 6) RPT button...
  • Page 122 OTHER CONTROLS AND EQUIPMENT MH0-74E Random playback Display change Listening to an MP3/WMA/AAC Disc Press the RDM button (7). Press the DISP button (8). Each time the button is pressed, the mode Each time the button is pressed, display will EXAMPLE will change as follows: change as follows:...
  • Page 123 OTHER CONTROLS AND EQUIPMENT MH0-74E Selecting a folder  ALL RANDOM Turn the TUNE FOLDER PUSH SOUND The random indicator “RDM” will light. knob (1) to select a folder. The tracks in the loaded disc will be played in random order. Selecting a track ...
  • Page 124 OTHER CONTROLS AND EQUIPMENT MH0-74E Notes on MP3/WMA/AAC Points to remember when making MP3/ data on the same disc, sort and place WMA/AAC files them in different folders. What is MP3? Common  Do not write files other than MP3/WMA/ ...
  • Page 125 OTHER CONTROLS AND EQUIPMENT MH0-74E WMA (Ver. 7, Ver. 8, Ver. 9*) Listening to files stored in a USB A) Folder number  Bit rate: CBR 32 k - 320 kbps B) Track number device  Sampling frequency: 32 k/44.1 k/48 kHz C) Play time WMA 9 Professional/LossLess/Voice are D) File type...
  • Page 126 OTHER CONTROLS AND EQUIPMENT MH0-74E  Press the Down button (4) twice to listen Repeat playback to the previous track. Press the RPT button (5). When the Down button (4) is pressed Each time the button is pressed, the mode once, the track currently being played will change as follows: will start from the beginning again.
  • Page 127 OTHER CONTROLS AND EQUIPMENT MH0-74E  USB Standard Compatibility 1.1/2.0 Full Recording MP3/WMA/AAC files on a Maximum number of files/folders Speed  Maximum number of files: 2500 USB device  File System FAT12/16/32, VFAT  Maximum number of files in a folder: 255 ...
  • Page 128 OTHER CONTROLS AND EQUIPMENT MH0-74E 5) RPT button Random playback  SONG REPEAT 6) RDM button Press the RDM button (6). The repeat indicator “RPT” will light. 7) DISP button Each time the button is pressed, the mode The track currently being played will be 8) Preset buttons ([1] to [6]) will change as follows: played repeatedly.
  • Page 129 OTHER CONTROLS AND EQUIPMENT MH0-74E Playing Mode selection  iPod® touch (3rd generation) not be shut down when it is being 1) Press the button numbered [6] of the  iPod® touch (2nd generation) connected and may result in battery Preset buttons (8) for 1 second or ...
  • Page 130 OTHER CONTROLS AND EQUIPMENT MH0-74E 2) Press the MEDIA button (1). Bluetooth® Hands-Free (if equipped) Each time the button is pressed, the mode will change as follows: MH0-05-011 CAUTION 76MH0A132  Before connection, mute the unit, 4) Bluetooth® setup button and also keep the volume of the 76MH0A102 5) Off Hook button...
  • Page 131 OTHER CONTROLS AND EQUIPMENT MH0-74E again or refer to the manual of the Rejecting a call (only for supported 2) Turn the TUNE FOLDER PUSH SOUND phone in use for how to establish the models) knob (1) to select “Setup Telephone”, pairing with the phone.
  • Page 132 OTHER CONTROLS AND EQUIPMENT MH0-74E 3) Turn the TUNE FOLDER PUSH SOUND To dial from the dialed history or the 3) Turn the TUNE FOLDER PUSH SOUND knob (1) to select “Sound Setting”, and received history, select “Missed Calls”, knob (1) to select “Delete History”, and press the knob (1) to determine the “Incoming Calls”...
  • Page 133 OTHER CONTROLS AND EQUIPMENT MH0-74E 2) Turn the TUNE FOLDER PUSH SOUND Transfer of call history (Call History) 2) Turn the TUNE FOLDER PUSH SOUND knob (1) to select “Setup Telephone”, Follow the instructions below to transfer call knob (1) to select “Phonebook”, and and press the knob (1) to determine the history of the registered phone.
  • Page 134 OTHER CONTROLS AND EQUIPMENT MH0-74E 3) Turn the TUNE FOLDER PUSH SOUND 3) Turn the TUNE FOLDER PUSH SOUND number assigned to each of the Preset knob (1) to select “Setup Phonebook”, knob (1) to select “Setup Phonebook”, buttons (3). and press the knob (1) to determine the and press the knob (1) to determine the 1) Press the Off Hook button (5).
  • Page 135 OTHER CONTROLS AND EQUIPMENT MH0-74E 5) Turn the TUNE FOLDER PUSH SOUND NOTE: 1) Press the Bluetooth® setup button (4). knob (1) to select “Del Speed Dial”, and When selecting “Go Back”, the previous The Bluetooth® setup menu will be press the knob (1) to determine the menu will be displayed.

