  • Page 1 SmartClass VDSL Tester (Conexant/Accelity chipset) User’s Guide...
  • Page 3 SmartClass VDSL Tester (Conexant/Accelity chipset) User’s Guide...
  • Page 4 © Copyright 2010, JDS Uniphase Corporation. All rights reserved. JDSU, Enabling Broadband and Optical Innovation, Communications Test and Mea- surement Solutions, and the JDSU logo are trademarks of JDS Uniphase Cor- poration (“JDS Uniphase”). All other trademarks are the property of their respective owners.
  • Page 5 Instructions for returning waste equipment and batteries to JDSU can be found in the Environmental section of JDSU’s web site at www.jdsu.com. If you have questions concerning disposal of your equipment or batteries, contact JDSU’s WEEE Program Management team at WEEE.EMEA@jdsu.com. SmartClass VDSL Tester User’s Guide...
  • Page 6 SmartClass VDSL Tester User’s Guide...

  • Page 7: Table Of Contents

    Typing text ..........10 SmartClass VDSL Tester User’s Guide...
  • Page 8 Warranty information ......... 33 SmartClass VDSL Tester User’s Guide...

  • Page 9: About This Guide

    This chapter describes how to use this guide. Topics discussed in this chapter include the following: – “Purpose and scope” on page viii – “Assumptions” on page viii – “Safety and compliance information” on page viii – “Conventions” on page viii SmartClass VDSL Tester User’s Guide...

  • Page 10: Purpose And Scope

    This symbol, located on the equipment or its packaging indi- cates that the equipment must not be disposed of in a land-fill site or as municipal waste, and should be disposed of accord- ing to your national regulations. viii SmartClass VDSL Tester User’s Guide...
  • Page 11 WARNING Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. CAUTION Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. SmartClass VDSL Tester User’s Guide...
  • Page 12 About this Guide Conventions SmartClass VDSL Tester User’s Guide...

  • Page 13: Getting Started

    Getting Started Chapter 1 This chapter provides a general description of the SmartClass VDSL Services Tester. Topics discussed in this chapter include the following: – “Ship list” on page 2 – “Features and capabilities” on page 2 – “Preparation for use” on page 2...

  • Page 14: Ship List

    When unpacking the unit, verify that each of the standard items, and any optional items you ordered, are included in the package. Features and capabilities Features and capabilities of the SmartClass VDSL Services Tester include the following: – Qualification of VDSL access service –...

  • Page 15: Changing The Ac Line Plug Fitting

    4 Select the appropriate AC line plug adapter. 5 Slide the AC line plug adapter into the slot. You will hear a click when the fitting is fully inserted. The AC Adapter/Charger is ready for use. SmartClass VDSL Tester User’s Guide...
  • Page 16 Chapter 1 Getting Started Preparation for use SmartClass VDSL Tester User’s Guide...

  • Page 17: Quick Tour

    “Exploring the front panel” on page 6 – “Exploring the connector panel” on page 7 – “Exploring the bottom panel” on page 8 – “Navigating the user interface” on page 8 – “Using the keypad” on page 10 SmartClass VDSL Tester User’s Guide...

  • Page 18: Exploring The Front Panel

    Cancel key Keypad Backlight key Power key Figure 1 SmartClass VDSL Services Tester front panel The following paragraphs describe each of the controls and LEDs on the front panel. Status LEDs These indicators report the status of the unit. The function of each LED is described in “LEDs”...

  • Page 19: Keypad

    DSL line connector Ethernet connector Figure 2 SmartClass VDSL Services Tester connector panel Use the 6-pin modular DSL jack when connecting to VDSL circuits. If you are testing in through mode, connect an Ethernet cable to the Ethernet jack.

  • Page 20: Exploring The Bottom Panel

    Using the LCD and keypad, you can view test results, set up the unit, and configure test parameters. This section describes the user interface, and explains how to navigate through the menus and screens. When you power up the SmartClass VDSL Services Tester, the user interface appears (see Figure...

  • Page 21: Menu Screens

    Figure 7 SmartClass Result screen (example) These screens display error logs or test results. The results are split into cate- gories. Press the arrow keys to navigate among the results categories (screens). SmartClass VDSL Tester User’s Guide...

  • Page 22: Using The Keypad

    If you move the cursor between characters, typing characters will insert new characters at that location. To append characters, position the cursor at the end of your text, after the last character. SmartClass VDSL Tester User’s Guide...
  • Page 23 “Setting the date and time” on page 12 – “Adjusting the contrast” on page 13 – “Specifying the auto power down setting” on page 13 – “Setting the language” on page 14 – “Restoring factory defaults” on page 14 SmartClass VDSL Tester User’s Guide...

  • Page 24: Viewing Software Versions

    3 Scroll down to the DATE. 4 Enter the current month, day, and year in numerical form. For example, the date April 1, 2004 would be 4/1/2004. 5 Press the OK key. The date is set. SmartClass VDSL Tester User’s Guide...

  • Page 25: Changing The Date Format

    – 5, 10, or 15 Minutes - the amount of time to wait (in minutes) after a keypress or no line activity before power down. 4 Press the OK key. The auto power down setting is specified. SmartClass VDSL Tester User’s Guide...

  • Page 26: Setting The Language

    2 Select FACTORY DEFS. You may have to scroll to find the FACTORY DEFS selection. A confirmation menu appears. 3 Press the OK key to reset the defaults or Cancel to keep the current settings SmartClass VDSL Tester User’s Guide...

