ventIde etup uIde
The DMC.micro supports three "families" of Eventide devices:
H9 / Factor: H9, Timefactor, Modfactor, Pitchfactor, SPACE
Rose
Stompbox Series: Pedals using Eventide Device Manager, including Blackhole, UltraTap,
MicroPitch
H9 and Factor devices: Select the H9 device driver for the device slot you wish to use.
Eventide devices have a robust MIDI mapping capability, but none of their functions are
set from the factory. In order for these devices to recognize the commands we send, a few
parameters must be set in their MIDI menus
If using H9 Control, navigate to Pedal -> MIDI Settings -> MIDI Channel
Set MIDI Receive Channel match device selection - 1 for DevA, 2 for DevB, etc.
Navigate to Pedal -> MIDI Settings -> Assign MIDI CC Messages. Map Tap Tempo to MIDI CC 44
Map Performance Switch to MIDI CC 46
Map Toggle Tuner to MIDI CC 69
Map Activate to MIDI CC 42
Map Set Expression Pedal Value to CC 48
If using the MIDI menu on the device itself:
Navigate to RCV CHANNEL and set to match device selection - 1 for DevA, 2 for DevB, etc.
Navigate to the RCV CTL menu and set the following:
TAP C42 HOTSW C46 ACTIVE C42 PEDAL C48
If you plan to use the looper on the H9 or Timefactor, set the following:
Looper - Record MIDI CC 87
Looper - Play MIDI CC 86
Looper - Stop MIDI CC 85
Looper - Empty MIDI CC 90
Looper - Flip Direction MIDI CC 94
Looper - Flip Octave MIDI CC 95
Rose: Select the EVEN. ROSE / ROSE device driver for the device slot you wish to use. Connect
the Rose EXP jack using a TRS cable, set MULTIJACK = MIDI TIP and JACK CHAN active for the
device slot you are using. Set the DIP switches to ON-ON-ON.
Power on the Rose and hold active + φ, then click the PRESET button until the 4th LED is lit.
Click the shape button to set the MIDI channel, the Rose defaults to channel 1.
CH1 = LED5, CH2 = LED4, CH3 = LED 4+5, CH4, LED3.
Click the φ button to enable or disable MIDI clock (LED5.)
Hold the active footswitch to save and exit.
EDM Series: Select the EVEN STOMP / E.STP device driver for the device slot you wish to use.
Connect the pedal EXP jack using a TRS cable, set MULTIJACK = MIDI TIP and JACK CHAN
active for the device slot you are using. Set the DIP switches to ON-ON-ON.
Power on the pedal while holding the active footswitch and V button to enter system setup.
Tap the V button until the 4th LED is lit (MIDI BOX.) Then press the tap button to set the MIDI
channel. The default is OMNI (all five LEDs,) but the pedal needs to be set to a channel between
1 and 4. CH1 = LED5, CH2 = LED4, CH3 = LED 4+5, CH4, LED3. Tap the active footswitch to
enable or disable MIDI clock (all five LEDs light when enabled.) Power cycle the pedal to save
and exit.