  • Page 136: Bt Function On/Off

    OTHER CONTROLS AND EQUIPMENT MH0-74E 2) Turn the TUNE FOLDER PUSH SOUND 5) Press or turn the TUNE FOLDER PUSH 4) Turn the TUNE FOLDER PUSH SOUND knob (1) to select “Setup Bluetooth”, and SOUND knob (1) to select “Confirm”. knob (1) to select a phone to be deleted, press the knob (1) to determine the 6) Turn the TUNE FOLDER PUSH SOUND...

  • Page 137: Bluetooth Audio

    OTHER CONTROLS AND EQUIPMENT MH0-74E 4) Press the TUNE FOLDER PUSH Steering switch Registration of audio devices SOUND knob (1) to select “BT Power To use Bluetooth ® -ready audio devices On” or “BT Power Off”. with this unit, it required to register the NOTE: phone in advance.

  • Page 138: Selecting Bluetooth Audio Mode

    OTHER CONTROLS AND EQUIPMENT MH0-74E Bluetooth version 2.1 or above passkey  Press the Down button (4) twice to listen NOTE: input is not required). to the previous track. If text data contains more than 12 charac- ters, the “>” mark will appear at the right When the Down button (4) is pressed NOTE: once, the track currently being played...
  • Page 139 OTHER CONTROLS AND EQUIPMENT MH0-74E NOTE: 2) Turn the TUNE FOLDER PUSH SOUND 1) Press the Bluetooth® setup button (6).  When selecting “Go Back”, the previous knob (2) to select “Setup Bluetooth”, and The Bluetooth® setup menu will be menu will be displayed.
  • Page 140 OTHER CONTROLS AND EQUIPMENT MH0-74E  To decrease the volume, hold down “-”  To scan a higher frequency radio station, • Connectivity or voice quality may get press “^” of the switch (4) for 1 second of the VOL switch (1). The volume will affected depending on circumstances.
  • Page 141 OTHER CONTROLS AND EQUIPMENT MH0-74E Anti-Theft Feature Setting the Anti-Theft Function 4) Enter a 4-digit number to be registered 1) Press the VOL PUSH POWER knob (1) as PIN using the buttons numbered [1] to power off. - [4] of the Preset buttons (2). 2) Hold down the buttons numbered [1] and 5) Hold down the TUNE FOLDER PUSH [6] of the Preset buttons (2) and press...
  • Page 142 OTHER CONTROLS AND EQUIPMENT MH0-74E NOTE: Battery replacement timing If battery leakage has occurred, wipe the If an incorrect PIN is entered, “ERROR” and  When battery power is depleted, the but- container first then install a new battery. If the total number of incorrect entry attempts ton may not be operable.
  • Page 143 OTHER CONTROLS AND EQUIPMENT MH0-74E Remote Controller common operations MH0-05-018 7-42...
  • Page 144 OTHER CONTROLS AND EQUIPMENT MH0-74E Radio operations NOTE: When there are fewer than 6 stations that can be stored even if 1 round of auto store operation is performed, no station will be stored at the remaining preset buttons. MH0-05-019 7-43...
  • Page 145 OTHER CONTROLS AND EQUIPMENT MH0-74E CD operations MH0-05-020 7-44...
  • Page 146 OTHER CONTROLS AND EQUIPMENT MH0-74E MP3/WMA/AAC Disc operations MH0-05-021 7-45...
  • Page 147 OTHER CONTROLS AND EQUIPMENT MH0-74E USB operations MH0-05-022 7-46...
  • Page 148 OTHER CONTROLS AND EQUIPMENT MH0-74E iPod operations MH0-05-023 7-47...
  • Page 149 MH0-74E Troubleshooting When encountered a problem, check and follow the instructions as described below. If the described suggestions do not solve the problem, it is recommended to take the unit to your authorized MARUTI SUZUKI deal er. Problem Possible cause...
  • Page 150 OTHER CONTROLS AND EQUIPMENT MH0-74E Problem Possible cause Possible solution MP3/WMA/AAC No playback The disc contains unsupported formatted Check the file format. data. Sound skips or noise produced Sound skipping may occur when playing It is not recommended to play VBR files. VBR (Variable Bit Rate) files.
  • Page 151 OTHER CONTROLS AND EQUIPMENT MH0-74E Error Display Messages Display Possible cause Possible solution Insert the disc with its label side up. ERROR 1 The disc cannot be read. Check the disc if it is not warped or is free of flaws. When ERROR 1 does not disappear even when a normal disc is inserted, contact your dealer.
  • Page 152 OTHER CONTROLS AND EQUIPMENT MH0-74E Display Possible cause Possible solution Bluetooth ® ERROR 1 The player developed an error of an uni- Disconnect the Bluetooth ® ready device and connect it dentified cause. again. When ERROR 1 does not disappear, contact your dealer. Failed Failed to establish pairing Try to establish the pairing again.

