Page 1 OWNER’S MANUAL & SERVICE BOOKLET • • Keep With Vehicle At All Times Contains Important Information On Safety, Operation & Maintenance Part No. 99011M68P06-74E January, 2017...
Page 2 This Owner Manual & Service Booklet applies to the BALENO series produced by MARUTI SUZUKI INDIA LIMITED BALENO BALENO RS Note: The illustrated models one of the BALENO Series. © COPYRIGHT MARUTI SUZUKI INDIA LIMITED 2017...
Page 3 Kindly appreciate that any tampering of wiring harness to fit accessories may cause the vehicle to malfunction. Thank you once again for choosing a Maruti Suzuki vehicle. I wish you many years of safe and happy driving.
Page 4 “WARNING” Vehicle may break-down , meet with an Avoid driving into or starting the vehicle in a accident catch fire due to heavily water logged area. Vehicle may break- down or engine may fail due to 1. Installation of - High wattage bulbs 1.
Page 5 “CAUTION” 1. Retro-fitment of LPG / CNG kit may deteriorate vehicle performance, reduce engine & engine related component’s life and also warranty will be null and void for such vehicles. 2. Do not use domestic LPG/LPG cylinder for your factory fitted LPG vehicles. 3.
Page 6 MARUTI SUZUKI INDIA LIMITED new MARUTI SUZUKI and review the tyres etc. reserves the right to make production manual from time to time. It contains changes at any time, without notice and important information on safety, operation...
Page 7 NOTE: NOTICE Indicates special information to make maintenance easier or instructions clearer. Severe damage may be caused by the use of either poor quality fuel and/or lubricants not recommended by MARUTI SUZUKI.
Page 8: Warranty Policy
(3) Maruti Suzuki Warranty Obligation: ries. If any defect(s) should be found in a Maruti Suzuki vehicle within Any vehicle on which parts or accessories not approved by the term stipulated above, Maruti Suzuki’s only obligation is to Maruti Suzuki have been used.
Page 9 This warranty is the entire written warranty given by Maruti Suzuki (8) Disclaimer of Consequential Damage: for Maruti Suzuki vehicles and no dealer or its or his agent or Maruti Suzuki assumes no responsibility for loss of vehicle, loss of...
Page 10 EMISSION WARRANTY POLICY 3. The method of examination for deciding the warranty of the parts will be at the sole discretion of Maruti Suzuki and autho- rised Maruti Suzuki workshop and results of the examination Maruti Suzuki offers the Emission Warranty on all Maruti Suzuki will be final and binding.
Page 11 8. Fuel Tank and Filler Cap. 1. In the absence of valid PUC certificate. 9. PCV (Positive Crankcase Ventilation) Valve. 2. Vehicle not serviced from authorised Maruti Suzuki workshop 10. Oil Filler Cap. as per the schedule specified in the Owner’s Manual.
Page 12: Table Of Contents
TABLE OF CONTENTS FUEL RECOMMENDATION BEFORE DRIVING OPERATING YOUR VEHICLE DRIVING TIPS OTHER CONTROLS AND EQUIPMENT VEHICLE LOADING AND TOWING INSPECTION AND MAINTENANCE EMERGENCY SERVICE APPEARANCE CARE GENERAL INFORMATION SPECIFICATIONS...
Page 14: Fuel Recommendation
FUEL RECOMMENDATION FUEL RECOMMENDATION Fuel Recommendation ............1-1...
Page 15 Blends of unleaded petrol and ethanol occurs, the air chamber will become (grain alcohol), also known as gasohol, are the responsibility of MARUTI SUZUKI and full. Exposure to heat when fully may not be covered under the New Vehicle commercially available in some areas.
Page 16 Be careful not to spill fuel containing less than 350 ppm (parts per million). alcohol while refueling. If fuel is MARUTI SUZUKI recommends to use the spilled on the vehicle body, wipe it up diesel fuel conformable to EN590. Do not immediately.
Page 18: Before Driving
BEFORE DRIVING BEFORE DRIVING Instrument Cluster (Type A) (If equipped) ......2-52 Speedometer ............... 2-53 Fuel Gauge ................2-53 Brightness Control .............. 2-54 Information Display ............. 2-54 Instrument Cluster (Type B) (If equipped) ......2-61 Speedometer ............... 2-62 Tachometer ................2-62 Fuel Gauge ................
Page 19: Keys
Keep the tag (If equipped) in a immobilizer system. Ask your authorised safe place. If you lose your keys, you will Maruti Suzuki workshop to have the sys- need this number to have new keys made. tem inspected.
Page 20: Door Locks
NOTE: • If you lose your immobilizer ignition key or remote controller, see your authorised Maruti Suzuki workshop as soon as pos- sible to have the lost one deactivated, then have the new key or remote con- troller made by them.
Page 21 BEFORE DRIVING Central Door Locking System NOTE: You can switch the function that unlocks all EXAMPLE doors from twice operations to once opera- EXAMPLE tion, and vice versa, via the setting mode of the information display. For details on how to use the information display, refer to “Information Display”...
Page 22 BEFORE DRIVING NOTE: Child-Proof Locks (Rear door) Tailgate • You can also lock or unlock all doors by operating the transmitter or remote con- EXAMPLE troller. Refer to “Keyless Push Start Sys- tem Remote Controller/Keyless Entry System Transmitter” in this section. •...
Page 23: Keyless Push Start System Remote Controller/Keyless Entry System Transmitter (If Equipped)
BEFORE DRIVING Keyless Push Start System WARNING EXAMPLE Remote Controller/Keyless Always make sure that the tailgate is Entry System Transmitter closed and latched securely. Com- (If equipped) pletely closing the tailgate helps pre- vent occupants from being thrown from the vehicle in the event of an Type A Type B accident.
Page 24 • If radio wave interference is a con- You can lock or unlock all doors (including cern, have the function of the the tailgate) simultaneously by operating antenna(s) disabled by your autho- the remote controller near the vehicle. rised Maruti Suzuki workshop.
Page 25 BEFORE DRIVING Central door locking system Be sure the doors are locked after you NOTE: • To lock all doors, push the “LOCK” but- operate the “LOCK” button (1). • If you lock the doors using the remote ton (1) once. If no door is opened within about 30 sec- controller when the engine hood are •...
Page 26 “Information Display” in this section. • If you lose one of the remote controllers, EXAMPLE ask your authorised Maruti Suzuki work- When the doors are unlocked: shop as soon as possible for a replace- • The turn signal lights will flash twice and 68PM02001 ment.
Page 27 BEFORE DRIVING NOTE: NOTE: • The door locks cannot be operated by • If the remote controller is outside the NOTICE the request switch under the following request switch operating range The remote controller is a sensitive conditions: described above, you will not be able to electronic instrument.
Page 28 EXAMPLE • If you lose one of the remote controllers, With the ignition mode changed to “LOCK” ask your authorised Maruti Suzuki work- (OFF) by pressing the engine switch, bring shop as soon as possible for a replace- out the remote controller if it is inside the ment.
Page 29 BEFORE DRIVING The indicator light will turn off within sev- Replacement of the battery eral seconds after the remote controller is If the remote controller becomes unreli- EXAMPLE returned to an area of the vehicle other able, replace the battery. than the rear luggage area.
Page 30 BEFORE DRIVING Keyless Entry System Transmitter Central door locking system WARNING • To lock all doors, push the “LOCK” but- (Type B) ton (1) once. Swallowing a lithium battery may • To unlock only the driver’s door, push the EXAMPLE cause serious internal injury.
Page 31 5 sec- • If you lose one of the transmitters, ask onds, the siren will not sound. However, your authorised Maruti Suzuki workshop NOTE: If you push one of the buttons twice as soon as possible for a replacement.
Page 32 BEFORE DRIVING Replacement of the battery If the transmitter becomes unreliable, EXAMPLE WARNING replace the battery. Swallowing a lithium battery may cause serious internal injury. Do not To replace the battery of the transmitter: allow anyone to swallow a lithium battery.
Page 33: Security System (If Equipped)
To set the shock sen- we recommend you explain the system sor, ask your authorised Maruti Suzuki and its operation to the person, or dis- workshop or use the setting mode of the able the system beforehand.
Page 34 Ask your authorised system will be rearmed with a delay of lights start to blink and the interior buzzer beeps intermittently. After 5 sec- Maruti Suzuki workshop to inspect the about 5 seconds. system. • If you disconnect the battery while the onds, the siren will sound for about 27.5...
Page 35 BEFORE DRIVING (If the shock sensor is in the enabled state) 1) Sit in the driver’s seat and make sure • If the vehicle feels a shock higher than that all doors, tailgate and engine hood EXAMPLE the pre-warning sensitivity, the siren are closed.
Page 36: Theft Deterrent Light (If Equipped)
BEFORE DRIVING Theft Deterrent Light 4) Turn the knob on the lighting control lever to the position and then turn System state Number of beeps (If equipped) back to the OFF position. Repeat this operation 4 times. Disabled Once 3 times Enabled 4 times •...
Page 37: Windows
BEFORE DRIVING Windows Electric Window Controls Driver’s side (Type B) The electric windows can only be operated Manual Window Control EXAMPLE when the ignition switch is in the “ON” (If equipped) position or the ignition mode is “ON”. EXAMPLE Driver’s side (Type A) EXAMPLE 68PH00225 The driver’s door has a switch (1) to oper-...
Page 38 BEFORE DRIVING Passenger’s door The driver’s window has “auto-down” and “auto-up” (If equipped) features for added WARNING EXAMPLE convenience (at toll booths or drive- • You should always lock the pas- through restaurants, for example). This senger’s window operation when means the driver can open or close the there are children in the vehicle.
Page 39 Have your vehicle inspected by When you disconnect and re-connect the the occupant’s body such as hands an authorised Maruti Suzuki workshop. battery or replace the fuse, the function will or head is in the path of the electric be deactivated.
Page 40: Mirrors
BEFORE DRIVING Mirrors When driving at night, you can move the You can adjust the auto dimming rearview selector tab to the night position to reduce mirror by hand so you can see to the rear Inside Rearview Mirror glare from the headlights of vehicles of your vehicle in the mirror.
Page 41 BEFORE DRIVING Outside Rearview Mirrors Electric Mirrors (If equipped) EXAMPLE EXAMPLE EXAMPLE 68PH00230 68PH00231 68PH00232 WARNING Adjust the outside rearview mirrors so you The switch to control the electric mirrors is can just see the side of your vehicle in the located on the driver’s door panel.
Page 42: Front Seats
BEFORE DRIVING Front Seats Outside Rearview Mirrors Folding Switch (If equipped) Seat Adjustment EXAMPLE WARNING Never attempt to adjust the driver’s seat or seatback while driving. The seat or seatback could move unex- pectedly, causing loss of control. Make sure that the driver’s seat and seatback properly adjusted...
Page 43 BEFORE DRIVING Seat position adjustment lever (1) Pull the lever up and slide the seat. EXAMPLE Seatback angle adjustment lever (2) Pull the lever up and move the seatback. Seat height adjustment lever (3) (If equipped) Pull the lever up to raise the seat. Push the lever down to lower the seat.
Page 44: Rear Seats
BEFORE DRIVING Rear Seats Head Restraints NOTE: It may be necessary to recline the seat- Head Restraints (If equipped) EXAMPLE back to provide enough overhead clear- Head restraints are designed to help ance to remove the head restraint. reduce the risk of neck injuries in the case of an accident.
Page 45 BEFORE DRIVING Rear Folding Rear Seats WARNING The rear seat(s) of your vehicle can be EXAMPLE folded forward to provide additional cargo If you need to carry cargo in the pas- space. senger compartment with the rear seat back folded forward, be sure to To fold the rear seats forward: secure the cargo or it may be thrown about, causing injury.
Page 46: Seat Belts And Child Restraint Systems
BEFORE DRIVING Seat Belts and Child Restraint NOTICE Systems • When returning the rear seatback to the normal position, do not allow EXAMPLE any foreign material to enter the lock opening. This may prevent the seatback from being locked securely. •...
