Modbus Address Map

2.4.
Modbus address from the formula is expressed in link layer format. This is, first register address is 0.
Modbus Address
/Write
First Address is 0
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
(ID+1)*25+10000+0
Where ID stands for ID field in
Fujitsu VRF configuration in MAPS,
from 0 to 31
(ID+1)*25+10000+1
© HMS Industrial Networks S.L.U - All rights reserved
This information is subject to change without notice
Read
Register/signal name
R/W
Gateway Energy Saving
R
Gateway error
R
Gateway error code
W
On (all the units)
W
Off (all the units)
W
Operation Mode Auto (all the units)
W
Operation Mode Heat (all the units)
W
Operation Mode Dry (all the units)
W
Operation Mode Fan (all the units)
W
Operation Mode Cool (all the units)
W
Fan Speed Auto (all the units)
W
Fan Speed Quiet (all the units)
W
Fan Speed Low (all the units)
W
Fan Speed Med-Low (all the units)
W
Fan Speed Med-High (all the units)
W
Fan Speed High (all the units)
W
Temperature Setpoint (x10ºC) (all units)
Outdoor units
R
Capacity save
R
Forced Off
User Manual r1.0 EN
Possible values
0-Disable energy saving
1-Enable energy saving
0-Normal
1-Error
0-No error
1-Comm. error
2-No config. error
1-Set all the units On
1-Set all the units Off
1-Set Auto Mode
1-Set Heat Mode
1-Set Dry Mode
1-Set Fan Mode
1-Set Cool Mode
1-Set Fan Speed Auto
1-Set Fan Speed Quiet
1-Set Fan Speed Low
1-Set Fan Speed Mid-Low
1-Set Fan Speed Mid-High
1-Set Fan Speed High
Cool: 19...30°C; Heat: 17...30°C
0-Not set
1-100%
2-90%
3-80%
4-70%
5-60%
6-50%
7-40%
0-Not forced
1-Forced off