  • Page 153: Vehicle Loading And Towing

    VEHICLE LOADING AND TOWING MH0-74E VEHICLE LOADING AND TOWING Vehicle Loading ........................8-1 Trailer Towing ........................8-1 Towing Your Vehicle ......................8-2...

  • Page 154: Vehicle Loading

    Trailer Towing addition, sure observe government and local requirements Your MARUTI SUZUKI was originally desig- regarding vehicle lighting and trailer ned to carry people and a normal amount hitches or tow bars. of cargo, not to tow a trailer. MARUTI...
  • Page 155 VEHICLE LOADING AND TOWING MH0-74E A: 2WD VEHICLES WITH MANUAL WARNING NOTICE TRANSAXLE OR AUTOMATED MANUAL A safety chain should always be used After shifting the automated manual TRANSAXLE when you tow your vehicle. transaxle gearshift lever to the “N” 1) Secure the front wheels on a towing dolly according to the instructions position, always check the gear...

  • Page 156: Inspection And Maintenance

    INSPECTION AND MAINTENANCE MH0-74E INSPECTION AND MAINTENANCE Maintenance Schedule ....................... 9-1 Periodic Maintenance Schedule ..................9-3 Drive Belt ..........................9-7 Engine Oil and Filter ......................9-7 Engine Coolant ........................9-10 Air Cleaner ......................... 9-11 Spark Plugs ........................9-12 Gear Oil ..........................9-13 Clutch Pedal ........................

  • Page 157: Maintenance Schedule

     Do not allow smoking, sparks, or electrical service work on your flames around fuel or the battery. MARUTI SUZUKI. Do not touch air Flammable fumes are present. bag system components or wires.  Do not get under your vehicle if it is supported only with the portable jack provided in your vehicle.
  • Page 158 INSPECTION AND MAINTENANCE MH0-74E WARNING MARUTI SUZUKI recommends that maintenance on your Maruti Suzuki vehicle should be performed by MARUTI SUZUKI authorised workshop/ Service station. NOTICE Whenever it becomes necessary to replace parts on your vehicle, it is recommended that you use MARUTI genuine replacement parts or their equivalent.