Page 47 BEFORE DRIVING EXAMPLE EXAMPLE EXAMPLE as low as possible across the hips Above the pelvis Across the pelvis 65D606 65D201 65D199 WARNING WARNING WARNING • Never allow persons to ride in the (Continued) (Continued) cargo area of a vehicle. In the event •...
Page 48 BEFORE DRIVING Lap-Shoulder Belt WARNING WARNING Emergency locking retractor (ELR) (Continued) (Continued) The seat belt has an emergency locking • Never use the same seat belt on • For children, if the shoulder belt retractor (ELR), which is designed to lock more than one occupant and never irritates the neck or face, move the the seat belt only during a sudden stop or...
Page 49 BEFORE DRIVING All Seat Belts Except Rear Center WARNING All seat belts except rear center are the EXAMPLE lap-shoulder belt. If rear outside seat belt is fastened Low on hips without unhooking the webbing from EXAMPLE the belt guide (1), the seat belt does not show full performance in the event of accident and can result in serious personal injury.
Page 50 BEFORE DRIVING Lap Belt EXAMPLE EXAMPLE Rear Center Seat Belt To fasten the belt, pull the latch plate attached to the seat belt across your hips and press it straight into the buckle until you hear a “click”. To reduce the risk of sliding under the belt during a collision, position the belt across your lap as low on your hips as possible and adjust it to a...
Page 51 BEFORE DRIVING To unfasten the belt, press the release but- Driver’s Seat Belt Reminder ton on the buckle catch. With tachometer TO LOOSEN EXAMPLE EXAMPLE Right angle EXAMPLE 80JS029 To lengthen, release the latch plate from 79MH0239 68PH00239 the buckle, pull the latch plate (adjuster) in the direction of the arrow, at right angles to NOTE: Without tachometer...
Page 52 BEFORE DRIVING When the driver does not buckle his or her engine switch is pressed to change the Shoulder Anchor Height Adjuster seat belt, the driver’s seat belt reminder ignition mode to “LOCK” (OFF). (If equipped) light in the instrument cluster will come on or blink and a buzzer will sound as a WARNING EXAMPLE...
Page 53 BEFORE DRIVING Rear Outside Seat Belt Guide WARNING WARNING EXAMPLE If rear outside seat belt is fastened Be sure to inspect all seat belt without unhooking the webbing from assemblies after any collision. Any the belt guide (1), the seat belt does seat belt assembly which was in use not show full performance in the during a collision (Other than a very...
Page 54 EXAMPLE 80JC007 80JC008 Child restraint MARUTI SUZUKI highly recommends that you use a child restraint system to restrain EXAMPLE infants and small children. Many different types of child restraint systems are avail- able; make sure that the restraint system you select meets applicable safety stan- dards.
Page 55 BEFORE DRIVING Installation with Lap-Shoulder Seat WARNING EXAMPLE Belts If you install a child restraint system Rear outside seat belt guide in the rear seat, slide the front seat far enough forward so that the child’s EXAMPLE feet do not touch the front seatback. This will help avoid injury to the child in the event of an accident.
Page 56 BEFORE DRIVING ELR type belt Installation with a Lap Belt Installation with ISOFIX type anchorages (If equipped) EXAMPLE EXAMPLE Pull to tighten 68PH00243 EXAMPLE 68PH00244 Install your child restraint system accord- Install your child restraint system accord- 54P000223 ing to the instructions provided by the child ing to the instructions provided by the child Your vehicle is equipped with the lower restraint system manufacturer.
Page 57 BEFORE DRIVING Install the ISOFIX type child restraint sys- Here is a general instruction: tem according to the instructions provided EXAMPLE CAUTION by the child restraint system manufacturer. After installation, try moving the child Adjust the height of the rear head restraint system in all directions especially restraint or remove it for fitting the forward to check that connecting bars are...
Page 58 BEFORE DRIVING 2) Use your hands to carefully align the Installation of child restraint with connecting bar tips with the anchor- top tether (If equipped) EXAMPLE ages. Take care not to pinch your fin- Type A gers. EXAMPLE EXAMPLE Front 54G185 4) Grasp the front of the child restraint and push the child restraint forcefully to...
Page 59 Incorrectly NOTE: attached top tether strap will reduce Maruti Suzuki recommends use of Maruti the intended effectiveness of the child restraint system. Suzuki Genuine accessory of “Child seat, ISOFIX”. 2-41...
Page 60: Child Restraint System For India
BEFORE DRIVING Child Restraint System for India Child Restraint The suitability of each passenger’s seat position for carriage of children and fitting of child restraint system is shown in the table below. Whenever you carry children up to 12 years of age, properly use the child restraints which conform to AIS 072, the standard for child restraints, referring to the table.
Page 61 BEFORE DRIVING Seat Belt Pretensioner System To determine if your vehicle is equipped some smoke may be released. These con- with a seat belt pretensioner system at the ditions are not harmful and do not indicate a front seating positions, check the label on fire in the vehicle.
Page 62 Have both systems inspected by an authorised Maruti Suzuki workshop as soon as possi- ble. Service on or around the pretensioner sys- tem components or wiring must be per- formed only by an authorised Maruti Suzuki workshop who is specially trained.
Page 63: Supplemental Restraint System (Air Bags)
BEFORE DRIVING Supplemental Restraint EXAMPLE System (Air bags) WARNING This section of the owner’s manual describes the protection provided by your Vehicle’s SUPPLEMENTAL RESTRAINT SYSTEM (air bags). Please read and follow ALL these instructions carefully to minimize your risk of severe injury or death in the event of a collision.
Page 64 (Or the seat belt pretensioner pants from further movements during the system) may not work properly. Have the accident. air bag system inspected by an authorised Maruti Suzuki workshop as soon as possi- ble. 2-46...
Page 65 BEFORE DRIVING Therefore, an air bag is NOT a substitute Front passenger’s front air bag for seat belts. To maximize your protection, EXAMPLE ALWAYS WEAR YOUR SEAT BELTS. Be EXAMPLE aware that no system can prevent all pos- sible injuries that may occur in an accident. Driver’s front air bag EXAMPLE 58MS030...
Page 66 BEFORE DRIVING Conditions of front air bags deployment Conditions of front air bags may inflate (Inflation) Receiving a strong impact to the lower EXAMPLE body of your vehicle, the front air bags will EXAMPLE inflate in many cases. EXAMPLE 80J101 •...
Page 67 BEFORE DRIVING Front air bags may not inflate The front air bags may not inflate when the EXAMPLE EXAMPLE impact is absorbed since the collision object moved, vehicle body deformed, or collision angle was greater than about 30 degrees from the front. EXAMPLE 80J119 80J104...
Page 68 BEFORE DRIVING How the system works in this section for details on proper seat EXAMPLE and seat belt adjustments. In a frontal collision, the crash sensors will detect rapid deceleration, and if the con- troller judges that the deceleration rep- resents a severe frontal crash, the controller will trigger the inflators.
Page 69 These objects may interfere with air ing or replacing an air bag. For that rea- bag operation or may be propelled son, only an authorised Maruti Suzuki by the air bag in the event of a workshop should be allowed to service or crash.
Page 70: Instrument Cluster (Type A) (If Equipped)
BEFORE DRIVING Instrument Cluster (Type A) (If equipped) 1. Speedometer 2. Fuel gauge 3. Information display 4. Trip meter selector knob 5. Indicator selector knob 6. Warning and indicator lights EXAMPLE 68PH02201 2-52...
Page 71: Speedometer
BEFORE DRIVING Speedometer Fuel Gauge NOTE: The activation point of the low fuel warning The speedometer indicates vehicle speed. light (1) varies depending on road condi- tions (for example, slope or curve) and driving conditions because of fuel moving in the tank. Refer to “Low Fuel Warning Light”...
Page 72: Brightness Control
BEFORE DRIVING Brightness Control Information Display WARNING EXAMPLE If you attempt to adjust the display while driving, you could lose control of the vehicle. Do not attempt to adjust the display while driving. NOTE: • If you do not turn the knob for more than 5 seconds while activating the bright- ness control, the brightness control dis- play will be canceled automatically.
Page 73 BEFORE DRIVING Clock NOTE: When you reconnect the negative (–) ter- When the ignition switch is in the “ON” EXAMPLE position, the display (A) shows the time. minal to the battery, the clock indication will be reinitialized. Change the indication To change the time indication: again to your preference.
Page 74 BEFORE DRIVING NOTE: (a) Trip meter A EXAMPLE The indicated maximum value of the trip EXAMPLE (b) Trip meter B meter is 9999.9. When you run past the (c) Odometer maximum value, the indicated value will (d) Instantaneous fuel consumption return to 0.0.
Page 75 BEFORE DRIVING sumption is 50. No more than 50 will be value of average fuel consumption will be Driving range indicated on the display even if the shown after driving for a while. If you selected driving range the last time actual instantaneous fuel consumption is you drove the vehicle, the display indicates higher.
Page 76 BEFORE DRIVING Setting mode In the setting mode, you can set up the following functions. Indication Functions Time indication of clock “ ” Central door locking system “ ” Automatic door locking function “ ” Automatic door unlocking function “ ”...
Page 77 BEFORE DRIVING Indication Functions Additional flashes of the turn signal “ ” Initialization setting “ ” Exit the setting mode “ ” 2-59...
Page 78 BEFORE DRIVING Time indication of clock “ ” Initialization setting “ ” Turn the indicator selector knob • : 12-hour format (Default set- • : Initialize all settings (2). ting) • : 24-hour format EXAMPLE Central door locking system “ ”...
Page 79: Instrument Cluster (Type B) (If Equipped)
BEFORE DRIVING Instrument Cluster (Type B) (If equipped) 1. Speedometer 2. Tachometer 3. Fuel gauge 4. Temperature gauge 5. Information display 6. Trip meter selector knob 7. Indicator selector knob 8. Warning and indicator lights EXAMPLE 68PH02208 2-61...
Page 80: Speedometer
BEFORE DRIVING Speedometer Fuel Gauge Refer to “Low Fuel Warning Light” in “Warning and Indicator Lights” in this sec- The speedometer indicates vehicle speed. tion for details. Tachometer The mark (2) indicates that the fuel filler door is located on the left side of the vehi- The tachometer indicates engine speed in cle.
Page 81: Temperature Gauge
BEFORE DRIVING Temperature Gauge Brightness Control To reduce the brightness of the instrument panel lights, turn the brightness control knob (1) counterclockwise. EXAMPLE WARNING If you attempt to adjust the display while driving, you could lose control of the vehicle. Do not attempt to adjust the display while driving.
Page 82: Information Display
BEFORE DRIVING Information Display Thermometer EXAMPLE When the ignition switch is in the “ON” The information display is shown when the position, the display (A) shows the ther- ignition switch is in the “ON” position. mometer. The thermometer indicates the outside temperature.
Page 83 BEFORE DRIVING Selector position (For CVT vehi- Push the trip meter selector cles) / Gearshift indicator (For man- EXAMPLE knob (2). ual transaxle vehicles) Push the indicator selector EXAMPLE knob (3). (b) b (c) Trip meter A (d) Trip meter B (e) Odometer (f) Instantaneous Fuel Consumption 68PH02215...
Page 84 BEFORE DRIVING Trip meter Instantaneous fuel consumption Average fuel consumption The trip meter can be used to measure the If you selected instantaneous fuel con- If you selected average fuel consumption distance traveled on short trips or between sumption the last time you drove the vehi- the last time you drove the vehicle, the dis- fuel stops.