  • Page 27: Vdsl Testing

    Topics discussed in this chapter include the following: – “Specifying modem settings” on page 16 – “Verifying connectivity” on page 16 – “Running a VDSL quick test” on page 17 – “SELT Termination” on page 17 SmartClass VDSL Tester User’s Guide...

  • Page 28: Specifying Modem Settings

    2 Connect a cable from the line to the DSL jack on the right side of the VDSL Services Tester. 3 Select VDSL TEST. The modems begin to synchronize. Modem synchronization may take a few minutes. After the modems have achieved synchronization, the Sync light turns green. This verifies connectivity. SmartClass VDSL Tester User’s Guide...

  • Page 29: Running A Vdsl Quick Test

    After initializing the modem, the SELT verification screen is displayed. The timer indicates the time until the next restart. The modem must periodically reset (every 3 minutes) to maintain the termination. The far end technician can continue testing. SmartClass VDSL Tester User’s Guide...
  • Page 30 Chapter 4 VDSL Testing SELT Termination SmartClass VDSL Tester User’s Guide...

  • Page 31: Interpreting Test Results

    This chapter describes the test results that are gathered when running a test. Topics in this chapter include the following: – “LEDs” on page 20 – “VDSL Summary results” on page 20 – “Saving results” on page 21 SmartClass VDSL Tester User’s Guide...

  • Page 32: About Vdsl Results

    Chapter 5 Interpreting Test Results About VDSL results About VDSL results After the SmartClass VDSL Services Tester synchronizes with the DSLAM, the unit immediately displays results on the LCD. You can view many additional results by pressing the arrow keys.

  • Page 33: Saving Results

    4 Press the 1 key. 5 Enter the file name. 6 Press the OK key. The test results are stored. For more information on downloading the results to Excel, see the instructions provided with the Download Manager utility. SmartClass VDSL Tester User’s Guide...
  • Page 34 Chapter 5 Interpreting Test Results Saving results SmartClass VDSL Tester User’s Guide...

  • Page 35: Maintaining The Batteries

    This chapter describes how to maintain the VDSL Services Tester‘s batteries. Topics discussed in this chapter include the following: – “Prolonging battery life” on page 24 – “Recharging the battery” on page 24 – “Replacing the battery pack” on page 25 SmartClass VDSL Tester User’s Guide...

  • Page 36: Prolonging Battery Life

    Batt LED is green. After the Batt LED turns green (fast charge is complete), allow the unit to trickle charge overnight for maximum performance. Charging the batteries is complete. SmartClass VDSL Tester User’s Guide...

  • Page 37: Replacing The Battery Pack

    The battery compartment is located on the back of the unit, as shown in Figure Battery compartment Figure 8 Back of SmartClass VDSL Services Tester The following procedure describes how to replace the battery pack. To replace the battery pack 1 Turn the power off.
  • Page 38 Chapter 6 Maintaining the Batteries Replacing the battery pack SmartClass VDSL Tester User’s Guide...

  • Page 39: Troubleshooting

    Troubleshooting Chapter 7 This chapter describes how to identify and correct problems related to the SmartClass VDSL Services Tester. Topics discussed in this chapter include the following: – “Getting Technical Assistance” on page 28 – “Additional information” on page 28 –...

  • Page 40: Getting Technical Assistance

    TAC for your region; email the North American TAC (tac@jdsu.com); submit your question using our online Technical Assis- tance request form at www.jdsu.com. Additional information For additional information, visit the SmartClass VDSL section of the following web page: http://www.jdsu.com/test_and_measurement/products/access/index.html Resolving problems If you are having trouble with the VDSL Services Tester, the following sections describe common problems and solutions.

  • Page 41: General Testing

    Check whether the max rate on the DSLAM is limited. Check for a premise alarm system on the same pair. Check the attenuation. Make sure that you are connected on pins 3 and 4 instead of 2 and 5. Verify the noise margin. SmartClass VDSL Tester User’s Guide...
  • Page 42 Chapter 7 Troubleshooting Resolving problems SmartClass VDSL Tester User’s Guide...

  • Page 43: Specifications

    This appendix contains specifications for the VDSL Services Tester. Topics discussed in this appendix include the following: – “Connector specifications” on page 32 – “Environmental specifications” on page 32 – “Power specifications” on page 32 – “Warranty information” on page 33 SmartClass VDSL Tester User’s Guide...

  • Page 44: Connector Specifications

    Charging time 5 hours for a fast charge; for a full charge, allow to trickle charge overnight Power supply input 100 to 240 VAC, 50/60 Hz, autosensing Power supply output 12 V, 1.25 Amp SmartClass VDSL Tester User’s Guide...

  • Page 45: Warranty Information

    Customer with a refund of all charges paid with respect thereto. JDSU shall have no warranty obligations hereunder if (a) the Software is altered or modified or is merged with other software by Customer or any third SmartClass VDSL Tester User’s Guide...
  • Page 46 MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, AS WELL AS THOSE ARISING FROM ANY COURSE OF DEALING, USAGE OR TRADE PRACTICE. UNDER NO CIRCUMSTANCES WILL JDSU BE LIABLE FOR ANY INDIRECT OR CONSEQUENTIAL DAMAGES RELATED TO BREACH OF THIS WARRANTY. SmartClass VDSL Tester User’s Guide...
  • Page 48 Communications Test and Measurement Regional Sales North America Latin America Asia Pacific EMEA www.jdsu.com Toll Free: 1 800 638 2049 Tel: +55 11 5503 3800 Tel: +852 2892 0990 Tel: +49 7121 86 2222 Tel: +1 240 404 2999 Fax:+55 11 5505 1598 Fax:+852 2892 0770 Fax:+49 7121 86 1222 Fax:+1 240 404 2195...