  • Page 159: Periodic Maintenance Schedule

    INSPECTION AND MAINTENANCE MH0-74E Periodic Maintenance Schedule A..Adjust. I..Inspect and correct or replace if necessary. T..Tighten to specified torque. C..Clean. R..Replace or change. O..Rotate L..Lubricate. NOTE: This table includes services as scheduled up to 80000 km mileage. Beyond 80000 km carry out the same services at the same intervals respectively.
  • Page 160 INSPECTION AND MAINTENANCE MH0-74E FREE INSPECTIONS PERIODIC MAINTENANCE SERVICE AT COST Interval: This interval should be judged by odometer reading or months, km (x 1,000) whichever comes first. months Fuel tank cap, fuel lines & connections (leakage,damage) – – – –...
  • Page 161 INSPECTION AND MAINTENANCE MH0-74E FREE INSPECTIONS PERIODIC MAINTENANCE SERVICE AT COST Interval: This interval should be judged by odometer reading or months, km (x 1,000) whichever comes first. months WHEEL Tyres (air pressure, abnormal wear, crack, rotation) I&O I&O I&O I&O I&O I&O...
  • Page 162 INSPECTION AND MAINTENANCE MH0-74E FREE INSPECTIONS PERIODIC MAINTENANCE SERVICE AT COST Interval: This interval should be judged by odometer reading or months, km (x 1,000) whichever comes first. months BODY All chassis bolts and nuts (tighten) – All Latches, Hinges & Locks (function) I&L I&L I&L...

  • Page 163: Drive Belt

    SAE 0W-20 (1) is the best choice for good If you need to replace or adjust the belt fuel economy, and good starting in cold have it done by your MARUTI SUZUKI weather. dealer. Oil Level Check K10B DEF: 4.0 –...
  • Page 164 INSPECTION AND MAINTENANCE MH0-74E Changing Engine Oil and Filter NOTICE EXAMPLE Drain the engine oil while the engine is still Failure to check the oil level regularly warm. could lead to serious engine trouble due to insufficient oil. EXAMPLE Close Open Refilling EXAMPLE...

  • Page 165: Refill With Oil/Check For Leaks

    INSPECTION AND MAINTENANCE MH0-74E WARNING NOTICE EXAMPLE To tighten the oil filter properly, it is Launder any clothing or rags if wet Important to accurately identify the with oil. position at which the filter gasket first Recycle or properly dispose of used contacts the mounting surface.

  • Page 166: Engine Coolant

    Failure to use the proper coolant can dam- the “FULL” and “LOW” marks. NOTICE age your cooling system. Your authorized Adding Coolant MARUTI SUZUKI dealer can help you select  When replacing the oil filter, it is the proper coolant. recommended that you use a Maruti EXAMPLE genuine replacement filter.

  • Page 167: Air Cleaner

    (–31°F) or below, use higher one. concentrations up to 60% following the instructions on the antifreeze container. Coolant Replacement Since special procedures are required, we recommend you take your vehicle to your MARUTI SUZUKI dealer for coolant replacement. 9-11...

  • Page 168: Spark Plugs

    INSPECTION AND MAINTENANCE MH0-74E Spark Plugs spark may not be produced. Remove NOTICE carbon deposits with a wire or pin and  When pulling the ignition coils out, adjust the spark plug gap. EXAMPLE do not pull on the cable. Pulling on To access the spark plugs: the cable can damage it.

  • Page 169: Gear Oil

    INSPECTION AND MAINTENANCE MH0-74E Gear Oil Level Check NOTICE NOTICE  When installing the spark plugs, When replacing spark plugs, you EXAMPLE screw them in with your fingers to should use the brand and type speci- avoid stripping the threads. Tighten fied for your vehicle.