Page 85 BEFORE DRIVING Driving range Clock If you selected driving range the last time When the ignition switch is in the “ON” posi- EXAMPLE you drove the vehicle, the display indicates tion, the display (D) shows the time. “---” for a few seconds and then indicates To change the time indication: the current driving range when the ignition 1) Push the trip meter selector knob (2) and...
Page 86 BEFORE DRIVING Setting mode In the setting mode, you can set up the following functions. Indication Functions Central door locking system “ ” Automatic door locking function “ ” Automatic door unlocking function “ ” Door locking and unlocking siren “ ”...
Page 87 BEFORE DRIVING Indication Functions Security system “ ” Shock sensor “ ” Pre-warning sensitivity of the shock sensor “ ” Full blast warning sensitivity of the shock sensor “ ” Initialization setting “ ” Exit the setting mode “ ” How to operate the setting mode: Turn the indicator selector knob 1) When the ignition switch is in the “ON”...
Page 88 BEFORE DRIVING Central door locking system “ ” Door locking and unlocking Pre-warning sensitivity of • : Unlock all doors by turning the siren “ ” the shock sensor “ ” key or pushing the keyless • : Siren sounds when •...
Page 89 BEFORE DRIVING EXAMPLE 68PM00272 NOTE: • As shown in the above illustration, “SEL” indicates on the display of currently set- ting item. • To go back to the higher level display during operation, turn the indicator selector knob (3) to display “ ”...
Page 90: Instrument Cluster (Type C) (If Equipped)
BEFORE DRIVING Instrument Cluster (Type C) (If equipped) 1. Speedometer 2. Tachometer 3. Fuel gauge 4. Temperature gauge 5. Information display 6. Trip meter selector knob 7. Indicator selector knob 8. Warning and indicator lights EXAMPLE 68PH02222 2-72...
Page 91: Speedometer
BEFORE DRIVING Speedometer Fuel Gauge Refer to “Low fuel warning light” in “Warn- ing and indicator lights” in this section for The speedometer indicates vehicle speed. details. Tachometer The mark (2) indicates that the fuel filler door is located on the left side of the vehi- The tachometer indicates engine speed in cle.
Page 92: Temperature Gauge
BEFORE DRIVING Temperature Gauge Brightness Control WARNING EXAMPLE EXAMPLE Do not adjust the brightness of the instrument panel lights while driving. Otherwise, you could lose control of the vehicle. NOTE: • If you do not turn the knob for more than 5 seconds while activating the bright- ness control, the brightness control dis- play will be canceled automatically.
Page 93: Information Display
BEFORE DRIVING Information Display Display (D) Gearshift indicator / Gear position indicator EXAMPLE The information display is shown when the ignition mode is “ON”. Display (E) Trip meter EXAMPLE Display (F) Odometer EXAMPLE 68PM00253 (2) Indicator selector knob (3) Trip meter selector knob 68PH02226 The information display shows the follow- (1) Information display...
Page 94 BEFORE DRIVING Clock Fuel consumption / Driving range / The display (A) shows the time. Average speed / Driving time Clock and date / Torque and power To set the clock, follow “Setting mode” When there are no warning or indicator instructions in this section.
Page 95 BEFORE DRIVING To switch the display indication, push the indicator selector knob (2) quickly. EXAMPLE NOTE: The value of instantaneous fuel consump- tion, average fuel consumption, driving range, average speed and torque and power shown on the display are affected by the following conditions;...
Page 96 BEFORE DRIVING Instantaneous fuel consumption • For “MPG(UK)” setting, the indicated (Average fuel consumption) The display shows instantaneous fuel con- maximum value of instantaneous fuel sumption with a bar graph only when the consumption is 80. No more than 80 will EXAMPLE vehicle is moving.
Page 97 BEFORE DRIVING You can select when the value of average (5-minute average fuel consumption) Driving range fuel consumption is reset from among the following two methods; EXAMPLE EXAMPLE • Reset after refuel: the value of average fuel consumption will be reset automati- cally by refueling.
Page 98 BEFORE DRIVING condition, the value is different each time If you selected average speed the last time (5-minute average speed) you refuel. you drove the vehicle, the display indicates the last value of average speed from previ- EXAMPLE ous driving when the engine switch is NOTE: pressed to change the ignition mode to •...
Page 99 BEFORE DRIVING Driving time Torque and Power Torque and Power display Present engine torque and power are Display (e) shows Torque and Power EXAMPLE shown. graphs at various vehicle condition. This figure is for reference only and indica- Information of after driving tion may not be same as actual value.
Page 100 BEFORE DRIVING Trip meter • To select the setting that you want to • If you turn the ignition switch, press the change, turn the indicator selector knob engine switch or start to move the vehi- The display (E) shows the trip meter. (2) left or right.
Page 101 BEFORE DRIVING NOTE: (Adjusting the date) Antitheft (Theft deterrent alarm system When you change the units that tempera- Adjust year, month, and day by operating setting) (If equipped) ture is displayed in, the automatic heating the indicator selector knob (2) in the same You can switch the theft deterrent alarm and air conditioning system (If equipped) way as the adjusting the clock.
Page 102 BEFORE DRIVING Fuel eco history NOTE: (Fuel economy history setting) • When the problem that causes a mes- Transitional indication of average fuel sage to appear is corrected, the mes- consumption can be switched to timed sage will disappear. indication and driving cycle indication. •...
Page 103 BEFORE DRIVING Warning and indicator messages All model Warning and indicator Master warning Sound Cause and remedy message indicator light Blinks Beep (One time from interior A door or tailgate is not properly closed. (Only while vehi- buzzer; only while vehicle is Stop the vehicle in a safe place and close cle is in motion) in motion)
Page 104 BEFORE DRIVING Warning and indicator Master warning Sound Cause and remedy message indicator light Beep (One time from interior Fuel is low. Refill it immediately. (#1) buzzer) 68PH02234 The road may be icy. Drive very carefully. (#1) 68PH02235 (#1) This message will disappear for a while even if the problem that caused the message to appear is not corrected. 2-86...
Page 105 BEFORE DRIVING Warning and indicator Master warning Sound Cause and remedy message indicator light This message is displayed when “ACC” position is selected as the power supply position. (#1) 68PH02237 The clutch pedal is depressed. Press the engine switch to start the engine. 68PH02238 (#1) This message will disappear for a while even if the problem that caused the message to appear is not corrected.
Page 106 Also, the vehicle battery volt- age may be decreased. When the message is displayed even if you start the engine with normal voltage of the vehicle battery, have your vehicle inspected by an authorised Maruti Suzuki workshop. 68PH02240 2-88...
Page 107 BEFORE DRIVING Warning and indicator Master warning Sound Cause and remedy message indicator light Blinks Series of beeps under cer- The remote controller may be outside the tain conditions (For about 2 vehicle or its battery may have become dis- seconds from exterior and/or charged.
Page 108 BEFORE DRIVING Warning and indicator Master warning Sound Cause and remedy message indicator light This message is displayed when “ON” posi- tion is selected as the power supply posi- tion. (#1) 68PH02243 Blinks Beep (One time from interior The steering lock is not disengaged. While buzzer) lightly turning the steering wheel in both directions, press the engine switch again.
Page 109 BEFORE DRIVING Warning and indicator Master warning Sound Cause and remedy message indicator light The remote controller battery is about to become flat. Replace the battery. (#1) 68PH02245 The engine switch is pressed without depressing the brake and clutch pedals. Try again as instructed by the message.
Page 110 Beep (One time from interior There may be a problem with the fuel filter. buzzer) Have your vehicle inspected by an autho- rized Maruti Suzuki workshop. 68PH02247 Blinks Beep (One time from interior It is possible that water may be in the fuel buzzer) filter.
Page 111 BEFORE DRIVING Warning and indicator Master warning Sound Cause and remedy message indicator light If the coolant temperature is cool enough, this message is displayed when the engine switch is pressed to change the ignition mode to “ON” and this message will disap- pear when the glow plug is heated enough for engine starting.
Page 112: Warning And Indicator Lights
The light also comes on together with the your authorised Maruti Suzuki work- shown on the information display. ABS warning light when the rear brake shop to inspect the brake system.
Page 113 1) Pull off the road and stop carefully. tem should be inspected by your autho- 2) Turn the ignition switch to “LOCK” or rised Maruti Suzuki workshop before you change the ignition mode to “LOCK” drive the vehicle again. (OFF) by pressing the engine switch and then start the engine again.
Page 114 If the light comes on when the engine is running, the charging WARNING system should be inspected immediately by your authorised Maruti Suzuki work- If the “AIR BAG” light does not blink shop. or come on briefly when the ignition switch is turned to the “ON”...
Page 115 Ask your authorised “ON” to let you know the light is working Maruti Suzuki workshop to have the sys- Open Door Warning Light and goes out when the engine is started.
Page 116 Have the system inspected by your mode to “ON”. authorised Maruti Suzuki workshop. NOTE: NOTE: The activation point of this light varies Following operations of the steering wheel...
Page 117 If this light blinks, there is a problem with the system. Have your vehicle inspected by your authorised Maruti Suzuki work- shop. 50G055 64J045 When you turn on the left or right turn sig-...
Page 118: Lighting Control Lever
(If equipped) Drain water as soon as possible. Have EXAMPLE your vehicle inspected by an authorised Maruti Suzuki workshop. Master Warning Indicator Light (If equipped) 60A543 If the coolant temperature is cool enough, this light comes on when the ignition switch is turned to the “ON”...
Page 119 BEFORE DRIVING Lighting Operation Automatic Lights Operation (If equipped) EXAMPLE EXAMPLE EXAMPLE 68PH00251 68PH00250 With the headlights on, push the lever for- 68PH00252 To turn the lights on or off, twist the knob ward to switch to the high beams (Main on the end of the lever.
Page 120 BEFORE DRIVING ON: Lights ON To turn the lights on or off, twist the knob LIGHT: When it is light around the light sensor (5). on the end of the lever. There are four DARK: When it is dark around the light sensor (5). positions: Ignition mode OFF (1)
Page 121 BEFORE DRIVING NOTE: Auto-on headlight system • Avoid covering the light sensor area of EXAMPLE the windshield with a sticker. The sticker EXAMPLE may impair the performance of the sen- sor and make the system unable to con- trol operation of the lights correctly. •...
Page 122 BEFORE DRIVING Light Reminder Buzzer Guide Me Light (Vehicle with auto- WARNING The interior buzzer continuously beeps if matic lights operation) you open the driver’s door without turning It takes about 5 seconds for the light off the headlights and position lights. This Follow me home function sensor to react to a change in light- function is triggered under the following...
Page 123: Headlight Leveling Switch
BEFORE DRIVING Headlight Leveling Switch mation display. Refer to “Information Dis- Front Fog Light Switch play” in this section. (If equipped) EXAMPLE Lead to vehicle function EXAMPLE If the “UNLOCK” button of the remote con- troller is pressed while the lighting switch is positioned in the “AUTO”, the front position lights and the headlights in the low beam are turned on for 10, 15, 20, 25 or 30 sec-...
Page 124: Turn Signal Control Lever
BEFORE DRIVING Turn Signal Control Lever Vehicle with the halogen headlights Normal turn signal Switch Vehicle Load Condition Position EXAMPLE Driver only Driver + 1 passenger (in front seat) Driver + 4 passengers, no cargo Driver + 4 passengers, cargo added EXAMPLE Driver + full cargo 68PH00258...
