BEFORE USING THE POWER SUPPLY UNIT
Be sure to read this instruction manual thoroughly before using this product. Pay attention to all cautions and warnings before using this product.
Incorrect usage could lead to an electrical shock, damage to the unit or a fire hazard.
DANGER
Never use this product in locations where flammable gas or ignitable substances are present. There are risks of igniting these substances and
exploding by an arcing.
WARNING
·
Do not touch this product or its internal components while it is in operation, or shortly after shut down. There may be high voltage or high
temperature resent and you may receive an electric shock or burn.
·
When this product is operating, keep your hands and face away from it as you may be injured by an unexpected situation.
·
Do not make unauthorized changes to this product, otherwise you may receive an electric shock and void your warranty.
·
Do not drop or insert anything into this product. It might cause a failure, fire and electric shock.
·
Do not use this product under unusual condition such as emission of smoke or abnormal smell and sound etc. It might lead to fire and electric
shock. In such cases, please contact us. Do not attempt repair by yourself, as it is dangerous for the user.
·
Do not operate this product in the presence of condensation. It might cause fire and electric shock.
CAUTION
·
This power supply is designed and manufactured for use within an end product such that it is accessible to SERVICE ENGINEERS only.
·
Confirm connections to input/output terminals are correct as indicated in the instruction manual before switching on.
·
Input voltage, Output current, Output power, ambient temperature and ambient humidity should be kept within specifications, otherwise the
product will be damaged.
·
Do not operate and store this product in an environment where condensation might occur. In such case, waterproof treatment is necessary.
·
Do not use this product in environment with a strong electromagnetic field, corrosive gas or conductive substances.
·
For applications, which require very high reliability (Nuclear related equipment, traffic control equipment, medical equipment, etc.), it is
necessary to provide a fail-safe mechanism in the end equipment.
·
Do not inject abnormal voltages into the output of this product. The injection of reverse voltage or over voltage exceeding nominal output
voltage into the output terminal might cause damage to internal components.
·
Never operate the product under over current or short-circuit conditions for more than 30 seconds, or outside its specified Input Voltage Range.
Insulation failure, smoking, burning or other damage may occur.
·
This product contains a printed circuit board utilizing surface mounted devices. PCB stress such as bending, twisting etc. could cause damage.
Therefore, please handle with care.
·
When handling this product, hold the board edge and take care not to touch the component side. When installing this product in apparatus or
equipment, mount it on spacers.
·
The outputs of this product may, under fault conditions, exceed SELV voltage limits. Therefore the outputs must be earthed in the end
equipment to maintain SELV. If the outputs are not earthed, they must be considered hazardous and must not be made user accessible.
·
This product has used Power Thermistor to protect the circuit from Inrush Current. Frequent repetition of input might cause damage to internal
components because of generating surge current.
·
Breaking of internal fuse is considered internal failure. In such cases, please contact us.
·
The information in this document is subject to change without prior notice. Please refer to the latest version of the data sheet, etc., for the most
up-to date specifications of the product.
·
No part of this document may be copied or reproduced in any form without prior written consent of TDK-Lambda.
MARKING
Note: CE
CE Marking, when applied to a product covered by this handbook, indicates compliance with the low voltage directive.
VS-E Series
VS50E
・ 75E ・ 100E ・ 150E
Instruction Manual
TDK-Lambda
VS-E Series
Instruction Manual
A239-04-01E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VS-E Series and is the answer not in the manual?

Questions and answers

Summary of Contents for TDK-Lambda VS-E Series

  • Page 1 The information in this document is subject to change without prior notice. Please refer to the latest version of the data sheet, etc., for the most up-to date specifications of the product. · No part of this document may be copied or reproduced in any form without prior written consent of TDK-Lambda. MARKING Note: CE CE Marking, when applied to a product covered by this handbook, indicates compliance with the low voltage directive.
  • Page 2 TDK-Lambda VS-E Series Instruction Manual 1.Model name identification method VS 50 E – 5 Rated Output Voltage Output Power type Series Name 2.Terminal Explanation VS50E VS75E ④ ④ ④ ④ ③ ③ ⑦ ② ② ⑥ ⑥ ① ① ⑤...
  • Page 3: Input/Output Connector

    TDK-Lambda VS-E Series Instruction Manual 3. Terminal Connection Method Pay attention to the input wiring. If it is connected to wrong terminal, the power supply will be damaged. · Input must be off when making connections. · Connect terminal of input connector and mounting hole to protective earth of the equipment.
  • Page 4: Inrush Current

    TDK-Lambda VS-E Series Instruction Manual 4.Explanation of Function and Precautions 4-1. Input Voltage Range Input voltage range is single phase 85-132VAC(47-63Hz). Input voltage, which is out of specification, might cause unit damage. For cases where conformance to various safeties required, described as 100-120VAC (50/60Hz). Also, 110-175VDC is possible for VS100E and VS150E.
  • Page 5: Parallel Operation

    TDK-Lambda VS-E Series Instruction Manual 4-8. Parallel Operation For parallel operation, method (B) is possible. (A) To increase the output current is not possible. (B) To use as Back-up Power Supply 1. Adjust the output voltage of each power supply to be the same.
  • Page 6: Mounting Directions

    TDK-Lambda VS-E Series Instruction Manual 5.Mounting Directions 5-1. Output Derating according to the Mounting Directions. Recommended standard mounting method is (A). Method (B)-(E) are also possible. Refer to the output derating below. (A) Standard (F) Inhibit Mounting (INPUT) 5-2. Output Derating...
  • Page 7: Mounting Method

    TDK-Lambda VS-E Series Instruction Manual FORCED AIR COOLING VS50E・75E・100E・150E Electrolytic capacitor upper bound temperature MOUNTING (A) - (E) Load (%) Load (%) MODEL (℃) Mounting (A) - (E) (*1) Io≦80 (*2) 80<Io≦100 -10 - +60 VS50E 75℃ 80℃ VS75E・100E・150E 80℃...
  • Page 8: Wiring Method

    (3) Noise can be reduced by attaching a capacitor to the load terminals. (4) For safety and EMI considerations, connect terminal of input connector and mountable Frame Ground of VS-E series to ground terminal equipment firmly. 7. External Fuse Rating Refer to the following fuse rating when selecting the external fuses that are to be used on input line.

This manual is also suitable for:

Vs50eVs75eVs100eVs150e