  • Page 170: Clutch Pedal

    MARUTI SUZUKI dealer. pedal should be between the specified values. If the play is more or less than the above, or clutch dragging is felt with the pedal fully depressed, have the clutch inspected by your MARUTI SUZUKI dealer. 9-14...
  • Page 171 If not, have the brake partic-les and other liquids are kept adjusting, there is no need for pedal system inspected by your MARUTI SUZUKI out of the brake fluid reservoir. adjustment. dealer. If you doubt the brake pedal for the...

  • Page 172: Steering

    The play should immediately by your MARUTI SUZUKI by the ratchet teeth as you slowly pull up be between the specified values. dealer.

  • Page 173: Tires

    If any tires 1) Measure the air pressure with a tire show abnormal wear, have them gauge. Adjust the pressure if neces- inspected by your MARUTI SUZUKI sary. Remember to check the spare tire, dealer. too.

  • Page 174: Battery

    WARNING explosion may occur. Never smoke when working in the vicinity of the  Your MARUTI SUZUKI is equipped battery. with tires which are all the same type  When checking or servicing the and size.

  • Page 175: Fuses

    INSPECTION AND MAINTENANCE MH0-74E Replacement of the battery Fuses Your vehicle has three types of fuses, as EXAMPLE-1 EXAMPLE-2 EXAMPLE described below: Main fuse The main fuse takes current directly from the battery. Primary fuses These fuses are between the main fuse and individual fuses, and are for electrical load groups.
  • Page 176 INSPECTION AND MAINTENANCE MH0-74E The main fuse, primary fuses and some of Fuses in the Engine Compartment MAIN FUSE/PRIMARY FUSE the individual fuses are located in the engine compartment. If the main fuse blows, EXAMPLE no electrical component will function. If a primary fuse blows, no electrical component in the corresponding load group will –...
  • Page 177 IG1 SIG short period of time, you may have a major electrical problem. Have your (14) Air bag vehicle inspected immediately by your (15) Power window timer 68KH078 MARUTI SUZUKI dealer. (16) Door lock EXAMPLE (17) Horn/Hazard (18) Rear defogger (19)

  • Page 178: Bulb Replacement

    NOTICE Frequent replacement of a bulb indicates the need for an inspection of the electrical system. This should be carried out by your MARUTI SUZUKI EXAMPLE dealer. 76MH0A113 1) Open the engine hood. Disconnect the...
  • Page 179 INSPECTION AND MAINTENANCE MH0-74E Side Turn Signal Light (if equipped) 2) Turn the bulb holder (2) clockwise and Front Turn Signal Light (1) pull it out from the light housing. Front Position Light (2) EXAMPLE 76MH0A006 1) Remove the light housing (1) by sliding 76MH0A008 76MH0A116 (4) Removal...
  • Page 180 INSPECTION AND MAINTENANCE MH0-74E light housing, turn the holder counter- Front Fog Light (if equipped) clockwise and pull it out. 1) Start the engine. Turn the steering wheel to the opposite side of the replacing fog EXAMPLE light to replace the bulb easily. Then turn off the engine.
  • Page 181 INSPECTION AND MAINTENANCE MH0-74E Rear Combination Light 2) To remove the bulb holder of the tail/ EXAMPLE brake light (3), the turn signal light (4) or the reversing light (5) from the light EXAMPLE housing, turn the holder counterclockwise and pull it out. EXAMPLE 76MH0A124 NOTE:...
  • Page 182 INSPECTION AND MAINTENANCE MH0-74E EXAMPLE EXAMPLE EXAMPLE 76MH0A126 76MH0A127 76MH0A128 2) To remove and install the bulb of the 2) Close the tailgate. Remove the high- (4) Removal license plate light (2), simply pull out or mount stop light housing (2) from the (5) Install push in the bulb.