Page 125: Hazard Warning Switch
Use the hazard warning lights to warn and its indicator. Please ask an authorised steering wheel. other traffic during emergency parking or Maruti Suzuki workshop for the customiza- when your vehicle could otherwise become tion. a traffic hazard. Wiper and Washer Operation When the ignition switch is in the “ON”...
Page 126 BEFORE DRIVING Windshield Wipers Windshield Washer NOTICE To help prevent damage to the wind- shield wiper and washer system components, you should take the fol- lowing precautions: • Do not continue to hold in the lever when there windshield washer fluid being sprayed or the washer motor can be damaged.
Page 127: Tilt/Telescoping (If Equipped) Steering Lock Lever
BEFORE DRIVING Tilt/Telescoping (If equipped) Rear Window Wiper/Washer Switch NOTICE (If equipped) Steering Lock Lever Clear ice or snow from the rear win- EXAMPLE dow and rear wiper blade before EXAMPLE using the rear wiper. Accumulated Washer ice or snow could prevent the wiper blade from moving, causing damage to the wiper motor.
Page 128: Horn
BEFORE DRIVING Horn Heated Rear Window Switch WARNING (If equipped) Never attempt to adjust the steering EXAMPLE wheel while the vehicle is moving or you could lose control of the vehicle. EXAMPLE 68PH00265 Press the horn button of the steering wheel 68PH00266 to sound the horn.
Page 129 BEFORE DRIVING NOTE: • The defogger will work only when the engine is running. • The defogger will automatically turn off after the defogger remains on for 15 min- utes to prevent discharging of the bat- tery. 2-111...
Page 130: Operating Your Vehicle
OPERATING YOUR VEHICLE OPERATING YOUR VEHICLE Exhaust Gas Warning ............3-1 Daily Inspection Checklist ..........3-1 Engine Oil Consumption ............ 3-2 Ignition Switch (Vehicle without keyless push start system) ....3-3 Engine Switch (Vehicle with keyless push start system) ......3-5 Keyless Push Start System (If equipped) ......
Page 131: Exhaust Gas Warning
OPERATING YOUR VEHICLE Exhaust Gas Warning Daily Inspection Checklist WARNING Before Driving EXAMPLE (Continued) • Do not park with the engine run- EXAMPLE ning for a long period of time, even in an open area. If it is necessary to sit for a short time in a parked vehi- cle with the engine running, make sure the air intake selector is set to...
Page 132: Engine Oil Consumption
OPERATING YOUR VEHICLE Engine Oil Consumption NOTE: 6) Hood latch operation It is normal for water to drip from the air Pull the hood release handle inside the conditioning system after use. vehicle. Make sure that you cannot It is normal for the engine to consume open the hood all the way without some engine oil during normal vehicle 4) Make sure the hood is fully closed and...
Page 133: Ignition Switch
OPERATING YOUR VEHICLE Ignition Switch You should also be aware that the diluting The ignition switch has the following four ingredients evaporate out when the vehicle positions: (Vehicle without keyless push is subsequently driven at high speeds, start system) such as on an expressway, making it LOCK appear that oil is excessively consumed This is the normal parking position.
Page 134 Maruti Suzuki workshop. • Do not leave the ignition switch in the “ON” position if the engine is not running as the battery will dis-...
Page 135: Engine Switch
OPERATING YOUR VEHICLE Engine Switch NOTE: • With the engine off In the presence of strong radio signals or (Vehicle with keyless push You can use such electric equipment as noise, you may not be able to change the start system) the power windows and wipers with the ignition mode to “ACC”...
Page 136: Keyless Push Start System (If Equipped)
OPERATING YOUR VEHICLE Keyless Push Start System illumination will go out when the position 1) Bring the keyless push start system lights and/or the headlights are turned remote controller with you and sit in the (If equipped) off. driver’s seat. Provided the keyless push start system 2) Without depressing the clutch pedal, EXAMPLE...
Page 137 To be able to select an the keyless push start system. Contact interior and exterior buzzers.At the same ignition mode, you must then use the follow- an authorised Maruti Suzuki workshop time the immobilizer/keyless push start ing method: for an inspection of the system.
Page 138 OPERATING YOUR VEHICLE (OFF) by pressing the engine switch and Interior Workable Area for Engine EXAMPLE then perform the engine starting opera- Starting, Ignition Mode Selection tion Refer to “Starting the Engine” in this and “Remote Controller Outside” section. Warning •...
Page 139: Parking Brake Lever
68PHM3001 fully release, have your vehicle (1) To set inspected immediately by autho- (2) To release rised Maruti Suzuki workshop. (3) To release The parking brake lever is located between WARNING the seats. To set the parking brake, hold Always set the parking brake fully...
Page 140: Pedal
OPERATING YOUR VEHICLE Pedal Brake Pedal (2) WARNING Your vehicle is equipped with front disc Manual transaxle brakes and rear drum brakes. Depressing When parking vehicle the brake pedal applies both sets of extremely cold weather, the following brakes. procedure should be used: You may hear occasional brake squeal 1) Set the parking brake.
Page 141: Starting The Engine (Vehicle Without Keyless Push Start System)
OPERATING YOUR VEHICLE Starting the Engine NOTE: If the engine does not start after 12 sec- CVT vehicles have a starter interlock onds of cranking, wait about 15 seconds, (Vehicle without keyless push device which is designed to keep the then press down the accelerator pedal to start system) starter from operating if the transaxle is in...
Page 142: Starting The Engine (Vehicle With Keyless Push Start System)
Ask your EXAMPLE • You do not need to keep the engine authorised Maruti Suzuki workshop to switch pressed to start the engine. have the engine inspected. • The engine of a manual transaxle vehi-...
Page 143 If you are unable to start the engine using unexpectedly or was raced before stop- this procedure, consult your authorised ping, a clicking sound may be heard Maruti Suzuki workshop. 3-13...
Page 144 “remote controller out of sensing range” 68PH00304 warning. Please contact an authorised If the malfunction indicator light still comes Maruti Suzuki workshop for the customi- 1) Make sure the parking brake is set fully. on after the engine started, there may be zation.
Page 145: Using The Transaxle
Manual Transaxle • Disconnect the negative cable from the rised Maruti Suzuki workshop. battery to prevent discharge. “LOCK” (OFF) mode reminder buzzer If the driver’s door is opened without returning the ignition mode to “LOCK”...
Page 146 OPERATING YOUR VEHICLE Downshifting maximum allowable *NOTE: speeds You may not accelerate to the maximum NOTICE allowable speed because of the driving sit- For Petrol Engine • To help avoid clutch damage, do uation and/or the vehicle condition. not use the clutch pedal as a foot- (K10C model) rest while driving or use the clutch NOTICE...
Page 147 OPERATING YOUR VEHICLE Gearshift lever EXAMPLE Shift with the knob button (1) EXAMPLE pushed in and the brake pedal depressed. Shift with the knob button (1) pushed in. 68PH00312 (2) Sport mode indicator Shift without the knob button (1) pushed in. S (Sport) mode switch The sport mode switch (1) is used to turn on and off the sport mode.
Page 148 OPERATING YOUR VEHICLE R (Reverse) NOTE: If You Cannot Shift CVT Gearshift Use this position to reverse the vehicle If you move the gearshift lever to a lower Lever Out of “P” (Park) from stop. Make sure that vehicle is com- gear while driving faster than the maximum pletely stationary...
Page 149: Gearshift Indicator (If Equipped)
EXAMPLE rised Maruti Suzuki workshop for repair. WARNING The gearshift indicator is designed to indicate optimal gear position for your driving, however, a driver will...
Page 150: Parking Sensors (If Equipped)
OPERATING YOUR VEHICLE Parking Sensors Example of the gearshift indicator (If equipped) Indication Description Information display symbol (If equipped) Lower gear position is selected for the vehicle speed and/or engine revolution. Changing to a higher gear position is recom- EXAMPLE mended.
Page 151 “R” position and an accident if you control the vehi- Maruti Suzuki workshop. the parking sensor switch is in the “ON” cle relying only on the parking sen- position. This function is helpful in the sor.
Page 152 OPERATING YOUR VEHICLE Working sensors Approximate areas where obstacles can The sensors that work depends on the position of the gearshift lever as follows: be detected EXAMPLE Manual transaxle Gearshift lever position N, 1st – 5th N, D or L Center Rear sensors Corner...
Page 153 OPERATING YOUR VEHICLE NOTE: WARNING WARNING • Thin poles or obstacles lower than the sensors may become undetectable as • Under the following conditions, the (Continued) the vehicle moves closer to them even if parking sensor system may not – Sensors have intercepted ultra- they have been detected from longer work normally because the sensors sonic noise from another vehi-...
Page 154 OPERATING YOUR VEHICLE • Turn the ignition switch to the “ON” position or press the engine switch to change the Obstacle Indication by Parking Sen- ignition mode to “ON” with the parking sensor switch in the “ON” position. • Push the switch again and it stays in; this is the OFF position. The indicator in the Information display symbol switch goes out and the parking sensor is deactivated.
Page 155 OPERATING YOUR VEHICLE • Warnings when obstacles are detected by corner sensors Set Sensors (If equipped) You can select either the normal or trailer Symbol mode of the parking sensor via the infor- Distance (Approx.) Buzzer (If equipped) mation display. Refer to “Information dis- play”...
Page 156: Rearview Camera (If Equipped)
If the buzzer does not stop after wiping, there may be problem with the matically shows the view behind the vehi- parking sensor system. Have your vehicle inspected by an authorised Maruti Suzuki cle on the display.
Page 157 OPERATING YOUR VEHICLE How to Use Rearview Camera NOTICE NOTICE 1) Press the engine switch to change the ignition mode to “ON”. If you use the rearview camera for a The rearview camera is a precision 2) Shift the gearshift lever in the “R” posi- long time when the ignition mode is instrument.
Page 158 OPERATING YOUR VEHICLE Example of display range of rearview – In dark areas, on a rainy day or at (1) Object camera night. (2) Actual distance – When the temperature around the lens (3) Distance on the display is too high/low, or the camera is wet EXAMPLE When there is an uphill incline behind the such as on a rainy day or during peri-...
Page 159: Braking
30 km/h. Start to brake the vehi- pressing the brake pedal once and holding rised Maruti Suzuki workshop as soon as cle when there is plenty of distance it down. The reserve power is partly used possible.
Page 160 OPERATING YOUR VEHICLE Brake Assist System • You may hear and operation sound when you start the engine or after the WARNING When you slam the brakes on, the brake assist system judges as an emergency vehicle begins the move. This means (Continued) that the above systems are in the self- stop and provides more powerful braking...
Page 161 ABS system. change braking pressure several times Ask your authorised Maruti Suzuki each second to prevent the wheels from workshop to inspect the ABS sys- locking. When you start your vehicle or tem immediately. If the ABS system...
Page 162: Driving Tips
DRIVING TIPS DRIVING TIPS Running-in ................4-1 Catalytic Converter ............. 4-1 Improving Fuel Economy ........... 4-2 Highway Driving ..............4-3 Driving on Hills ..............4-3 Driving on Slippery Roads ..........4-4 Driving on Wet Roads ............4-5 Do’s and Dont’s for Safe Driving ........4-6 Margin for Safety ..............
Page 163: Running-In
DRIVING TIPS Running-in Catalytic Converter EXAMPLE NOTICE EXAMPLE The future performance and reliabil- ity of the engine depends on the care and restraint exercised during its early life. It is especially important to observe the following precautions during the initial 960 km of vehicle 68PHM4001 operation.
Page 164: Improving Fuel Economy
DRIVING TIPS Improving Fuel Economy NOTICE EXAMPLE The following instructions will help you improve fuel economy. To minimize the possibility of catalyst or other vehicle damage: Avoid excessive idling • Maintain the engine in the proper If you are to wait for more than a minute operating condition.
Page 165: Highway Driving
DRIVING TIPS Highway Driving Driving on Hills Keep the air cleaner clean When driving at high speeds, pay attention EXAMPLE EXAMPLE to the following: • Stopping distance progressively increases with vehicle speed. Apply the brakes far enough ahead of the stopping point to allow for the extra stopping dis- tance.
Page 166: Driving On Slippery Roads
DRIVING TIPS Driving on Slippery Roads • When driving down a hill, the engine Tire Chains should be used for braking by shifting to Tire chains should only be used if they are next lower gear. (Do this with either a needed to increase traction or are required EXAMPLE CVT or a manual transaxle vehicle).
Page 167: Driving On Wet Roads
DRIVING TIPS Driving on Wet Roads If Your Vehicle Gets Stuck WARNING If your vehicle gets stuck in snow, mud, or sand, follow the directions below: NOTICE Do not allow anyone to stand near 1) Shift the transaxle back and forth the vehicle when you are rocking it, •...
Page 168: Do's And Dont's For Safe Driving
DRIVING TIPS Do’s and Dont’s for Safe WARNING EXAMPLE Driving (Continued) Exercise care in handling your vehicle. Be • Do not use tires other than those conscious of not only your own safety but specified MARUTI SUZUKI. also the safety of others on the road, and Never use different sizes or types thus enjoy the best and most comfortable of tires on the front and rear...
Page 169 DRIVING TIPS 3) Before moving, look around your vehi- Braking 5) When overtaking other vehicles, watch cle to confirm safety. out for oncoming vehicles and carefully 4) Don’t accelerate suddenly, since it is ensure safety. EXAMPLE dangerous and wastes fuel. 6) Don’t attempt zigzag driving as it will hinder your control over the vehicle and General driving...
Page 170 DRIVING TIPS Night time driving EXAMPLE EXAMPLE EXAMPLE 83K-04-011 83K-04-014 Use foot brake in three stages 83K-04-013 3) Don’t use headlights on high beam 1. Warn the vehicle behind you unless its use is inevitable. It may cause 1) Drive at lower speeds during the night 2.
Page 171: Margin For Safety
DRIVING TIPS Margin for Safety It is important to allow yourself a margin for safety during driving so that you can cope with erroneous or unexpected driving of other drivers. For that, observe the follow- ing. • Drive at a safe speed. •...
Page 172: Other Controls And Equipment
OTHER CONTROLS AND EQUIPMENT OTHER CONTROLS AND EQUIPMENT Fuel Filler Cap ..............5-1 Engine Hood ................ 5-2 Sun Visor ................5-4 Interior Light ................ 5-5 Accessory Socket ............... 5-8 AUX/USB Socket (If equipped) ........... 5-9 Assist Grips ................. 5-9 Coat Hooks ................5-9 Glove Box ................
Page 173: Fuel Filler Cap
OTHER CONTROLS AND EQUIPMENT Fuel Filler Cap The fuel filler cap is located on the left rear side of the vehicle. The fuel filler door can EXAMPLE be unlocked by pulling up the opener lever EXAMPLE located on the outboard side of the driver’s seat and locked by simply closing the door.
Page 174: Engine Hood
OTHER CONTROLS AND EQUIPMENT Engine Hood WARNING EXAMPLE If you need to replace the fuel cap, EXAMPLE use a MARUTI genuine cap. Use of an improper cap can result in a malfunc- tion of the fuel system or emission control system. It may also result in fuel leakage in the event of an acci- dent.
Page 175 OTHER CONTROLS AND EQUIPMENT To close the engine hood: 1) Lift the hood up slightly and remove the WARNING EXAMPLE prop rod from the hole. Put the prop rod Make sure the hood is fully closed back to the holding clip. and latched before driving.
Page 176: Sun Visor
OTHER CONTROLS AND EQUIPMENT Sun Visor Card holder (If equipped) You can put a card in the card holder (1) on Type1 the back of the sun visor. EXAMPLE NOTICE When you park your vehicle outdoors in direct sunlight or in hot weather, do not leave plastic cards in the holder.
Page 177: Interior Light
OTHER CONTROLS AND EQUIPMENT Interior Light WARNING EXAMPLE EXAMPLE • Do not use the mirror while driving your vehicle or could lose control of the vehicle. • When using the vanity mirror, do not move too close to a front air bag location or lean against it.
Page 178 OTHER CONTROLS AND EQUIPMENT Glove Box Light (If equipped) (1) Front (If equipped) (3) Center (4) Refer to “Glove Box” in this section. EXAMPLE EXAMPLE Footwell Lights (If equipped) (2) A footwell light is provided in the leg space in front of each front seat. The light comes on when the door is opened.
Page 179 OTHER CONTROLS AND EQUIPMENT DOOR (b) Courtesy Lights (If equipped) (5) Luggage Compartment The light comes on when the door is (If equipped) (6) EXAMPLE opened. After closing all doors, the light will remain on for about 15 seconds and EXAMPLE then fade out.
Page 180: Accessory Socket
OTHER CONTROLS AND EQUIPMENT Accessory Socket The accessory socket will work when the ignition switch is in the “ACC” or “ON” posi- EXAMPLE Center console tion, or the ignition mode is “ACC” or “ON”. EXAMPLE Each socket can be used to provide 12 volt/120 watt/10 ampere power for electri- cal accessories when used alone.
Page 181: Aux/Usb Socket (If Equipped)
OTHER CONTROLS AND EQUIPMENT AUX/USB Socket (If equipped) Assist Grips Coat Hooks EXAMPLE EXAMPLE EXAMPLE 68PH00520 68PH00521 68PH00522 Connect your portable digital music player, Assist grips are provided for convenience. You can hang clothing on the coat hooks. etc. to this socket to enjoy music through These hooks are not designed for large or the vehicle’s audio system using it as a NOTICE...
Page 182: Glove Box
OTHER CONTROLS AND EQUIPMENT Glove Box EXAMPLE EXAMPLE 68PH00524 The glove box light (If equipped) stays on 68PH00523 while the lid is open. To open the glove box, pull the latch lever. To close it, push the lid until it latches securely.
Page 183: Cup Holder And Storage Area
OTHER CONTROLS AND EQUIPMENT Cup Holder and Storage Area Driver’s Pocket (1) WARNING EXAMPLE Do not place any objects which may fall out from the pocket when the vehicle is moving. Failure to take the precaution may result in an object interfering with the (4)/(5) pedals and causing a loss of vehicle control or an accident.
Page 184 OTHER CONTROLS AND EQUIPMENT Front Cup Holders (2) / Front Bottle Holder (3) / Front Armrest with Console Box Rear Cup Holder (If equipped) (5) Rear Bottle Holder (7) (If equipped) (4) Always place the bottle with its cap closed WARNING NOTICE in the bottle holder.
Page 185: Footrest
OTHER CONTROLS AND EQUIPMENT Footrest Floor Mats (If equipped) Front Seat Back Pocket (If equipped) (6) EXAMPLE EXAMPLE EXAMPLE 68PH00529 68PH00530 68PH00528 Use the footrest (1) as a support for your To prevent the driver’s side floor mat from This pocket is provided for holding light left foot.
Page 186: Luggage Compartment Hook (If Equipped)
OTHER CONTROLS AND EQUIPMENT Luggage Compartment Hook Luggage Compartment Cover WARNING (If equipped) Failure to take the following precau- EXAMPLE tions may result in the driver’s side EXAMPLE floor mat interfering with the pedals and causing a loss of vehicle control or an accident.
Page 187: Frame Hooks
OTHER CONTROLS AND EQUIPMENT Frame Hooks EXAMPLE EXAMPLE Front EXAMPLE 61MM0B039 68PM05006 1) Pick up the towing hook (1), jack handle 2) Remove the cover (C) by using a jack (A) and wheel brace (B) that are stowed handle (A) covered with a soft cloth as 68PM05005 in the luggage compartment.
Page 188: Heating And Air Conditioning System
OTHER CONTROLS AND EQUIPMENT Heating and Air Conditioning Rear EXAMPLE System EXAMPLE There are two of heating and air condition- ing systems as follows: • Manual Heating and Air Conditioning System • Automatic Heating and Air Conditioning System (Climate control) 68PM05008 68PM05009 4) To tighten the towing hook (1), turn it...
Page 189 OTHER CONTROLS AND EQUIPMENT Air Outlet (1) Windshield defroster outlet (2) Side defroster outlet (3) Side outlet (4) Center outlet (5) Floor outlet EXAMPLE 68PH00538 5-17...
Page 190 OTHER CONTROLS AND EQUIPMENT Center outlet Side outlet EXAMPLE EXAMPLE 68PH00540 Move the knob (1) vertically or horizontally, 68PH00539 to adjust the direction of airflow as desired. Move the knob (1) vertically or horizontally, to adjust the direction of airflow as desired. The side outlet opens when you turn the dial (2) upward and closes when you turn it downward.
Page 191: Manual Heating And Air Conditioning System
OTHER CONTROLS AND EQUIPMENT Manual Heating and Air Air flow selector (3) Bi-level (b) Conditioning System EXAMPLE EXAMPLE Description of Controls 68PH00542 68PH00544 This is used to select one of the functions Temperature-controlled air comes out of described below. the floor outlets and cooler air comes out EXAMPLE (4) (5) of the center and side outlets.
Page 192 OTHER CONTROLS AND EQUIPMENT Heat (c) Heat & defrost (d) Defrost (e) EXAMPLE EXAMPLE EXAMPLE 68PH00545 68PH00546 68PH00547 Temperature-controlled air comes out of Temperature-controlled air comes out of Temperature-controlled air comes out of the floor outlets and the side outlets, also the floor outlets, the windshield defroster the windshield defroster outlets, the side comes out of the windshield defroster out-...
Page 193 OTHER CONTROLS AND EQUIPMENT Air intake selector (4) System Operating Instructions Air conditioning switch (5) EXAMPLE Natural ventilation To turn on the air conditioning system, set Select “VENTILATION” and “FRESH AIR”, the blower speed selector to a position the temperature selector to the desired other than off and push in the “A/C”...
Page 194 OTHER CONTROLS AND EQUIPMENT Head cooled/Feet warmed heating NOTE: Select “BI-LEVEL” and “FRESH AIR”, the • If you select “RECIRCULATED AIR” for EXAMPLE temperature selector to the desired tem- an extended period of time, the air in the perature position, and the blower speed vehicle become contaminated.
Page 195 OTHER CONTROLS AND EQUIPMENT Maintenance If you do not use the air conditioner for a long period, such as during winter, it may not give the best performance when you start using it again. To help maintain opti- mum performance and durability of your air conditioner, it needs to be run periodically.
Page 196: Automatic Heating And Air Conditioning System (Climate Control)
OTHER CONTROLS AND EQUIPMENT Automatic Heating and Air Conditioning System (1) Temperature selector (2) Blower speed selector (Climate control) (3) Air intake selector (4) Air flow selector Description of Controls (5) Defrost switch (6) Air conditioning switch EXAMPLE (7) “OFF” switch (8) “AUTO”...
Page 197 OTHER CONTROLS AND EQUIPMENT Temperature selector (1) Blower speed selector (2) Air intake selector (3) EXAMPLE EXAMPLE EXAMPLE 68PH00551 68PH00552 68PH00553 Push the temperature selector (1) to adjust Air flows out at a higher rate when you Push the air intake selector (3) to change the temperature.
Page 198 OTHER CONTROLS AND EQUIPMENT FRESH AIR (b) If the “AUTO” switch (8) is pushed, the air Bi-level (d) When this mode is selected, outside air is flow will vary automatically as the climate EXAMPLE introduced. control system maintains the selected tem- perature.
Page 199 OTHER CONTROLS AND EQUIPMENT Heat (e) Heat & defrost (f) Defrost switch (5) EXAMPLE EXAMPLE EXAMPLE 68PH00545 68PH00546 68PH00555 Temperature-controlled air comes out of Temperature-controlled air comes out of Push the defrost switch (5) to turn on the the floor outlets and the side outlets, a the floor outlets, the windshield defroster defroster.
Page 200 OTHER CONTROLS AND EQUIPMENT Defrost Air conditioning switch (6) System Operating Instructions EXAMPLE EXAMPLE Automatic operation EXAMPLE 68PH00547 68PH00556 Temperature-controlled air comes out of 68PH00557 The air conditioning switch (6) is used to the windshield defroster outlets, the side turn on and off the air conditioning system You can let the climate control system work defroster outlets and the side outlets.