  • Page 183: Wiper Blades

    Type A Wiper Blades NOTE: Some wiper blades may be different from the ones described here depending on vehicle specifications. If so, consult your MARUTI SUZUKI dealer for proper replacement method. For windshield wipers: 60G115 54G129 Type B If the wiper blades become brittle or damaged, or make streaks when wiping, replace the wiper blades.
  • Page 184 INSPECTION AND MAINTENANCE MH0-74E Removal EXAMPLE EXAMPLE EXAMPLE 54G135 60A260 (1) Retainer Installation 4) If the new blade is provided without the two metal retainers, move them from the old blade to the new one. EXAMPLE 54G130 2) Squeeze lock (1) towards wiper arm (2) and remove the wiper frame from the arm as shown.
  • Page 185 INSPECTION AND MAINTENANCE MH0-74E For rear wipers: EXAMPLE 60MH072 65D151 NOTE: (A) Up Do not flex the wiper blade frame end more (B) Down than necessary. If you do, it can break off. NOTE: When you install the metal retainers (3), make sure the direction of metal retainers as shown in the above illustrations.

  • Page 186: Windshield Washer Fluid

    INSPECTION AND MAINTENANCE MH0-74E 4) If the new blade is provided without the WARNING two metal retainers, move them from the old blade to the new one. Do not use “antifreeze” solution in the windshield washer reservoir. This can 5) Install the new blade in the reverse order severely impair visibility when sprayed of removal.

  • Page 187: Emergency Service

    EMERGENCY SERVICE MH0-74E EMERGENCY SERVICE Tire Changing Tool......................10-1 Jacking Instructions ......................10-1 Changing Wheels ......................10-3 Jump Starting Instructions....................10-4 Towing ..........................10-5 If the Starter Does Not Operate..................10-6 If the Engine is Flooded ....................10-6 If the Engine Overheats ....................10-6...

  • Page 188: Tire Changing Tool

    EMERGENCY SERVICE MH0-74E Tire Changing Tool WARNING WARNING After using the tire changing tools, be  Be sure to shift into “R” (Reverse) EXAMPLE sure to stow them securely or they when you jack up the vehicle. can cause injury if an accident occurs. ...
  • Page 189 EMERGENCY SERVICE MH0-74E 7) Continue to raise the jack slowly and Front jacking point for garage jack (1) EXAMPLE smoothly until the tire clears the ground. Do not raise the vehicle more than EXAMPLE necessary. WARNING  Use the jack only to change wheels on level, hard ground.

  • Page 190: Changing Wheels

    (if equipped), engine undercover or rear torsion beam. NOTE: For more details, please contact an authorized MARUTI SUZUKI dealer. Changing Wheels To change a wheel, use the following MH0-07-014 procedure: Tightening torque for wheel nut...

  • Page 191: Jump Starting Instructions

    Also, stow vehicle inspected by an authorized the flat tyre in the spare tyre stowed position. MARUTI SUZUKI dealer. Refer to “Tyre Changing Tool” in this section.  To avoid harm to yourself or damage...

  • Page 192: Towing

    EMERGENCY SERVICE MH0-74E using either of the following methods. WARNING EXAMPLE 1) From the front, with the front wheels Never connect the jump lead directly lifted and the rear wheels on the ground. to the negative (–) terminal of the Before towing, make sure that the discharged battery, or an explosion parking brake is released.

  • Page 193: If The Starter Does Not Operate

    If it is, you must wait until it major electrical problem. Have the stops boiling before you proceed. vehicle inspected by your authorized MARUTI SUZUKI dealer. 10-6...

  • Page 194: Warning Triangle

    EMERGENCY SERVICE MH0-74E Warning Triangle • Remove the warning triangle carefully from EXAMPLE the cover as shown by arrow 1. • Open both the reflector arms as shown by arrow and lock the arms with each other with the clip provided in the right arm. Open the bottom stand in counter clock-wise EXAMPLE direction as shown by arrow 3.