Page 201 OTHER CONTROLS AND EQUIPMENT You can use the air conditioning switch (6) ual mode. The manually selected func- Manual operation to manually turn the air conditioner on or off tions are maintained, and the other You can manually control the climate con- according to your preference.
Page 202: Radio Antenna
MAINTENANCE” section. Have this job done by your autho- 68PH00559 rised Maruti Suzuki workshop as the lower The radio antenna on the roof is remov- glove box must be lowered for this job. able. To remove the antenna, turn it coun- terclockwise.
Page 203: Audio System (If Equipped)
OTHER CONTROLS AND EQUIPMENT Audio System (If equipped) EXAMPLE AM/FM CD PLAYER 68PH00575 NOTE: For vehicle equipped with SMARTPLAY INFOTAINMENT SYSTEM, refer to audio manual available with the vehicle. 5-31...
Page 204 Please bring the unit to an authorised quickly tune to them using the pre- Maruti Suzuki workshop. sets. • Set the sound volume to a level that will allow you to continue to be...
Page 205 OTHER CONTROLS AND EQUIPMENT Use of such discs will cause damage or EXAMPLE prevent the system from operating prop- erly. EXAMPLE EXAMPLE 52D347 52D348 To remove fingermarks and dust, use a Never stick labels on the surface of the soft cloth, and wipe in a straight line from compact disc or write on the surface with a 52D351 the center of the compact disc to the cir-...
Page 206 OTHER CONTROLS AND EQUIPMENT WARNING ® The Bluetooth word mark and logo are This is a class I laser product. Use of registered trademarks and are owned by controls or adjustments or perfor- the Bluetooth SIG, Ink. mance of procedures other than those specified herein may result in ®...
Page 207 OTHER CONTROLS AND EQUIPMENT Basic Operations Turning power on/off Press the VOL PUSH POWER knob (1). The unit starts in the function mode it was EXAMPLE in when the power was turned off last. Adjusting the volume Turn the VOL PUSH POWER knob (1). Turning it clockwise increases the volume;...
Page 208 OTHER CONTROLS AND EQUIPMENT Adjusting bass/treble/balance /fader Adjusting the AVC (Auto volume con- Preset-EQ 1) Press the TUNE FOLDER PUSH trol) Preset-EQ calls up various sound types in SOUND knob (2). The Auto Volume Control (AVC) function accordance with the listening music type. Each time the knob is pressed, sound automatically adjusts...
Page 209 OTHER CONTROLS AND EQUIPMENT Listening to the Radio Display EXAMPLE (1) FM button (2) AM button (3) Up button (4) Down button (5) TUNE FOLDER PUSH SOUND knob (6) Preset buttons ([1] to [6]) (7) AS button (A) Band (B) Frequency 68PH00561 5-37...
Page 210 OTHER CONTROLS AND EQUIPMENT Selecting the FM band Auto store Radio reception Press the FM button (1). Hold down the AS button (7) for 2 seconds Radio reception can be affected by envi- Each time the button is pressed, the recep- or longer.
Page 211 OTHER CONTROLS AND EQUIPMENT Listening to a CD Display EXAMPLE (1) Insertion slot (2) Eject button (3) CD button (4) Up button (5) Down button (6) RPT button (7) RDM button (8) DISP button (A) Track number (B) Play time NOTE: This product does not support 8 cm CD (sometimes called as “mini single CD”, “3-...
Page 212 OTHER CONTROLS AND EQUIPMENT EXAMPLE NOTICE NOTICE • Never insert your finger or hand If you forcefully try to push an into the CD insertion slot. Never ejected CD inside the unit before auto insert foreign objects. reloading, the disc surface might be •...
Page 213 OTHER CONTROLS AND EQUIPMENT Random playback Display change Press the RDM button (7). Press the DISP button (8). Each time the button is pressed, the mode Each time the button is pressed, display will change as follows: will change as follows: Play time TRACK RANDOM Disc title...
Page 214 OTHER CONTROLS AND EQUIPMENT Listening to an MP3/WMA/AAC Disc Display EXAMPLE (1) TUNE FOLDER PUSH SOUND knob (2) Up button (3) Down button (4) RPT button (5) RDM button (6) DISP button (A) Folder number (B) Track number (C) Play time (D) DISC type 68PH00563 5-42...
Page 215 OTHER CONTROLS AND EQUIPMENT Selecting a folder Random playback Repeat playback Turn the TUNE FOLDER PUSH SOUND Press the RDM button (5). Press the RPT button (4). knob (1) to select a folder. Each time the button is pressed, the mode Each time the button is pressed, the mode will change as follows: will change as follows:...
Page 216 OTHER CONTROLS AND EQUIPMENT Display change Notes on MP3/WMA/AAC Points to remember when making MP3/ Press the DISP button (6). WMA/AAC files What is MP3? Each time the button is pressed, display • MP3 (MPEG audio layer3) is an audio Common will change as follows: •...
Page 217 OTHER CONTROLS AND EQUIPMENT • When storing both MP3 data and WMA WMA (Ver. 7, Ver. 8, Ver. 9*) data on the same disc, sort and place • Bit rate: CBR 32 k - 320 kbps them in different folders. •...
Page 218 OTHER CONTROLS AND EQUIPMENT Listening to files stored in a USB device Display EXAMPLE (1) MEDIA button (2) TUNE FOLDER PUSH SOUND knob (3) Up button (4) Down button (5) RPT button (6) RDM button (7) DISP button (A) Folder number (B) Track number (C) Play time (D) File type...
Page 219 OTHER CONTROLS AND EQUIPMENT Selecting a USB device mode Random playback • FOLDER REPEAT Press the MEDIA button (1). Press the RDM button (6). The repeat indicator “F.RPT” will light. Each time the button is pressed, the mode Each time the button is pressed, the mode All the tracks in the folder currently will change as follows: will change as follows:...
Page 220 OTHER CONTROLS AND EQUIPMENT Notes on USB device Recording MP3/WMA/AAC files on a Maximum number of files/folders USB device • Maximum number of files: 2500 Compatible USB devices • USB Mass Storage Class • Playback or display may not be possible •...
Page 221 OTHER CONTROLS AND EQUIPMENT ® Listening to an iPod Display EXAMPLE (1) MEDIA button (2) TUNE FOLDER PUSH SOUND knob (3) Up button (4) Down button (5) RPT button (6) RDM button (7) DISP button (8) Preset buttons ([1] to [6]) (A) Track title (B) Track number (C) Play time...
Page 222 OTHER CONTROLS AND EQUIPMENT ® Selecting an iPod mode Random playback Display change Press the MEDIA button (1). Press the RDM button (6). Press the DISP button (7). Each time the button is pressed, the mode Each time the button is pressed, the mode Each time the button is pressed, display will change as follows: will change as follows:...
Page 223 OTHER CONTROLS AND EQUIPMENT ® ® Playing Mode selection Notes on iPod iPod connection ® ® 1) Press the button numbered [1] of the • Make sure to detach the iPod after Supported iPod ® Preset buttons (8) for 1 second or lon- •...
Page 224 OTHER CONTROLS AND EQUIPMENT AUX Function AUX connection To listen to auxiliary audio sources (Sold separately) through the unit, follow the EXAMPLE instruction below. 1) Connect the auxiliary audio source to AUX/USB socket (Separately attached) with an AUX cable. 2) Press the MEDIA button (1). Each time the button is pressed, the mode will change as follows: ®...
Page 225 OTHER CONTROLS AND EQUIPMENT NOTE: • Please consult your place of purchase for details about whether a given auxil- iary audio source can be connected and the proper auxiliary cord to use. • The volume and tone controls of the auxiliary audio source can be adjusted on the unit.
Page 226 OTHER CONTROLS AND EQUIPMENT ® Bluetooth Hands-Free (If equipped) Steering switch EXAMPLE EXAMPLE Bluetooth 68PH00568 EXAMPLE (10) 68PH00569 68PH00567 ® (6) Bluetooth setup button (On steering (1) TUNE FOLDER PUSH SOUND knob wheel) (2) VOL PUSH POWER knob (7) Off Hook button (3) Preset buttons (8) On Hook button (4) Back button...
Page 227 OTHER CONTROLS AND EQUIPMENT Phone registration 5) Enter the Passkey displayed on the unit Adjusting the listening volume to the phone. • Turn the VOL PUSH POWER knob (2) To use the hands-free function with this 6) When the pairing with the phone is during a call.
Page 228 OTHER CONTROLS AND EQUIPMENT 3) Turn TUNE FOLDER PUSH Dialing using Missed/Incoming/ NOTE: SOUND knob (1) to select “Sound Set- Outgoing Calls • When selecting “Go Back” or pressing ting”, and press the knob (1) to deter- Follow the instructions below to dial to the the back button (4), the previous menu mine the selection.
Page 229 OTHER CONTROLS AND EQUIPMENT be deleted or “ALL”, and press the knob tacts”, and press the knob (1) to deter- tory”, and press the knob (1) to deter- (1) to determine the selection. mine the selection. mine the selection. 7) Turn TUNE FOLDER PUSH...
Page 230 OTHER CONTROLS AND EQUIPMENT 4) Pressing the TUNE FOLDER PUSH registered with the displayed name will 7) Turn TUNE FOLDER PUSH SOUND knob (1) switches between be dialed. SOUND knob (1) to select “Confirm”, “A.transfer On” and “A.transfer Off”. and press the knob (1) to complete the deletion.
Page 231 OTHER CONTROLS AND EQUIPMENT Preset”, and press the knob (1) to ,“Missed Call”, “Incoming Calls “or “Out- One-touch call (Speed dial) determine the selection. going Calls” respectively. Follow the instructions below to dial the 7) Press one of the Preset buttons (3) to 3) Turn TUNE FOLDER...
Page 232 OTHER CONTROLS AND EQUIPMENT Deletion of speed dial (Del speed dial) Display of device data (Device name) Reset to the factory defaults To delete a number assigned for the speed Follow the instructions below to display the Follow the instructions below to reset all ®...
Page 233 OTHER CONTROLS AND EQUIPMENT Selection of phone (Select phone) List of phones (List phones) 3) Turn TUNE FOLDER PUSH Follow the instructions below to select a Follow the instructions below to display the SOUND knob (1) to select “Passkey”, phone to be paired with from the registered names of the registered phones in and press the knob (1) to determine the phones.
Page 234 OTHER CONTROLS AND EQUIPMENT Deletion of phone information (Delete NOTE: NOTE: phone) When selecting “Go Back” or pressing the • When the BT function is turned off, the Follow the instructions below to delete the back button (4), the previous menu will be connection between this unit and the registered information of the phone.
Page 235 OTHER CONTROLS AND EQUIPMENT ® Bluetooth audio (If equipped) Steering switch EXAMPLE EXAMPLE Bluetooth 68PH00571 Display (1) MEDIA button (2) TUNE FOLDER PUSH SOUND knob (3) Up button (4) Down button (5) DISP button (6) Back button 68PH00570 ® (7) Bluetooth setup button (On control panel) ®...
Page 236 OTHER CONTROLS AND EQUIPMENT Registration of audio devices NOTE: Fast forwarding/Rewinding a track • When selecting “Go Back” or pressing • Hold down the Up button (3) to fast for- the back button (6), the previous menu ward the track. ®...
Page 237 OTHER CONTROLS AND EQUIPMENT Selection of audio device (Select audio) List of audio devices (List audio) 3) Turn TUNE FOLDER PUSH Follow the instructions below to select an Follow the instructions below to display the SOUND knob (2) to select “Passkey”, audio device to be paired with from the names of the registered audio devices in and press the knob (2) to determine the...
Page 238 OTHER CONTROLS AND EQUIPMENT Deletion of audio device information NOTE: Remote Audio Controls (Delete audio) When selecting “Go Back” or pressing the (If equipped) Follow the instructions below to delete the back button (6), the previous menu will be Controlling of basic functions of the audio registered information of audio device.
Page 239 OTHER CONTROLS AND EQUIPMENT Adjusting the volume Selecting the radio station (FM1, FM2, • To increase the volume, hold down “+” of AM mode) the VOL switch (1). The volume will keep • To select the next preset station, press on being increased until the switch is “...
Page 240 OTHER CONTROLS AND EQUIPMENT Anti-Theft Feature (1) VOL PUSH POWER knob (2) Preset buttons ([1] to [6]) (3) Up button EXAMPLE (4) TUNE FOLDER PUSH SOUND knob 68PH00573 5-68...
Page 241 OTHER CONTROLS AND EQUIPMENT The anti-theft function is intended to dis- Canceling the anti-theft feature Confirming the personal identification courage thefts, such as that the audio sys- To cancel the anti-theft function, delete the number (PIN) tem becomes inoperable when it is registered PIN.
Page 242 OTHER CONTROLS AND EQUIPMENT Battery Installation WARNING Install a lithium battery (CR2025) with the poles facing the correct direction. • Do not expose the battery to flame. Do not short circuit, disassemble, or heat the battery. • Do not charge the battery. •...