  • Page 195: Appearance Care

    APPEARANCE CARE MH0-74E APPEARANCE CARE Corrosion Prevention 4) High temperatures will cause an Remove foreign material deposits accelerated rate of corrosion to parts of Foreign material such as salts, chemicals, It is important to take good care of your the vehicle which are not well ventilated road oil or tar, tree sap, bird droppings and vehicle to protect it from corrosion.

  • Page 196: Vehicle Cleaning

    APPEARANCE CARE MH0-74E Certain cargos such as chemicals, fertilizers, Vehicle Cleaning Rub the surface with a clean, damp cloth cleaners, salts, etc. are extremely corrosive to remove dirt and the soap solution. If by nature. These products should be some dirt still remains on the surface, transported in sealed containers.
  • Page 197 APPEARANCE CARE MH0-74E Carpets Washing When washing the vehicle, park it where Remove dirt and soil as much as possible direct sunlight does not fall on it and follow with a vacuum cleaner. Using a mild soap the instructions below: solution, rub stained areas with a clean 1) Flush the underside of body and wheel damp cloth.
  • Page 198 APPEARANCE CARE MH0-74E 3) Wash the entire exterior with a mild NOTICE detergent or car wash soap using a If you use an automatic car wash, sponge or soft cloth. The sponge or make sure that your vehicle’s body cloth should be frequently soaked in the soap solution.

  • Page 199: General Information

    Whenever you have occasion to consult your MARUTI SUZUKI dealer, remember to identify your vehicle with this number. Should you find the number difficult to read, you will also find it on the identification plate.
  • Page 200 Government of India. In case of any damage to RFID tag or replacement of front windscreen, please contact your nearest Maruti Suzuki Authorized workshop. EXAMPLE Note: Note:...

  • Page 201: Specification

    SPECIFICATIONS MH0-74E SPECIFICATIONS NOTE: M/T: Manual transaxle Specifications are subject to change without AMT: Automated manual transaxle notice. ITEM: Dimensions UNIT: mm Overall length 3600 Overall width 1600 Overall height 1560 Wheelbase 2425 Front 1420 Track Rear 1410 Ground clearance ITEM: Mass (weight) UNIT: kg 810 - 830...
  • Page 202 SPECIFICATIONS MH0-74E ITEM: Engine Type K10B (DOHC) Number of cylinders Bore 73.0 mm Stroke 79.5 mm Piston displacement 998 cm Compression ratio 11.0 ± 0.4 : 1 ITEM: Electrical Standard spark plug Nickel plug NGK KR6A-10 Battery 12V 34B19L Fuses See “INSPECTION AND MAINTENANCE”...
  • Page 203 SPECIFICATIONS MH0-74E ITEM: Lights WATTAGE BULB No. Headlight 12V 60/55W Front fog light (if equipped) 12V 35W H8/PSX24W Position light 12V 5W Turn signal light Front 12V 21W PY21W Rear 12V 21W PY21W Side turn signal light 12V 5W WY5W/W5W –...
  • Page 204 SPECIFICATIONS MH0-74E ITEM: Wheels and Tires 155/80R13 Tire size, front and rear 165/70R14 81S 155/80R13 79S tire: 13 × 4 1/2J Rim size 165/70R14 81S tire: 14 × 5J For the specified tire pressure, see the Tire Information Label located Tire pressures on the driver’s door lock pillar.
  • Page 205 MH0-74E MEMO...
  • Page 206 MH0-74E MEMO...
  • Page 207 MH0-74E MEMO...
  • Page 208 Prepared by MARUTI SUZUKI INDIA LIMITED Service Division December, 2013 Part No. 99011M76M00-74E Printed in India For round-the-clock on-road assistance, call Maruti On-road Service at 1800 4200 #No STD code to be prefixed.
  • Page 209 India's No. 1 Car Exchange Programme 1800 4200 PEACE OF MIND Service Division MARUTI SUZUKI INDIA LIMITED Palam Gurgaon Road, Gurgaon - 122 015 (Haryana) www.marutisuzuki.com...

Table of Contents