Page 243 OTHER CONTROLS AND EQUIPMENT Caution on Remote Controller • Do not leave the remote controller in an area exposed to direct sunlight, such as on the dashboard or steering wheel. The remote controller may deform because of the heat, (Be especially careful of the dashboard exposed to direct sunlight in the summer, as it will become extremely hot).
Page 244 OTHER CONTROLS AND EQUIPMENT Remote Controller Common operations POWER button VOLUME button Power ON / OFF Press to adjust volume. (including at AUX mode) TUNE FOLDER UP/DOWN button MUTE button In Sound Mode Press to mute the sound. Press it again to cancel Press to adjust the sound.(bass/treble/balance/fader) the mute.
Page 245 OTHER CONTROLS AND EQUIPMENT Radio operations SEEK TRACK UP/DOWN button Press to select the radio station. AS button Press to return to the last received fre- PRESET buttons (1-6) quency in the previous auto store mode. Press it for 2 seconds or longer. It selects Press to select the desired preset station.
Page 246 OTHER CONTROLS AND EQUIPMENT CD operations DISP button The display switches as follows: Play time Disc title SEEK TRACK UP/DOWN button Track title Press to skip to the next/previous track. Press it for 1 second or longer to display the Press it for 1 second or longer to fast-forward/ next page.
Page 247 OTHER CONTROLS AND EQUIPMENT MP3/WMA/AAC Disc operations DISP button The display switches as follows: Play time Folder name File name Album name (MP3, AAC only) SEEK TRACK UP/DOWN button Press to skip to the next/previous track. Track title Press it for 1 second or longer to fast-forward/fast- Artist name rewind the track.
Page 248 OTHER CONTROLS AND EQUIPMENT USB operations DISP button The display switches as follows: Play time Folder name File name Album name (MP3, AAC only) SEEK TRACK UP/DOWN button Track title Press to skip to the next/previous file. Press it for 1 second or longer to fast-forward/fast- Artist name rewind the file.
Page 249 OTHER CONTROLS AND EQUIPMENT ® iPod operations DISP button SEEK TRACK UP/DOWN button The display switches as follows: Playlist name / Press to skip to the next/previous file. Track title (Playlist mode only) Press it for 1 second or longer to fast-forward/fast- rewind the file.
Page 250: Troubleshooting
OTHER CONTROLS AND EQUIPMENT Troubleshooting When encountered a problem, check and follow the instructions as described below. If the described suggestions do not solve the problem, it is recommended to take the unit to your authorised Maruti Suzuki workshop. Problem Possible cause...
Page 251 OTHER CONTROLS AND EQUIPMENT Problem Possible cause Possible solution MP3/WMA/AAC The disc contains unsupported formatted No playback Check the file format. data. Sound skipping may occur when playing Sound skips or noise produced It is not recommended to play VBR files. VBR (Variable Bit Rate) files.
Page 252 The player developed an error of an remove the disc. ERROR 3 unidentified cause. When the disc cannot be ejected, contact your autho- rised Maruti Suzuki workshop. ® USB/iPod ERROR 1 The USB device is disconnected. Check the connection of the USB device.
Page 253 The player developed an error of an again. ERROR 1 unidentified cause. When ERROR 1 does not disappear, contact your autho- rised Maruti Suzuki workshop. Connection Failed to establish pairing or connection. Try to establish the pairing or connection again. Failed...
Page 254: Vehicle Loading And Towing
VEHICLE LOADING AND TOWING VEHICLE LOADING AND TOWING Vehicle Loading ..............6-1 Trailer Towing ..............6-1 54G215...
Page 255: Trailer Towing
VEHICLE LOADING AND TOWING Vehicle Loading Trailer Towing WARNING Your vehicle was designed for specific weight capacities. The weight capacities of EXAMPLE Never overload your vehicle. The your vehicle are indicated by the Gross gross vehicle weight (Sum of the Vehicle Weight Rating (GVWR) and the weights of the vehicle, all the occu- Permissible maximum Axle Weight (PAW,...
Page 256: Inspection And Maintenance
INSPECTION AND MAINTENANCE INSPECTION AND MAINTENANCE Maintenance Schedule ............7-2 Periodic Maintenance Schedule ........7-2 Drive Belt ................7-6 Engine Oil and Filter ............7-7 Engine Coolant ..............7-11 Air Cleaner ................7-13 Spark Plugs (Petrol engine) ..........7-14 Gear Oil ................7-15 Clutch Pedal ................
Page 257 90 seconds before performing pipes, muffler, radiator and water any electrical service work on your hoses. MARUTI SUZUKI. Do not touch air • Do not allow smoking, sparks, or bag system components, seat belt flames around fuel or the battery.
Page 258: Maintenance Schedule
“T”: Tighten to Specified Torque WARNING “O”: Rotate MARUTI SUZUKI recommends that NOTE: maintenance on your Maruti Suzuki This table includes services as scheduled vehicle should be performed by MAR- up to 80,000 km mileage. Beyond 80,000 UTI SUZUKI authorized workshop/ km, carry out the same services at the Service station.
Page 259 INSPECTION AND MAINTENANCE FREE INSPECTION PERIODIC MAINTENANCE AT COST Interval: This interval should be judged by odometer read- ing or months, whichever comes first. km (x1000) months ENGINE K10C 1-1. Water pump drive belt (Tension, Wear) Petrol K12M Engine Coolant (Level, Leakage) Engine oil, engine oil filter and drain plug gasket (Level, Leakage) Cooling system hoses and connections (Leakage and Damage) Engine cylinder head bolts...
Page 260 INSPECTION AND MAINTENANCE FREE INSPECTION PERIODIC MAINTENANCE AT COST Interval: This interval should be judged by odometer reading or months, whichever comes first. km (x1000) months Replace at 1,60,000 km or 10 years whichever comes first 4-4. Manual Transmission Oil (Level, Leakage) 4-5.
Page 261 INSPECTION AND MAINTENANCE FREE INSPECTION PERIODIC MAINTENANCE AT COST Interval: This interval should be judged by odometer reading or months, whichever comes first. km (x1000) months STEERING 9-1. Steering wheel (Play, Loose) 9-2. All rods and arms (Loose, Damage, Wear) 9-3.
Page 262: Drive Belt
INSPECTION AND MAINTENANCE Drive Belt (For petrol engine model) K12M model EXAMPLE K10C model WARNING When the engine is running, keep DEF: 5.6 – 6.8 mm hands, hair, clothing, tools, etc. away (0.22 – 0.27 in.) from the moving fan and drive belts. Make sure the drive belt tension is correct.
Page 263: Engine Oil And Filter
INSPECTION AND MAINTENANCE Engine Oil and Filter Oil Level Check (For diesel engine model) (For petrol engine model) Specified Oil EXAMPLE (For petrol engine model) • K10C model Be sure that the engine oil you use comes under the quality classification of API SL, SM and SN.
Page 264 INSPECTION AND MAINTENANCE If the oil level indication is near the lower Refilling Changing Engine Oil and Filter limit, add enough oil to raise the level to Drain the engine oil while the engine is still the upper limit. warm. EXAMPLE NOTICE EXAMPLE...
Page 265 INSPECTION AND MAINTENANCE Replace the Oil Filter WARNING EXAMPLE 1) Using an oil filter wrench, turn the oil fil- (Continued) ter counterclockwise and remove it. To minimize your exposure to used 2) Using a clean rag, wipe off the mount- oil, wear a long-sleeve shirt and ing surface on the engine where the moisture-proof gloves (Such as dish-...
Page 266 4) Tighten the oil filter housing cover on required, it is recommended that you trust the oil filter housing using a socket or this job to your authorised Maruti Suzuki ring spanner to the specified torque. workshop. Tightening torque for oil filter...
Page 267: Engine Coolant
Your authorised • Neither use 100% coolant nor 100% Maruti Suzuki workshop. Maruti Suzuki workshop can help you plain water. select the proper coolant. • Do not add extra inhibitors or addi- tives. They may not be compatible with your cooling system.
Page 268 INSPECTION AND MAINTENANCE Adding Coolant (For petrol engine model) (For diesel engine model) EXAMPLE WARNING Swallowing engine coolant can cause severe injury or death. Inhaling cool- ant mist or vapors or getting coolant in your eyes could result in severe injury.
Page 269: Air Cleaner
Coolant Replacement K10C model Since special procedures are required, we EXAMPLE recommend you take your vehicle to your authorised Maruti Suzuki workshop for coolant replacement. EXAMPLE 68PM00705 2) Unclamp the side clamps and remove the element from the air cleaner case. If...
Page 270: Spark Plugs (Petrol Engine)
INSPECTION AND MAINTENANCE Spark Plugs (Petrol engine) K12M model (For diesel engine model) Replacing and inspection of spark plugs Since special procedures, materials and tools are required, it is recommended that you trust this job to your authorised Maruti Suzuki workshop. EXAMPLE EXAMPLE 68PM00706...
Page 271: Gear Oil
(For K10C and D13A model) vent oil leakage. To check the gear oil level, use the fol- 68LM728 MARUTI SUZUKI Bond No. “1216E” or lowing procedure: “1217G” 1) Park the vehicle on a level surface with the parking brake applied. Then, stop Gear Oil Change the engine.
Page 272: Clutch Pedal
10 - 15 mm (0.4 - 0.6 in.) depressed, have the clutch inspected by vehicle or idle the engine until the tem- your authorised Maruti Suzuki workshop. If perature gauge indicates normal oper- Measure the clutch pedal play by moving the clutch fluid level is near the “MIN”...
Page 273 CVT oil or change, it is recom- mended that you trust this job to your Be sure to depress the brake pedal authorised Maruti Suzuki workshop. when moving the gearshift lever, or the vehicle can move suddenly. EXAMPLE...
Page 274: Fuel Filter (Diesel Engine)
EXAMPLE soon as possible. Have your vehicle ous damage to the brake system. inspected by an authorised Maruti Suzuki • If the brake fluid in the reservoir workshop. drops below a certain level, the...
Page 275 If the pedal to floor carpet distance as lows: Maruti Suzuki workshop. measured above is less than the minimum • Poor braking performance distance required, have your vehicle • Uneven braking (Brakes not work- inspected by your authorised Maruti ing uniformly on all wheels.)
Page 276: Steering
Maruti Suzuki work- and/or adjusted by your authorised Maruti shop. Suzuki workshop. 7-20...
Page 277 INSPECTION AND MAINTENANCE WARNING CAUTION EXAMPLE • Air pressures should be checked Hitting curbs and running over rocks when the tires are cold or you may can damage tires and affect wheel get inaccurate readings. alignment. Be sure to have tires and •...
Page 278 WARNING NOTICE (Vehicle with 185/65R15 88S tire) EXAMPLE • Your MARUTI SUZUKI is equipped Replacing the original tires with tires with tires which are all the same of a different size may result in false type and size (Except spare tire.
Page 279 8) In case of any problem, please get in can result in tire failure and loss of air pressure is maintained by the sealing touch with authorised Maruti Suzuki control. Always observe these precau- between tyre bead and wheel rim. Tube- workshop.
Page 280: Battery
INSPECTION AND MAINTENANCE Battery Replacement of the battery EXAMPLE For petrol engine model WARNING EXAMPLE • Batteries produce flammable hydrogen gas. Keep flames and sparks away from the battery or an explosion may occur. Never smoke when working in the vicinity of the battery.
Page 281: Fuses
INSPECTION AND MAINTENANCE Fuses To remove the battery: Fuses in the Engine Compartment 1) Disconnect the negative cable (1). Your vehicle has three types of fuses, as 2) Disconnect the positive cable (2). described below: For petrol engine model; Main fuse 3) Remove the retainer nuts (3) and The main fuse takes current directly from remove the retainer (4).
Page 282 INSPECTION AND MAINTENANCE (21) 30 A Radiator fan (39) 25 A Headlight high MAIN FUSE / PRIMARY FUSE (22) 60 A Power steering (40) 15 A Headlight high (Right) 120 A (23) (41) 15 A Headlight high (Left) 100 A (24) 20 A Fuel pump...
Page 283 INSPECTION AND MAINTENANCE Fuses under the Dash Board PRIMARY FUSE EXAMPLE 10 A Back-up light 15 A Ignition coil 10 A Meter 10 A Wiper Ignition-2 signal BLOWN 15 A Washer 25 A Front wiper EXAMPLE 10 A Tail light 68PH00723 68PH00724 10 A...
Page 284 INSPECTION AND MAINTENANCE (21) 15 A Radio (21) 20 A Power window timer PRIMARY FUSE (22) Dome light (22) 30 A Power window (23) 10 A Dome light-2 (23) 15 A Horn 10 A Meter (24) Tail light (Left) For vehicle with keyless push start sys- 15 A Ignition coil tem or keyless entry system...
Page 285: Headlight Aiming
EXAMPLE Since special procedures are required, we CAUTION recommend you take your vehicle to your authorised Maruti Suzuki workshop for • Light bulbs can be hot enough to headlight alignment. burn your finger right after being turned off. This is true especially...
Page 286 (1) Headlight (High/Low Beam) 68PM07001 (1) Headlight (High/Low Beam) Since special procedures are required, we recommend you take your vehicle to your authorised Maruti Suzuki workshop for bulb replacement. WARNING Never attempt to replace the bulb of a 68PH00727 discharge headlight, or you could Open the engine food.
Page 287 INSPECTION AND MAINTENANCE Side Turn Signal Light (On fender) EXAMPLE (If equipped) EXAMPLE EXAMPLE 68PH00728 68PH00761 NOTE: (4) Removal You can see the position of retaining spring 68PH00729 (5) Install from the hole of headlight. 1) Remove the light housing (1) by sliding 3) To remove and install the bulb of the to left with your finger.
Page 288 INSPECTION AND MAINTENANCE Front turn signal light and front position light EXAMPLE EXAMPLE Vehicle with the halogen headlights EXAMPLE 68PH00732 68PH00733 1) Open the engine hood. To remove the (3) Removal bulb holder of the front turn signal light (4) Installation or the front position light from the light 68PH00730 2) To remove the bulb of the front turn sig-...
Page 289 INSPECTION AND MAINTENANCE Front Fog Light (If equipped) Rear combination light 1) Start the engine. Turn the steering EXAMPLE wheel to the opposite side of the replac- ing fog light to replace the bulb easily. Then turn off the engine. EXAMPLE EXAMPLE 68PM07003...
Page 290 INSPECTION AND MAINTENANCE 4) To remove the bulb of the rear turn sig- License Plate Light EXAMPLE nal light (5) from the bulb holder, push in the bulb and turn it counterclockwise. EXAMPLE To install a new bulb, push it in and turn it clockwise.
Page 291 Since special procedures are required, we EXAMPLE screwdriver covered with a soft cloth as recommend you take your vehicle to your shown. To install it, simply push it back in. authorised Maruti Suzuki workshop for bulb replacement. Front (If equipped) EXAMPLE 68PH00746...
Page 292: Wiper Blades
INSPECTION AND MAINTENANCE Wiper Blades NOTE: Some wiper blades may be different from EXAMPLE the ones described here depending on vehicle specifications. If so, consult your authorised Maruti Suzuki workshop for proper replacement method. For windshield wipers: EXAMPLE EXAMPLE 54G129 68PH00749...
Page 293 INSPECTION AND MAINTENANCE Removal EXAMPLE EXAMPLE EXAMPLE EXAMPLE 68PH00753 68PH00751 (3) Retainer Installation 4) If the new blade is provided without the EXAMPLE two metal retainers, move them from the old blade to the new one. EXAMPLE 68PH00750 2) Squeeze lock (1) towards wiper arm (2) and remove the wiper frame from the 68PH00752 arm as shown.
Page 294 INSPECTION AND MAINTENANCE For rear wipers: EXAMPLE EXAMPLE EXAMPLE 60MHM7001 68PH00764 (A) Up NOTE: (B) Down Do not flex the wiper blade frame end more than necessary. If you do, it can break off. NOTE: When you install the metal retainers (3), make sure the direction of metal retainers as shown in the above illustrations.
Page 295: Windshield Washer Fluid
68PH00765 recommend you take your vehicle to your (1) Retainer 68PH00756 authorised Maruti Suzuki workshop for the Check that there is washer fluid in the tank. air conditioner filter replacement. 4) If the new blade is provided without the Refill it if necessary. Use a good quality...
Page 296 INSPECTION AND MAINTENANCE EXAMPLE 68PH00758 2) Remove the cover (1) and pull out the air conditioner filter (2). NOTE: When you install a new filter, make sure the UP mark (3) faces upward. 7-40...
Page 298: Emergency Service
EMERGENCY SERVICE EMERGENCY SERVICE Tire Changing Tool ............. 8-1 Jacking Instructions ............8-1 Changing Wheels ..............8-4 Jump Starting Instructions ..........8-5 Towing .................. 8-6 If the Starter Does Not Operate .......... 8-7 If the Engine is Flooded ............8-7 If the Engine Overheats ............
Page 299: Tire Changing Tool
EMERGENCY SERVICE Tire Changing Tool Jacking Instructions WARNING EXAMPLE After using the tire changing tools, be EXAMPLE sure to stow them securely or they can cause injury if an accident occurs. CAUTION The jack should be used only to change wheels. It is important to read the jacking instructions in this sec- tion before attempting to use the jack.
Page 300 EMERGENCY SERVICE 3) Turn on the hazard warning flasher if 7) Continue to raise the jack slowly and your vehicle is near traffic. smoothly until the tire clears the EXAMPLE 4) Block the front and rear of the wheel ground. Do not raise the vehicle more diagonally opposite of the wheel being than necessary.
Page 301 EMERGENCY SERVICE To Raise the Vehicle with a Garage Front jacking point for garage jack (1) Rear jacking point for garage jack (2) Jack EXAMPLE • Apply the garage jack to one of the points indicated below. • Always support the raised vehicle with jack stands (Commercially available) at the points indicated below.
Page 302: Changing Wheels
NOTE: 3) Loosen, but do not remove the wheel For more details, please contact an autho- nuts. rised Maruti Suzuki workshop. 4) Jack up the vehicle. 5) Remove the wheel nuts and wheel. 6) Before installing the new wheel, clean any mud or dirt off from the surface of the wheel and hub with a clean cloth.
Page 303: Jump Starting Instructions
• If your battery discharges repeat- edly, for no apparent reason, have EXAMPLE your vehicle inspected authorised Maruti Suzuki work- shop. • To avoid harm to yourself or dam- age to your vehicle or battery, fol- low the jump starting instructions 68PH00810 below precisely and in order.
Page 304: Towing
EMERGENCY SERVICE Towing WARNING If you need to have your vehicle towed, contact a professional service. Your dealer Never connect the jump lead directly can provide you with detailed towing to the negative (–) terminal of the dis- instructions. charged battery, or an explosion may occur.
Page 305: If The Starter Does Not Operate
EMERGENCY SERVICE If the Starter Does Not If the Engine is Flooded 2-Wheel Drive (2WD) Manual Transaxle Operate If the engine is flooded with fuel, it may be Manual transaxle vehicles may be towed hard to start. If this happens, press the 1) Try turning the ignition switch to the using either of the following methods.
Page 306: If The Engine Overheats
If it is, you must wait until it If your engine overheats and you are unsure what to do, contact your authorised stops boiling before you proceed. Maruti Suzuki workshop. 65D350d...
Page 307: Warning Triangle
EMERGENCY SERVICE Warning Triangle • Remove the warning triangle carefully WARNING from the cover as shown by arrow 1. • Open both the reflector arms as shown EXAMPLE • It is hazardous to remove the radia- by arrow and lock the arms with each tor cap (Or degassing tank cap for other with the clip provided in the right a diesel engine) when the water...
Page 308: Appearance Care
APPEARANCE CARE APPEARANCE CARE Corrosion Prevention ............9-1 Vehicle Cleaning ..............9-2 60G412...
Page 309: Corrosion Prevention
APPEARANCE CARE Corrosion Prevention vehicle which are not well ventilated to Remove foreign material deposits permit quick drying. Foreign material such as salts, chemicals, It is important to take good care of your road oil or tar, tree sap, bird droppings and vehicle to protect it from corrosion.
Page 310: Vehicle Cleaning
APPEARANCE CARE Vehicle Cleaning spill or leak does occur, clean and dry the Cleaning the Interior area immediately. Vinyl upholstery EXAMPLE Prepare a solution of soap or mild deter- Store your vehicle in a dry, well-venti- gent mixed with warm water. Apply the lated area solution to the vinyl with a sponge or soft Do not park your vehicle in a damp, poorly...
Page 311 APPEARANCE CARE Leather upholstery Seat belts Remove loose dirt with a vacuum cleaner. Clean seat belts with a mild soap and NOTICE Using a mild soap or saddle soap solution, water. Do not use bleach or dye on the Do not use chemical products that wipe dirt off with a clean damp soft cloth.
Page 312 APPEARANCE CARE Washing When washing the vehicle, park it where 2) Rinse the body to loosen the dirt. direct sunlight does not fall on it and follow Remove dirt and mud from the body the instructions below: exterior with running water. You may EXAMPLE 1) Flush the underside of body and wheel use a soft sponge or brush.
Page 313 APPEARANCE CARE 6) Check carefully for damage to painted Waxing surfaces. If there is any damage, “touch-up” the damage following the EXAMPLE procedure below: 1. Clean all damaged spots and allow them to dry. 2. Stir the paint and “touch-up” the damaged spots lightly using a small brush.
Page 314: General Information
GENERAL INFORMATION GENERAL INFORMATION Vehicle Identification ............10-1 Radio Frequency Identification (RFID) Tag .......10-2 84MM01001...
Page 315: Vehicle Identification
Chassis Serial Number information. Whenever you have occasion EXAMPLE to consult your authorised Maruti Suzuki workshop, remember to identify your vehi- EXAMPLE cle with this number. If you find the number difficult to read, you will also find it on the identification plate.
Page 316 GENERAL INFORMATION Radio frequency identification As seen from inside of the vehicle As seen from outside of the vehicle (RFID) tag EXAMPLE EXAMPLE As per Ministry of Road Transport and Highways, the Radio frequency identifica- tion (RFID) tag (1) is mandatory for each vehicle for the purpose of electronic toll collection or any other purpose as may be defined by the Government of India.
Page 318: Specifications
SPECIFICATIONS SPECIFICATIONS NOTE: Specifications are subject to change without notice. M/T: Manual transaxle Petrol: Petrol engine model CVT: Continuously variable transaxle Diesel: Diesel engine model ITEM: Dimensions UNIT: mm Overall length 3995 Overall width 1745 Overall height 1510 Wheelbase 2520 185/65R15 tire 1515 Front...
Page 319 SPECIFICATIONS ITEM: Engine Type K10C (DOHC) K12M (DOHC) D13A (DOHC) Number of cylinders Bore 73.0 mm 73.0 mm 69.6 mm Stroke 79.5 mm 71.5 mm 82.0 mm Piston displacement 998 cm 1197 cm 1248 cm Compression ratio 10.0 : 1 11.0 : 1 17.6 : 1 ITEM: Electrical...
Page 320 SPECIFICATIONS ITEM: Lights WATTAGE BULB No. Halogen 12V 60/55W Headlight Discharge 12V 25W Front fog light (If equipped) 12V 35W H8 / PSX24W Position light (Vehicle with the halogen headlights) 12V 5W Position light & Daytime running light – (Vehicle with the discharge headlights) Front 12V 21W PY21W...
Page 321 • Please understand that the maximum permissible speed of snow tires is generally less than the originally installed tires. Consult your authorised Maruti Suzuki workshop or supplier for further information. *3 The spare wheel provided with alloy wheel variant is of steel wheel rim, hence follow 4 tire rotation only. (Refer: Section Inspection...
Page 322 SPECIFICATIONS ITEM: Recommended Fuel/Lubricants and Capacities (approx.) Fuel See “FUEL RECOMMENDATION” section. 37 L Classification: API SL, SM and SN 2.9 L K10C Viscosity: SAE 5W-30 (Replacement with oil filter) Petrol Classification: API SL, SM and SN 3.1 L Engine oil K12M Viscosity: SAE 0W-20 (Replacement with oil filter)
Page 323 January, 2017 Part No. 99011M68P06-74E For 24 X 7 assistance, contact Toll Free number 1800 200 6392 (NEXA)
Page 324 Service Division MARUTI SUZUKI INDIA LIMITED Palam Gurgaon Road, Gurgaon - 122 015 (Haryana) www.marutisuzuki.com...

This manual is also suitable for:

Baleno rs 2017

MARUTI SUZUKI BALENO 2017 Owner's Manual

Table of Contents

Before Driving

Operating Your Vehicle

Driving Tips

Other Controls and Equipment

Inspection and Maintenance

Quick Links

Chapters

Need help?

Questions and answers

Related Manuals for MARUTI SUZUKI BALENO 2017

Summary of Contents for MARUTI SUZUKI BALENO 2017

This manual is also suitable for:

Table of Contents
